- Page 1 SOLAR KIT A SUSTAINABLE BATTERY CHARGING GEAR User Manual WSBC-50...
-
Page 2: Table Of Contents
Contents 1. General Information ..........................1 1.1 Key Design Features ......................... 1 1.2 Warnings ............................2 2. Components and accessories ........................3 2.1 Accessories ............................. 3 3. Specifications ............................4 3.1 Module electrical specifications ......................4 3.2 Module mechanical specifications ....................... 4 3.3 Charge controller specifications ...................... -
Page 3: General Information
User manual – Ceyone solar kit 1. General Information Please read this user manual carefully before using the product. Dear Customer, Thank you for purchasing Ceyone solar kit. We hope that you get best results from our product which has been manufactured with high quality and state of the art technology. -
Page 4: Warnings
User manual – 1.2 Warnings Please read all the warnings carefully before operating the product. It is necessary to understand and keep them in mind when the system is in use. Any negligence may lead to severe damage to you and your surroundings. IMAGE DESCRIPTION DETAILS... -
Page 5: Components And Accessories
User manual – 2. Components and accessories Sr. No Components Rooftop box Charge controller Mounting bracket & fixing ancillaries Solar module 2.1 Accessories Description Sr. No Components The rooftop box is an anti-UV & ABS based best in class Rooftop box available combiner box which enables power from solar module to be transferred to the battery An IP68 &... -
Page 6: Specifications
User manual – Ceyone solar kit 3. Specifications 3.1 Module electrical specifications The figure below shows the performance curve of 50Wp module under Standard Test Conditions (STC): 1000 irradiance, Air Mass 1.5 and 25°C cell temperature. Model Efficiency WSBC-50 17.21 2.91 3.11 21.47... -
Page 7: Rooftop Box Specifications
User manual – Ceyone solar kit Ingress Protection Rating IP68 Self-consumption < 10 mA Operating temperature -35° C to +60° C Size 150 mm x 78 mm x 35 mm Weight 150 g 3.4 Rooftop box specifications Description Value Material ABS with anti-UV agent Dimension (W x H x D) 5⅛”... -
Page 8: Packaging Information
User manual – 4. Packaging information Ceyone kit comprises of 2 solar modules and its associated accessories in a single box. The main packaging box is made up of best in class 5 ply cardboard. The 2 solar modules are packed individually in a 3 ply cardboard ensuring that they do not damage themselves/ each other. -
Page 9: Installation
User manual – 5. Installation 5.1 Wiring guidelines In order to achieve optimized output, it is recommended to that the electrical connections are made in the correct manner using 14 gauge wire. Verify that the connections are secure to ensure safe operation of the kit. It is recommended to use a 10 amp rated fuse before the battery for enhanced safety. -
Page 10: Kit Fixation Guidelines
User manual – 5.2 Kit fixation guidelines The following steps should be adhered to for kit installation/ fixation. 1. Connecting the rooftop box: The solar panel need to be connected to the rooftop box as shown in wiring diagram. Please use appropriate mating connectors between the inter-connecting wire(s) to ensure safe operation. -
Page 11: Operating Instructions
User manual – 6. Operating Instructions 6.1 Charge controller Before making initial connections, please ensure that the battery has enough charge or is at adequate voltage level such that the controller can sense the battery. The controller is only suitable for LEAD ACID BATTERIES: OPEN, AGM, and GEL type. -
Page 12: Special Instructions
User manual – Indication that the battery voltage is below threshold limit. The battery shall only deliver power once its voltage is above 12.6V Indication that the power output is good 6.4 Special Instructions To obtain maximum output it is suggested that the panel’s direction is adjusted such that it faces the sun. Locate a clear sunlit area, free from overhanging branches, wires or obstructions to ensure maximum generation Broken modules cannot be repaired and contact with any module surface or frame can lead to electrical... -
Page 13: Frequently Asked Questions
User manual – 8. Frequently Asked Questions Question 1: Can the kit charge two or more 12 V batteries connected in parallel? Answer: Yes, it is possible if the batteries have the same type & capacity and are wired in parallel as a single 12V battery bank.
