Executive standard:
En71 and En62115
ASTM F963-17
INSTALLATIONANDOPERATING
INSTRUCTIONS
WARNING:
!
·Assembly by an adult.
·This toy is unsuitable for children under 3 years due to
its maximum speed.
·Protective equipment should be worn.Not to be used in
traffic. A reminder that the toy should be used with
caution since skill is required to avoid falls or collisions
causing injury to the user or third parties.
Photos are for reference ONLY.
Advertisement
Table of Contents
Related Manuals for Lean BDM-0912
Summary of Contents for Lean BDM-0912
- Page 1 INSTALLATIONANDOPERATING INSTRUCTIONS WARNING: ·Assembly by an adult. ·This toy is unsuitable for children under 3 years due to its maximum speed. ·Protective equipment should be worn.Not to be used in traffic. A reminder that the toy should be used with caution since skill is required to avoid falls or collisions causing injury to the user or third parties.
- Page 2 INSTALLATION INSTRUCTION The illustrations in this instruction are used for easier understanding of the operation method of the product and the product structure. Please note there may be differences between the pictures and the physical item. In order to improve the quality, we may change part of the structure and appearance of the product without an advance notice.
- Page 3 96 months...
- Page 4 Specification PICTURE PICTURE Name specification (Recoverable fuse: 5A) Battery and fuse (6V4.5AH*1) G(Front wheel) H( handlebar shield) single drive 6V(Rotational Speed:18000r/min) Motor Suitable age 37-96 months Maxweight 20KG Body size 1080*520*720MM J(Left foot pedal) I(Right foot pedal) Speed 3-6KM/h Hours of use charging8-12hours，using1 to 2 hours Input：110~240V Charger...
- Page 5 Installation Steps Preparation for Installation: 1.Take out C (handlebar components), put H (handlebar shield) on the corresponding position as shown in figure, use S3 (M5 screw) and S4 (M5 nut) to fix H (handlebar shield) and handlebar together.(Use S5(M5 spanner)). 2.Use O (M8 spanner) to loosen and remove Q (M8 nuts), S(M8 shims)、R...
- Page 6 Install jockey pulley Ⅰ: 1. Use Spanner in a anticlockwise direction to unsnatch two Q (M8 nuts) from the rear axle. 2. Use spanner in a anticlockwise direction to unsnatch two R (M6 nuts) from the jockey pulley fixed axis. Install jockey pulley Ⅱ: 1.
- Page 7 2.Instructions of the recoverable fuse When the current exceeds 5 amperes, the recoverable fuse will automatically cut off the power supply for 5-10seconds, then the current S2、 Q2 will be resupplied. (optional) Install music board Ⅱ: 1. Properly connect X and Y lamp line terminal. Simple circuit diagram for single-drive,no-remote-control version 2.
- Page 8 3.Charging instructions. 1.Recharge the battery 1. Low battery voltage 2.Stop using for a few 2. Electric protection minutes 3. Switch is not reaching the 3.Use it according to correct position the directions 4. The Battery connector fell 4.Re-plug off or loosened 5.Go to the maintenance 5.
