- Page 1 MANUFACTURE OF DIGITAL PRESSURE SWITCH 1” DPG3100T SERIES AND CONTROL INSTRUMENTS Instruction Manual...
- Page 2 10 to 500 Hz freq., 0.06” (1.5mm) amplitude in X, Y, Z directions for (2 hours). IP Grade IP54 Connection Cable UL2464, 28AWG, 5P, ø4mm, 50cm Weight spprox. 0.15kg Repeatability ±1% of full scale Response Time 135 ms New-Flow Digital Pressure Switch 1” Instruction Manual page 1...
- Page 3 Once Power is applied, the display will show the current pressure (factory default units: psi) To display the current temperature, tap the Setting Key (factory default unit: °F). DPG 3100T OUT1 OUT2 After 5 seconds the display will automatically return to pressure mode. New-Flow Digital Pressure Switch 1” Instruction Manual page 2...
- Page 4 Once the desired setting is displayed, press the Setting Key. The displayed setting will be entered and the next parameter setting, output mode in this case, will be displayed. New-Flow Digital Pressure Switch 1” Instruction Manual page 3...
- Page 5 The digit will reset to zero (roll over) after nine has been reached in case the desired number has been accidentally passed. To scroll to the next digit, tap the Carry Key. Once the rightmost digit has been set, press the Setting Key to go to the next parameter. New-Flow Digital Pressure Switch 1” Instruction Manual page 4...
- Page 6 “2L” and then it will display the current value of the high setpoint. Once the rightmost digit has been set, press the Setting Key to go to the next parameter. New-Flow Digital Pressure Switch 1” Instruction Manual page 5...
- Page 7 Finally, the display will read “loAd” for approximately 3 seconds. DPG 3100T OUT1 OUT2 During this time the parameters are saved and loaded. The sensor will return to pressure display mode atuomatically. New-Flow Digital Pressure Switch 1” Instruction Manual page 6...
- Page 8 A set screw, provided, is used to block the unused port. It is advised to use thread sealant when installing the set screw. New-Flow Digital Pressure Switch 1” Instruction Manual page 7...
