MIDIbox TIA
What is it?
The
Television Interface Adaptor (TIA)
console, generating the screen display, sound effects, and reading input controller.
Stella = Name (by its maker) of Atari hardware design engineer Joe Decuir's bicycle
TIA = Television Interface Adapter
Where do i find this chip?
You can easily find an old and used console on the web.
Atari 2600 Models and Clones
On the motherboard:
Have a look at
2600 Connection site
TIA = "Stella" = MM9031N = UM6525N = CO10444 = CO10444D (NTSC, U.S.A. & SECAM, France)
TIA = "Stella" = UM6526P1 = CO11903 (PAL, Europe + Australia + most of the rest of the world)
MIDIbox - http://www.midibox.org/dokuwiki/
is the custom chip that is the heart of the
Atari 2600 on eBay
to find it.
