Quick Start
Getting to Know the PS220
Getting to Know the PS220
The graphic below points out key a ributes of the PS220.
Connect Sources Devices Here
IR (Infra-Red) Sensor
Source Selector
Front View
Front View
Front View
Active Source Indicators
Power & Indicator
Stereo Audio Output
RS-232 Port
24VDC / 1.5A
Back View
Back View
Proximity Sensor Port
Ethernet Port
USB Firmware Update
Display Outputs
Connections
Connections
Inputs and Outputs. Using the graphic above, connect the source devices to the ports labeled
above as, "Connect Source Devices Here", and the displays at loca on, "Display Outputs", port.
Connect audio, if applicable.
Power. Connect the DC power supply to the loca on, "24VDC", and the other end to your
110V/VAC power socket. The system LED will illuminate above "24VDC" loca on.
PS220 Quick Start Guide
Page 1
Advertisement
Table of Contents
Related Manuals for Presentation Switchers PS220
Summary of Contents for Presentation Switchers PS220
- Page 1 Quick Start Getting to Know the PS220 Getting to Know the PS220 The graphic below points out key a ributes of the PS220. Connect Sources Devices Here IR (Infra-Red) Sensor Source Selector Front View Front View Front View Active Source Indicators Power &...
- Page 2 Selecting a New Source Device to Display To display a new source, press the Source Selector bu on on the Front of the PS220 repeatedly un l the LED on the Ac ve Source Indicator corresponds to the desired Source Port Selec on.
