Introduction

The VX-3200V is carefully aligned at the factory for the specified performance across the
frequency range specified for each version. Realignment should therefore not be necessary
except in the event of a component failure, or altering version type. All component
replacement and service should be performed only by an authorized Vertex Standard
representative,or the warranty policy may be void.
The following procedures cover the sometimes critical and tedious adjustments that are not
normally required once the transceiver has left the factory. However, if damage occurs and
some parts subsequently are placed, realignment may be required. If a sudden problem
occurs during normal operation, it is likely due to component failure; realignment should not
be done until after the faulty component has been replaced.
We recommend that servicing be performed only by authorized Vertex Standard service
technicians who are experienced with the circuitry and fully equipped for repair and
alignment. Therefore, if a fault is suspected, contact the dealer from whom the transceiver
was purchased for instructions regarding repair. Authorized Vertex Standard service
technicians realign all circuits and make complete performance checks to ensure compliance
with factory specifications after replacing any faulty components.
Those who do undertake any of the following alignments are cautioned to proceed at their
own risk. Problems caused by unauthorized attempts at realignment are not covered by the
warranty policy. Also, Vertex Standard reserves the right to change circuits and alignment
procedures in the interest of improved performance, without notifying owners.
Under no circumstances should any alignment be attempted unless the normal function and
operation of the transceiver are clearly understood, the cause of the malfunction has been
clearly pinpointed and any faulty components replaced, and realignment determined to be
absolutely necessary.
The following test equipment (and thorough familiarity with its correct use) is necessary for
complete realignment. Correction of problems caused by misalignment resulting from use of
improper test equipment is not covered under the warranty policy. While most steps do not
require all of the equipment listed, the interactions of some adjustments may require that
more complex adjustments be performed afterwards.
Do not attempt to perform only a single step unless it is clearly isolated electrically from all
other steps. Have all test equipment ready before beginning, and follow all of the steps in a
section in the order presented.

Required Test Equipment

RF Signal Generator with calibrated output level at 1000MHz
Deviation Meter (linear detector)
In-line Wattmeter with 5% accuracy at 1000MHz
50-
RF Dummy Load with power rating 100W at 1000MHz
4-
AF Dummy Load
VX-3200V Alignment
1/6
FCC ID: K66VX-3200V
Alignment
Vertex Standard Co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VX-3200V and is the answer not in the manual?

Questions and answers

Summary of Contents for Vertex VX-3200V

  • Page 1 VX-3200V Alignment Introduction The VX-3200V is carefully aligned at the factory for the specified performance across the frequency range specified for each version. Realignment should therefore not be necessary except in the event of a component failure, or altering version type. All component replacement and service should be performed only by an authorized Vertex Standard representative,or the warranty policy may be void.
  • Page 2 DC Voltmeter VHF Sampling Coupler IBM PC / compatible Computer Oscilloscope Vertex Standard VPL-1 Connection Cable & Alignment program Alignment Preparation & Precautions A 50- Ω RF Dummy Load and in-line wattmeter must be connected to the main antenna jack in all procedures that call for transmission, except where specified otherwise.
  • Page 3 With the wattmeter, dummy load and frequency counter connected to the antenna jack, and select band center frequency channel, key the transmitter and adjust TC1001 on the RF-Unit, if necessary, so the counter frequency is within 100 Hz of the channel center frequency for the transceiver version. Vertex Standard Co., Ltd.
  • Page 4 Tx Power Low:5[W](±0.1[W]) When the 10Watt level is attained, press [Enter] to lock in the new data. - [2] VCO Deviation This parameter is used to align the VCO Deviation. Vertex Standard Co., Ltd.
  • Page 5 Press the [UP]/[DWN] key, as need, to set the DCS deviation (Wide) the following specification. Press [Enter] to lock in the new data. Select the Channel 2, and set the DCS deviation (Narrow), same as Channel 1. Vertex Standard Co., Ltd.
  • Page 6 This parameter is used to align RX Tune. Select the MID frequency channel in alignment range. Set the SG output level to –7dB EMF. µ Pressing the [DWN] key, reduce the RX Tune Level and set the SINAD above 12dB. Vertex Standard Co., Ltd.
