Metra Electronics AXXESS AXDSPX-HD1 Installation Instructions Manual

Dsp package with water resistant enclosure 1998-2013

Hide thumbs

INTERFACE COMPONENTS

• AXDSP-X circuit board

• AXDSPX-HD1 harness (with gaskets)

• AXDSPX-HD1 enclosure

• Case

• Cap (with O-ring)

AxxessInterfaces.com

Harley Davidson DSP

Package with Water

1998-2013

Resistant Enclosure

INTERFACE FEATURES

• Water resistant plug-n-play harness for the AXDSP-X

• AXDSP-X included

• Water resistant enclosure with zip tie mounts included

• Amplifier, if equipped, does not need to be retained

• All wiring will be done at the radio location

• Micro-B USB updatable

AXDSPX-HD1

I N S T A L L A T I O N I N S T R U C T I O N S

TABLE OF CONTENTS

Connections ............................................................2

Installation ......................................................... 3-4

TOOLS & INSTALLATION ACCESSORIES REQUIRED

• Crimping tool and connectors, or solder gun,

solder, and heat shrink • Tape • Wire cutter

• Zip ties

Product Info

REV. 1/30/20 INSTAXDSPX-HD1

Table of Contents

Need help?

Do you have a question about the AXXESS AXDSPX-HD1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Metra Electronics AXXESS AXDSPX-HD1

Page 1 • All wiring will be done at the radio location • Micro-B USB updatable INTERFACE COMPONENTS • AXDSP-X circuit board • AXDSPX-HD1 harness (with gaskets) Product Info • AXDSPX-HD1 enclosure • Case • Cap (with O-ring) AxxessInterfaces.com © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 1/30/20 INSTAXDSPX-HD1...
Page 2 CONNECTIONS Zip-tie Mounts Case Factory Radio White / Front Left + Green / Rear Left + White/Black / Front Left - Green/Black / Rear Left - AXDSP-X Gray / Front Right + Purple / Rear Right + Circuit Board Gray/Black Front Right - Purple/Black / Rear Right - Cap (with O-ring) 16-Pin...
Page 3 INSTALLATION 1. Remove the fairing to access the back of the factory radio. Refer to MetraOnline, part number 99-9600 for fairing disassembly instructions. 2. Install the AXDSPX-HD1 harness and make all necessary connections, but leave the amp turn-on wire disconnected. 3. With the arrow stamped onto the cap facing upwards, push the 16-pin connector from Zip-tie Mounts Case the AXDSPX-HD1 harness into the left side of the cap.
Page 4 INSTALLATION (CONT’D) 7. Download and install the AXDSP-X app from the Google Play Store or Apple App Store. 8. Open the app and follow the instructions on the Bluetooth Connection tab to pair the mobile device to the AXDSP-X. (Figure B) 9. Scroll to the Configuration tab then select the vehicle type. Press the Lock Down button to save the configuration.
Page 5 REV. 1/30/2020 INSTAXDSPX-HD1...
Page 7 REV. 1/30/2020 INSTAXDSPX-HD1...
Page 8 Log onto www.installerinstitute.com or call 800-354-6782 for more information and take steps toward a better tomorrow. Metra recommends MECP certified technicians AxxessInterfaces.com © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 1/30/20 INSTAXDSPX-HD1...
