Summary of Contents for PNY QUICKCHIP 133
- Page 1 UICK UICK Processor Upgrade for 486 Based Systems Installation Guide for 486-Based SX, SX2, DX & DX2 Systems...
- Page 2 Even if the registration card is not returned, the limitation of liability and disclaimer of any implied warranties by PNY Technologies, Inc. are still in effect. This warranty is valid only within the United States and applies only to QUICKCHIPs th at are new, in cartons and that are unopened on the date of original purchase.
-
Page 3: Table Of Contents
Table of Contents Section 1: Quick Start • Installation Overview ..........Page 4 •... -
Page 4: Installation Overview
Section 1 Quick Start Installation Overview We strongly recommend reading this entire manual prior to the installation procedure of the QUICKCHIP. Failure to do so may result in damage to your computer and/or the QUICKCHIP. If you feel uncomfortable with any part of the installation process, please take your computer to a trained computer technician or service center. -
Page 5: Section 2: Introduction
Section 2 Introduction Congratulations on the purchase of your PNY Technologies QUICKCHIP 133™ processor upgrade for 80486 SX, SX2, DX and DX2 systems. We strongly recommend reading this entire manual prior to the installation procedure of the QUICKCHIP. Failure to do so may result in damage to your computer and/or the QUICKCHIP. -
Page 6: Compatibility And Performance
The QUICKCHIP 133 uses clock-quadrupling technology which enables your computer to run four times faster than the native 486 processor speed. At 133MHz, the QUICKCHIP 133 is rated at Pentium-75 plus performance. The QUICKCHIP 133 features 16KB internal cache, a built-in math coprocessor, and 32-bit internal and external processing running internally at 133MHz and externally at 33MHz. -
Page 7: The Components
Section 1 Introduction The Components The QUICKCHIP consists of several main components which include: The Heatsink - Cools the 133 processor The 133 Processor - The replacement for the 486 The Module - Contains the circuitry, switches, pins and 133 processor DO NOT attempt to separate any of the QUICKCHIP’s components. -
Page 8: Pin 1 Orientation
Section 2 Introduction Pin 1 Orientation Notice that one of the corners on the QUICKCHIP 133 upgrade has a white stripe and beveled edge or other distinguishing mark. This corner signifies Pin 1 and must line-up with Pin 1 on the processor socket (Figure 2.1). -
Page 9: Special Notes
PNY Technologies is NOT responsible for damages to your computer or lost data even if PNY Technologies has been advised of the possibility of such damages. -
Page 10: Section 3 Installation
You will unlock the socket using the side bar or retaining screw, remove the 486 processor and install the QUICKCHIP 133 into the empty ZIF socket. If you have a ZIF socket with an overhead bar, call technical support BEFORE installing the... -
Page 11: Preliminary Speed Check Using Syschck
Section 3 Installation Preliminary Speed Check Using SysChk SysChck is a utility located on the Utilities Disk that measures different components in your computer. Use this utility to measure the CPU Speed and CPU Throughput Speed. You can measure the performance of your computer by checking SysChck. SysChck must be run in DOS. -
Page 12: Removing The 486 Processor
6. Take note of the position and orientation of Pin 1 of the 486 by marking it with a felt tip pen before you remove it. The QUICKCHIP 133 will be installed with its Pin 1 in the same position as the 486 Pin 1. - Page 13 2. Once free, carefully lift out the processor with your fingers taking care not to bend or break the pins. 3. Use the QUICKCHIP 133 packing material to store the 486 chip in a safe place. Figure 3.3 Removing the 486 from a Standard...
-
Page 14: Quickchip Installation
The upgrade installation may vary according to the type and location of your 486 processor socket. Also, the orientation when installing the QUICKCHIP 133 will depend on the location of Pin 1 on the processor socket. Pin 1 of the 133 processor has a white stripe and beveled edge or other distinguishing mark. - Page 15 Make sure the side bar lever is fully rotated upward or the retaining screw is loose. With the socket in the unlocked or open position, align the pins on the QUICKCHIP 133 with the holes on the ZIF socket. You do not need to force the QUICKCHIP 133 into the socket.
-
Page 16: Completing The Installation
DOS. It cannot be run in the DOS shell through Windows®. Accessing PNYBENCH: Insert the PNY Technologies Utility Diskette in the floppy drive (A:) Congratulations! You have just increased the speed of your computer! If you experience any prob- lems, refer to the Technical Guide on page 17. -
Page 17: Troubleshooting Problems & Solutions
Section 4 T echnical Guide If you are experiencing any problems after installing the QUICKCHIP for the first time, the follow- ing section should help you find the solution. Make sure you record all jumper and CMOS settings before you change them. Check the QUICKCHIP packaging to see if you computer is on the Incompatibility List. -
Page 18: Section 4: Technical Guide
Section 4 T echnical Guide QUICKCHIP Dip Switch Settings for 4x Step 1 -Turn the QUICKCHIP over and orient its position as shown. (Figure 5.1) If the switch is: Up=ON and Down=OFF. Switches A1-6 are on the left and B1-8 are on the right. -
Page 19: Dip Switch Settings For 3X
Section 4 T echnical Guide QUICKCHIP Dip Switch Settings for 3x Option 1 - 3X 3x Write Through Step 3 - Leave the default switches A1, A2 and B1-8 “ON” Step 4 - Turn switch A3and A5 “OFF” Option 2 - 3X 3x Pass Through Step 3 - Turn switches A1, A3 and A6 “ON”... - Page 20 299 Webro Rd Parsippany, NJ 07054 Tel. 973-515-9700 • Fax 973-560-5590 On the Internet: w w w. p ny. c o m ©1998 PNY Technologies, Inc V. 5.8...
