T-1GD Quick Start Guide
This guide helps you install and use your T-1GD for the first time.
Go to
Scan for full manual
Step 1: Check what's in the box
T-1GD 1 Gang bracket
Step 2: Install the T-1GD
Use T-1GD for installing a Kramer 1 gang US-D size wall plate in a TBUS with a dual power socket opening frame.
To connect the T-1GD:
1. Attach the faceplate of the wall plate.
2. Use the two M3x6 screws (supplied with
the kit) to attach
T-1GD
T-1GD Quick Start (P/N: 2900-300971QS REV 1)
www.kramerav.com/downloads/T-1GD
2 M3x6 screws
to the wall plate.
P/N: 2900- 300971QS
to download the latest documentation.
2 M3x5 flat-head screws
Rev: 1
1 Quick start guide
