Vimtag Cloud Box Quick Installation Manual

Cloud Box
S1 Series
Quick Installation Guide
Thank you for using Vimtag Cloud Box, Please
follow these steps.
V1.1
Product Diagram
Reset needle
POWER LED
Power port
RESET
Description Introduction
Reset needle For clicking the reset hole
POWER LED Red light shows normal power supply.
Different flash shows different device working states.
Network LED
Power port 12V-5A external power
Ethernet port External WAN port
FN Button Reserved function keys
RESET Restart key,press it 1s when box working normal,
then box restarted,and back to factory setting .
Connect Box
After cloud box connected to the ethernet and power, waiting
for 50s, then the green light of network flash once every 3s.
It shows cloud box connected successfully.
Network Status
Light
FN Button
Ethernet port
Before-operation introduction
① Cloud camera connection
First please make sure you have Vimtag brand cloud camera. And
connect to be online.
② Add cloud box
Add the new cloud box to the registered account
Remarks: the website visit and app download address:www.vimtag.com
Router
Power
