* PressIT is a nickname for "Wireless Presentation System".
Thank you for purchasing the Panasonic product.
• Please read these instructions before operating this product and retain
them for future reference.
• Be sure to read "Safety Precautions " (page 2) before use.
English
DA0121TS0 -PB
Wireless Presentation System Receiver Board
Operating Instructions
Basic Guide
For business use
TY-SB01WP
Model No.
2
3
4
5
6
10
15
17
19
DPQX1531ZA/X1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PressIT TY-SB01WP and is the answer not in the manual?

Questions and answers

Related Manuals for Panasonic PressIT TY-SB01WP

Summary of Contents for Panasonic PressIT TY-SB01WP

  • Page 1: Table Of Contents

    Precautions for use Part Names Installtion of the receiver board Basic Use Thank you for purchasing the Panasonic product. Transmitter Extension Method (Pairing) 8 • Please read these instructions before operating this product and retain Setting them for future reference.

  • Page 2: Safety Precautions

    Safety Precautions WARNING: Do not use the product near an automatic door, fire alarm or other automatic control devices. When mounting or removing this product on or from Radio waves from this product may affect automatic the flat panel display unit, be sure to turn the power control devices, which may cause an operational error, off, and remove the power plug from the socket.

  • Page 3: Precautions For Use

    This product is a Wireless Presentation System Details of usage Receiver Board used by being attached to a For details of usage, read “Operating Instructions - Panasonic display. Functional Manual”. Download the “Operating Instructions - Functional Do not touch this product directly by hand.

  • Page 4: Part Names

    Part Names Antenna ▼ Connection terminals / Controls FUNCTION button Used to save a pairing file to the USB memory. LAN terminal (RJ45) Connects to the network to change the settings of the product. USB terminal (Type-A) Connects the transmitter or USB memory when pairing devices. Use this by connecting an HID device (mouse, touch module). FUNCTION LED Displays the pairing status. Power Indicator ▼ Connection terminals / Controls Displays the power supply status, and connection...

  • Page 5: Installtion Of The Receiver Board

    Installtion of the receiver board Insert the receiver board to the main unit The installation instruction below is based on the flat panel display SQ1 series as an example. slot, and tighten the 2 screws. For attaching or removing this product to or from the flat Fix the receiver board with the 2 screws removed in panel display unit, it is recommended to ask a qualified step 1.

  • Page 6: Basic Use

    Basic Use Receiver board Transmitter Turn on the display. Connect the USB terminal and HDMI input terminal of the transmitter to the image Switch the input of the display to [SLOT]. output device. Pair the receiver board and the transmitter. •...
  • Page 7 Main LED changes from red blinking Pressing the main button again changes the main LED to white and returns to standby state. (connecting) to white illumination (standby). (The screen returns to the standby screen as well.) • When using multiple transmitters, the image is switched to the image of the transmitter of which the main button is pressed.

  • Page 8: Transmitter Extension Method (Pairing)

    Transmitter Extension Method (Pairing) Wait for a while until the FUNCTION LED of the Pairing by connecting the receiver board receiver board blinks in white. Then, pairing starts and transmitter automatically. Slide the mode switch to the STD side. “Pairing…” (pairing in progress) is displayed on the standby screen. Pairing is complete.
  • Page 9 Slide the mode switch to the EXT side. Pairing by saving a file to the USB memory Supported device ● Commercially available USB memory devices are supported. (Those with security functions are not supported.) Supply power to the transmitter. ● USB memory devices other than those formatted in TY-WPB1 FAT16 or FAT32 cannot be used.

  • Page 10: Setting

    Panasonic display link function Sets whether to display or hide the information of the Just connect the receiver board to a Panasonic display device connected to the HDMI terminal and SLOT. supporting this product and turn them on to perform...
  • Page 11 ■ ● [Wireless presentation settings] [Wireless presentation link] Sets the link of the Display with this product. Note [Off]: Does not link with this product. • Approx. 5 seconds may be required to reflect the [On]: Links with this product. menu settings.
  • Page 12 Setting Continued ● ● [Date/Time setting] [Language link] Specifies the display style of date on the standby [Enable]: Sets the language for the standby screen, screen. no-signal image and Web setting screen to [Y-M-D]: e.g. 2021-08-24 the language set for [OSD language]. [Y/M/D]: e.g.
  • Page 13 ● [HDMI-CEC control] [Power off / The device turns off/on (standby) in Enables/Disables the HDMI-CEC function. on]: conjunction with the power-off/on [Disable]: Disables HDMI-CEC control. (standby) operation of the Display. [Enable]: Enables HDMI-CEC control. ● [Device → Display] Note Enables/Disables the HDMI-CEC compatible device to • Enables/Disables the Display to perform interlocking perform interlocking control of the Display.
  • Page 14 Setting Continued ■ SLOT settings Set for SLOT. [SLOT settings] - submenu screen SLOT settings SLOT information SLOT power link SLOT standby SLOT power on SLOT forced termination ● [SLOT standby] Sets the power supply status for the SLOT when the unit is in standby mode.

  • Page 15: Notes On Using Wireless Lan

    Notes on Using Wireless LAN Wireless LAN uses radio waves in the 5 GHz bands. Using the product outside the country ● It is forbidden to take the product outside the country Be sure to read and fully understand the following items or region where you purchased it, so use it only in before use.
  • Page 16 Authorized Representative: Panasonic Testing Centre Panasonic Service Europe, a division of Panasonic Marketing Europe GmbH Winsbergring 15, 22525 Hamburg, Germany Indoor use restrictions are to be followed for the following countries if using 5 GHz frequency band.

  • Page 17: Request Regarding Security

    Request Regarding Security When using this product, take safety measures • A malicious third-party may access your personal against the following incidents. or corporate network without authorization and ● Personal information being leaked via this product engage in the following types of behaviour. ●...
  • Page 18 Depending on the specifications of the wireless LAN, a malicious third-party may be able to break security settings by special means. Please contact Panasonic if you need help taking care of security settings or other such. If you cannot perform security settings for your wireless LAN by yourself, please contact the Panasonic Support Center.

  • Page 19: Specifications

    Specifications Model No. TY-SB01WP Wireless Presentation System Receiver Product name Board Video output HDMI × 1 (HDCP1.4) 1920 x 1080/60p, Output resolution 3840 x 2160/30p (max.) Number of simultaneous connections Wireless IEEE802.11a/n/ac communication Bluetooth (GFSK, π/4-DQPSK, 8DPSK) standard Data rate wireless 867 Mbps (max.) Frequency band 5 GHz (5.150 GHz to 5.250 GHz) Security WPA/WPA2...
  • Page 20 Web setting screen of this product. At least three (3) years from delivery of this product, Panasonic will give to any third party who contacts us at the contact information provided below, for a charge no more than our cost of physically performing source code distribution, a complete machine-readable copy of the corresponding source code covered under GPL V2.0, LGPL...
  • Page 21 Any changes or modifications Operation is subject to the following two conditions: (1) not expressly approved by Panasonic Corp. of North This device may not cause harmful interference, and America could void the user’s authority to operate (2) this device must accept any interference received, this device.
  • Page 22 Whenever the date of original purchase cannot be satisfactorily determined, the date of manufacture of the unit will be deemed to be the effective date of the warranty. Panasonic reserves the right to audit and reject any warranty claim that cannot be substantiated.
  • Page 23 Whenever the date of original purchase cannot be satisfactorily determined, the date of manufacture of the unit will be deemed to be the effective date of the warranty. Panasonic reserves the right to audit and reject any warranty claim that cannot be substantiated.
  • Page 24 If you wish to discard this product, please contact your local authorities or dealer and ask for the correct method of disposal. Notice (U.S.A. only) Disposal may be regulated in your community due to environmental considerations. For disposal or recycling information, please visit Panasonic website: https://www.panasonic.com/us/corporate/sustainability.html or call 1-888-769-0149. English...
  • Page 25 Panasonic System Solutions Company of North America Unit of Panasonic Corporation of North America Executive Office : Two Riverfront Plaza, Newark, New Jersey 07102 Panasonic Testing Centre Panasonic Service Europe, a division of Panasonic Marketing Europe GmbH Winsbergring 15, 22525 Hamburg, F.R. Germany English Web Site: https://panasonic.net/cns/prodisplays/ © Panasonic Corporation 2021...
