Lock Buehl ER/Schaff house (model TS75)
1/3
TS75
To replace :
Substitution :
Lock Buehl ER/Schaffhouse (model TS75)
prudhomme S.a
LR 180 * * TS75
Optional :
CP/TS75 (drilling gauge)
90
SHXb21
CP/DV (drilling gauge)
100
Pin GVR + écrou
100
LR180
prudhomme S.a
38, Rue Charles de Gaulle F-94140 Paris/Alfortville - www.prudhommesa.com - Tél. : +33 o1 45 18 19 20 - Fax : +33 o1 45 18 19 21
