Sony MDR-EX76LP Operating Instructions

Stereo Headphones
Operating Instructions
使用說明書
使用说明书
사용설명서
MDR-EX76LP
©2008 Sony Corporation Printed in Thailand
A
When directly connecting to a CD WALKMAN

直接連接於 CD WALKMAN /Network WALKMAN
L-shaped stereo
mini plug
L形立體聲迷你插頭
Approx. 1.2 m
約 1.2 m
∗
"WALKMAN" and "WALKMAN" logo are registered trademarks of Sony Coporation.
B
C
English
Features
• Newly-developed, high-sensitivity driver unit realizes broader dynamic range.
• N U D E EX Plus reproduces powerful bass and clear treble.
• Small diameter driver unit with angled earbud structure and hybrid silicone earbuds provide a
comfortably snug and stable fit, even during extended listening.
• Cord length adjuster supplied.
Wearing the headphones (see fig. A)
Wear the earpiece marked R in your right ear and the one marked L in your left ear.
How to use the supplied cord adjuster
You can adjust the cord length by winding the cord on the cord adjuster.
The cord can be wound to the cord length adjuster up to 50 cm.
Note
Do not wind the plug or split section of the cord, as it will strain the cord and may cause a wire
break.
4-106-724-11(1)
 
or Network WALKMAN .

時。
Cord length
adjuster
導線長度調節器
Push cord into
slot hole to
Wind the cord.
secure in place.
捲起導線。
將導線壓入槽孔以
固定到位。
How to install the earbuds correctly (see fig. B)
If the earbuds do not fit your ears correctly, low-bass sound may not be heard. To enjoy better
sound quality, change the earbuds to another size, or adjust the earbuds position to sit on your
ears comfortably and fit your ears snugly. When you change the earbuds, install them firmly on
the headphones to prevent the earbud from detaching and remaining in your ear.
To detach an earbud
While holding the headphone, twist and pull the earbud off.
z Tip
If the earbud slips and cannot be detached, wrap it in a dry soft cloth.
To attach an earbud
Push the parts inside of the earbud into the headphone until the projecting part of the headphone
is fully covered.
Cleaning the earbuds
Remove the earbuds from the headphones, and wash them with a mild detergent solution.
Specifications
Type: Closed, dynamic / Driver unit: 9 mm, dome type (CCAW) / Power handling capacity: 100
mW (IEC*) / Impedance: 16 Ω at 1 kHz / Sensitivity: 103 dB/mW / Frequency response: 6 –
24,000 Hz / Cord: Approx. 1.2 m (47 1/4 in), OFC litz cord / Mass: Approx. 4 g (0.15 oz) /
Supplied accessories: Earbuds (S × 2, M × 2, L × 2), Carrying pouch (1), Cord length adjuster (1)
* IEC = International Electrotechnical Commission
Design and specifications are subject to change without notice.
Precautions
• Please keep your headphones clean at all times especially inside the rubber earbud. (see fig. C)
If any dust or ear wax inside the earbud, you may experience some listening difficulties.
• During dry weather, you may experience mild pain in your ears. This is not by malfunction of the
headphones, but is due to static electricity accumulated in your body. It is reduced by wearing
clothes made of natural materials that do not generate static electricity so easily.
• Listening with headphones at high volume may affect your hearing. For traffic safety, do not use
while driving or cycling.
• The earbuds may deteriorate due to long-term storage or use.
Optional replacement earbuds can be ordered from your nearest Sony dealer.
繁體中文
特點
• 新研發的高靈敏度激勵單元可表現的動態範圍更加寬廣。
• N U D E EX Plus可以實現強勁低音和清晰高音。
• 小直徑激勵單元配合有角度的耳塞結構和混合矽耳塞使長時間聆聽變得穩定而舒適。
• 隨附導線長度調節器。
佩戴耳機（請參閱圖A）
將有R標記的耳機戴在右耳，L標記的耳機戴在左耳。
如何使用隨附導線調節器
您可以將導線繞在導線調節器上以調節導線長度。
導線可以在導線長度調節器上繞50 cm。
注意
請勿捲起導線的插頭或開叉部分，否則會繃緊導線並可能使導線斷裂。
正確安裝耳塞的方式（請參閱圖B）
如果耳塞不適合您的耳型，您便可能無法聽到重低音。為了享受更佳音質，請更換耳塞
尺寸，或調整耳塞的位置以舒適貼合您的耳朵。當您更換耳塞時，請將其牢固地安裝在
耳機上以防止耳塞脫落在您耳朵內。
拆掉耳塞的方式
拿著耳機，然後轉動耳塞，把耳塞拔出來。
z 提示
如果耳塞滑落且無法拆開，請用柔軟乾布進行擦拭。
安裝耳機的方式
將耳塞組件推入耳機裡，直到完全覆蓋耳機突出部分為止。
清潔耳塞
將耳塞從耳機體上拆下，並以中性清潔劑溶液清洗。
規格
型式：封閉式，動態 / 激勵單元：9 mm，圓頂型 (CCAW) / 功率處理容量：100 mW
(IEC*) / 阻抗：1 kHz時 16 Ω / 靈敏度：103 dB/mW / 頻率響應：6 - 24000 Hz / 導
線：約 1.2 m 的 OFC 絞合線 / 質量：約 4 g / 附件：耳塞 (S × 2, M × 2, L × 2)，攜
帶式保護袋 (1)，導線長度調節器(1)
* IEC = 國際電工委員會
設計和規格如有變更，恕不另行通知。
注意事項
• 請隨時保持耳機的清潔，尤其是橡膠耳塞的內部 (請參閱圖C)。
如果耳塞有灰塵或耳垢，您可能會無法順利聆聽音樂。
• 天氣乾燥時，您的耳朵可能會出現輕微疼痛。這並非耳機故障所造成的，而是由於您
的身體積累靜電所致。如果您穿著的衣物是由不易產生靜電的天然材料製成，就可減
少這種情況。
• 戴著耳機用很高的音量收聽可能會影響您的聽力。為了交通安全，切勿在駕車或騎車
時使用耳機。
• 耳塞可能會因為長期存放或使用而損壞。
可向附近的Sony經銷商訂購選購的替換耳塞。
