Backpack Quick Start Guide
Charge Battery
Current
Remaining
Battery
Time Until
Charge
Fully Charged
A fully charged battery will
spray up to 4 hours before
needing to be recharged
SPRAYER USE
The optimum sprayer distance is 4–6 feet
(1.22–1.83 m) from surface being sprayed
Spray in an "S" like fashion from top to
bottom of surface areas
Start at opposite end of room & progress
toward the door to avoid walking through
spray pattern & touching sprayed surfaces
(800) 741-7788
See full manual for more detail
Remove & Fill Tank
1. Unlatch tank release by
lifting upward
2. Remove tank by lifting
upward and outward from
the backpack base
3. Fill tank with water-based
chemical that is approved to
be sprayed
4. Follow any recommended
PPE requirements for
handling and using chemical
per the Safety Data Sheet
4-6'
Utilize nozzle extension for better control
and reduce amount of back-spray on the
handle and user
Maintain proper grip of handle to ensure
contact to grounding strip on trigger
Hands should remain dry
during operation
Clean & Store Daily
• All users should follow safe cleaning practices to protect
themselves from harmful exposure when cleaning
the sprayer
• Review chemical MSDS sheet for how to secure and store
your chemical solution when not in use
• Remove all chemical from tank and flush with water
• Spray water through each nozzle size for at least
30 seconds
Cleaning Nozzle
If nozzle becomes plugged, soak in hot soapy water and blow
pressurized air through to remove blockage
Register sprayers with serial number & date
code via website or app.
Connect Tank
1. Any excess moisture on
the tank should be wiped
away before replacing
tank into housing
2. Lower the tank onto the
backpack base unit
3. Secure tank by pressing
down on latch at top
of unit
To reduce any static build up in the user,
the user's free hand should be used to
touch grounded surfaces that have not
been sprayed (e.g. metal components of
adjacent equipment)
Electrostatic Discharge (ESD)
In environments less conducive to natural
electrostatic charge dissipation, ESD events
may occur, resulting in a mild static shocking
sensation for the operator. To avoid this,
operators should maintain a firm grip on
the handle grounding strip & frequently
touch objects that are not being sprayed to
dissipate the negative charge that builds up
during sprayer use.
VP300ES
SPRAYER START UP
Nozzle Settings
Change
setting
Always
use nozzle
wrench when To insert or
changing nozzle
Turn one-quarter turn
counterclockwise to insert nozzle
Turn clockwise until you hear a
click to change setting
Select particle size for your
chemical's dwell time* & application:
110 microns | 15 min
80 microns | 10 min
40 microns | 5 min
*Average dwell times may vary based on
humidity, temperature, spray speed
and distance.
victoryinnovations.com
remove
