Summary of Contents for Stones Sound Studio S200W-V2
- Page 1 STONES S200W-V2 USER MANUAL Subwoofer Amplifier with TWIN A-V FILTER CURVES STONES SOUND STUDIO S200W-V2 INS 14-2013.doc...
- Page 2 STONES - S200W-V2 Installation and Operation Instructions By Russell Storey FEATURES NEW upgraded STONES S200W-V2 Amplifier Excellent for low impedance sub driver loads single or twin 10" 12" 15" subwoofers. Speaker sockets with high level in Very stable under all loads ...
-
Page 3: Quick Setup
STONES - S200W-V2 QUICK SETUP CONTROLS & RECOMMENDED SETTINGS 1. PWR/PRT SET SWITCH TO “ON” (OFF / AUTO /ON/) 2. LEVEL (GAIN) SET TO “9 O’clock ” 3. FREQ ( Frequency) SET TO “9 O’clock 4. PHASE SET SWITCH TO “REV”... -
Page 4: Frequency Control
STONES - S200W-V2 (LEVEL) CONTROL - volume Adjusts the output level of the Subwoofer Amplifier. Russell‘s Tip 1: For LEVEL #### Warning #### Don’t set the volume past 12 O’clock with the Level Control. This amp is a deceivingly powerful amplifier and can and will damage some subwoofer drivers. If you don’t have enough level from the sub amp it’s the HT amplifier or integrated amplifier line signal level out is not high enough to drive the... -
Page 5: Phase Switch
STONES - S200W-V2 PHASE SWITCH Selectable between 0° and 180°. This will aid in subwoofer room placement. Russell‘s Tip 3: PHASE The correct position will be the one that provides the most apparent/loudest bass output level and provides fast tight bass. - Page 6 STONES - S200W-V2 STONES S200W-V2 200W Subwoofer Amplifier - Audio and Video Filter curves...
- Page 7 STONES - S200W-V2 HUM & NOISE Home Theatre 2 Channel Amplifier As we have a mixture of different earth points around the house via TV antennas, satellite dishes, Foxtel, set top boxes etc. and also combine this with the use of 2 pin (no earth) and 3 pin (earth) equipment in our systems, sometimes a low or high level 50 Hz hum comes out through the subwoofer or main L&R...
- Page 8 STONES - S200W-V2 STONES Recommended HT and Subwoofer Room location V2 2010...
- Page 9 STONES - S200W-V2 Input/Outputs LOW LEVEL IN: These are line level RCA inputs used to connect from the Home Theatre (Sub out), RCA line out OR pre- amplifier outputs to the LOW LEVEL INPUTS on the S200W V2 Subwoofer Amplifier.
- Page 10 STONES - S200W-V2 SUBWOOFER SPEAKER CONNECTIONS: Connect the Subwoofer speaker to the Subwoofer amplifier using the supplied speaker cable with push on speaker connectors marked speaker negative (-) and positive (+). Russell‘s Tip: Solder speaker leads to Subwoofer Speaker as this enables most reliable connection compared to push on connectors which can vibrate loose with very low frequencies inside the cabinet.
-
Page 11: Specifications
STONES - S200W-V2 SPECIFICATIONS STONES S200W-V2 Subwoofer Amplifier This Subwoofer is designed to operate with 4 to 8 ohms Nominal speaker loads and NOT 2 Ohm loads. Rated Power Output: 200 Watts Signal to Noise Ratio: 95 dB Amplifier Dimensions:... - Page 12 STONES - S200W-V2...
- Page 13 STONES - S200W-V2 RECOMMENDED SETTINGS FOR BEST SOUND using an RCA cable from the Sub Out on Home Theatre receiver connected to the LOW LEVEL inputs of the S200W-V2 Subwoofer amp LOW LEVEL IN: Wiring Diagram Options These are line level RCA inputs. Use to connect from the Home Theatre (Sub ou t) RCA line out OR pre-amplifier outputs.
- Page 14 Russell‘s Tip: Use high level inputs to achieve the best bass transients and quality for music based systems NOTE. The HIGH LEVEL IN on the S200W-V2 is a high impedance “ signal input only “ and will not affect the sound quality of the speakers or the amplifier.
- Page 15 STONES - S200W-V2 High Level In Wiring Diagram Options...
