Display Features - Unit Connection Technology FT012TH Manual

1. Temperature
2. Temperature units (°F or °C)
3. Temperature, Rate of Change indicator
4. Temperature Calibrated Icon (when the
calibration is displayed )
5. Emission Icon (flashes when updating)
6. Humidity, Rate of Change indicator
7. Min/Max Clears daily mode
4. Close the battery door. on the table or on the wall.
2 Display Features
2.1 Comfort Colorful Icon
The comfort icon is based on humidity ranges specified in Figure 3.
RH<45%
Dry
Figure 2
8. Low power indicator
9. Humidity Calibrated Icon (when the calibration is
displayed )
10. Humidity Comfort Colorful Icon
11. Relative Humidity (%)
12. Channel 1,2,3,4,5,6,7,8 indictor
13. Min/Max Record mode
RH 45%~65%
Comfortable
Figure 3
RH >65%
Wet
