1.
INPUT HI - High sensitivity input (also has a brighter tone).
2.
INPUT LOW - Low sensitivity input (also has a slightly darker tone).
3.
CHANNEL SELECT – Front panel channel switching function. Button must be OUT for footswitch to operate.
4.
GAIN - Amount of overdrive on RED Channel.
5.
HI GAIN – Gain Stacking Switch. Activates additional tube overdrive gain stage. Normal = 3 stages, Hi = 4 stages.
6.
VOLUME - Amount of volume on RED Channel. Pre FX loop.
7.
BOOST - Switches from low gain (clean to slightly dirty) to medium gain (crunch to medium overdrive)
8.
TREBLE – Passive High frequency equalization.
9.
EDGE – Frequency-dependent gain boost. Enhances upper string harmonics and sustain.
10. MIDDLE – Passive Mid frequency equalization.
11. SHIFT - Shifts Treble, Middle and Bass shelving down (Mid Boost)
12. BASS – Passive low frequency equalization.
13. GAIN - Amount of overdrive on GREEN Channel.
14. HI GAIN – Gain Stacking Switch. Activates additional tube overdrive gain stage. Normal = 3 stages, Hi = 4 stages.
15. VOLUME - Amount of volume on GREEN Channel. Pre FX loop.
16. BOOST - Switches from low gain (clean to slightly dirty) to medium gain (crunch to medium overdrive)
17. TREBLE – Passive High frequency equalization.
18. EDGE – Frequency-dependent gain boost. Enhances upper string harmonics and sustain.
19. MIDDLE – Passive Mid frequency equalization.
20. SHIFT - Shifts Treble, Middle and Bass shelving down (Mid Boost)
21. BASS – Passive low frequency equalization.
22. MASTER VOLUME - Power amp volume control. Post FX loop
23. GRAPHIC EQ (Optional) – 100Hz, 250 Hz, 630 Hz, 1.2KHz, 2.3KHz, 5KHz, 12 dB cut or boost per band. Activated
by rear panel pushbutton or footswitch. Rear panel button must be OUT for footswitch to operate.
24. PRESENCE – High frequency variable feedback in power amp section. Mounted on rear panel on EQ equipped
models.
25. VOICING - Frequency contour. Increases 6dB per octave-2.5 kHz up, 250 Hz down. Non-EQ models only.
26. DEPTH - Variable damping (Low frequency resonance). Mounted on rear panel on EQ equipped models.
27. STANDBY - Turns on high voltage to output section.
MAINS - Lovely emerald green, don't you think?
28.
1201 S. FLOWER STREET
BURBANK, CA 91502
PH (818) 846-4000 FAX (818) 846-4040
PITTBULL MODEL G-50-CL FUNCTIONS
FRONT PANEL, LEFT TO RIGHT
URL:
e-mail:
www.vhtamp.com
productinfo@vhtamp.com
