33" ELECTRIC FIREPLACE 3D INSERT
ITEM: 95146
OWNER'S MANUAL AND SAFETY INSTRUCTIONS
SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY,
OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE PRODUCT'S
SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM (OR MONTH
AND YEAR OF PURCHASE IF PRODUCT HAS NO NUMBER)
FOR QUESTIONS PLEASE CALL OUR CUSTOMER SUPPORT: (909) 628 0880 MON-FRI 9AM TO 3PM PST
Advertisement
Table of Contents
Summary of Contents for Intertec Data Systems Barton 95146
- Page 1 33” ELECTRIC FIREPLACE 3D INSERT ITEM: 95146 OWNER’S MANUAL AND SAFETY INSTRUCTIONS SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY, OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE PRODUCT’S SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM (OR MONTH AND YEAR OF PURCHASE IF PRODUCT HAS NO NUMBER) FOR QUESTIONS PLEASE CALL OUR CUSTOMER SUPPORT: (909) 628 0880 MON-FRI 9AM TO 3PM PST...
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION GENERAL SAFETY WARNINGS Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. SAFETY WARNING DO NOT use this product or any available optional equipment without first completely reading and understanding these instructions and any additional instructional material such as owner’s manuals, service manuals or instruction sheets supplied with this product or optional equipment. - Page 3 IMPORTANT SAFETY INFORMATION DO NOT operate the fireplace with the glass panel removed, cracked or broken. Servicing should only be done while the fireplace is disconnected from the power outlet. Unplug fireplace if not being used for an extended period of time. DO NOT use outdoors.
-
Page 4: Specifications
FEATURES 33” Curved Electric Fireplace Insert Wood Fireplace Wall Mounted Adjustable Temperature with Remote Control This electric firebox can heat up to an impressive 400 square feet. 33” curved electric firebox features a realistic wood burning flame effect and simulated brick refractory as well as accent lights to enhance the flame. -
Page 5: Electrical Connection
INSTALLATION GROUNDING This heater is for use on 120 volts. The cord had a plug as shown. An adapter as shown is available for connecting three-blade grounding-type plugs to two-slot receptacles. The green grounding lug extending from the adapter must be connected to a permanent ground such as a properly grounded outlet box. The adapter should not be used if a three-slot grounded receptacle is available. -
Page 6: Remote Control
INSTALLATION and OPERATION REMOTE CONTROL The infrared remote control relies on a line of sight and must be pointed at the flame screen of the fireplace to work. The remote control unit has the controls required to turn ON/OFF both the main power and the heater. If you prefer to use the touchpad control on the unit, simply open the control panel cover to access the manual buttons. -
Page 7: Maintenance
MAINTENANCE DANGER: Disconnect power before servicing the heater. WARNING: Any electrical re-wiring of this appliance must be done by a qualified electrified. This wiring must be done in accordance with local codes and/or in Canada with the current CSA C22.1 Canadian Electrical Code, and for US installations, the National Electrical Code ANSI/NFPA NO 70. -
Page 8: Circuit Diagram
MAINTENANCE and TROUBLESHOOTING CIRCUIT DIAGRAM WARNING: Any electrical re-wiring of this appliance must be done by a qualified electrician. This wiring must be done in accordance with local codes and or/in Canada with the current CSA C22.1 Canadian Electrical Code, and for US installations, the National Electrical Code ANSI/NFPA NO 70. If repairing or replacing any electrical component or wiring, the original wire routing, color coding and securing locations must be followed. -
Page 9: Please Read The Following Carefully
PLEASE READ THE FOLLOWING CAREFULLY THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT.
