- Page 1 HYDRO PISTOL GRIP Instruction Manual Wright Manufacturing 4600X Wedgewood Blvd Frederick, Md 21703 Velke PG serial 63577 and higher WARNING: READ THIS MANUAL BEFORE USING 01/2013...
- Page 2 Foreword Welcome to the progressive group of mowing professionals who use Wright mowers. We are focused on giving you advanced engineering and quality construction in each mower we build. This manual explains the features and promotes safer use of the mower. Please read it and follow the instructions carefully so you can have many years of productive mowing.
-
Page 3: Table Of Contents
Table of Contents PRE-DELIVERY SERVICE OF MOWER BY DEALER .................... 5 1 INTRODUCTION ..............................7 1.1 TECHNICAL DATA .............................. 7 1.2 GENERAL SAFETY RULES ..........................8 1.2.1 DO’S AND DON’TS ............................8 1.2.2 WARNINGS ..............................8 1.3 IMPORTANT INFORMATION ..........................9 1.4 OWNER/USER NOTICE ............................. - Page 4 6.10 SPINDLE AND DRIVE PULLEY SPLIT HUB R&R ..................28 6.11 HYDRAULIC MOTOR SUPPORT ADJUSTMENT ..................29 6.12 BLADE ADJUSTMENTS AND HEIGHT-OF-CUT ................... 29 6.13 FUEL EVAPORATION SYSTEM ........................30 6.14 TRANSPORTING ............................31 6.15 LOADING AND UNLOADING ......................... 31 6.16 CLEANING THE MOWER ..........................
-
Page 5: Pre-Delivery Service Of Mower By Dealer
Wright dealer should perform the Pre-Delivery Service of the mower . The Wright Velke Hydro PG is shipped completely assembled and has been adjusted and tested at the factory. However, due to the jostling of the shipping process and the delivery time lapse, the following items need to be repeated again before starting the mower. - Page 6 Turn on the blade clutch switch. Run blades for approximately one minute. Next, engage and disengage the blades a few times about 10 seconds apart. If the blades do not start and stop in a few seconds each time, service the blade brake system. With the blades on, disengage the OPC switch to test the Operator Presence Control switch (OPC).
-
Page 7: Introduction
1 Introduction This mower is built to the highest standards in the industry. However, carelessness or operator error may result in serious bodily injury or death. Accident and hazard prevention are dependent upon the awareness, concern, wisdom, and proper training of the personnel involve in the operation, transport, maintenance, and storage of the equipment. -
Page 8: General Safety Rules
1.2 General Safety Rules The Wright Velke Hydro Pistol Grip is designed with your safety in mind. It has the following safety systems with which should become familiar: • The warning decals on the mower including the parking brake and general warning decal. -
Page 9: Important Information
1.3 Important Information It is vital that these instructions are available to machine user. It is also important to retain with the machine if the machine is sold or transferred to another user. 1.4 Owner/User Notice WARNING The owner’s/user’s obligation is to instruct themselves and all potential users in the safe operation of this equipment and be sure they read and follow the instructions in this safety manual and other material provided by Wright Manufacturing, Inc. -
Page 10: Regular Mower Safety
hand-operated hydraulic control system are tight and secure. This is to reduce the possibility that the mower could have a loss of control during operation and compromise operator safety. 1.9 Regular Mower Safety WARNING Keep your Wright mower in good operating condition, and keep safety devices and shields in place and in working condition. -
Page 11: Initial Operating Safety Guidelines
1.12 Initial Operating Safety Guidelines WARNING • Read and understand the warnings on the general warning decal on the mower. • Regularly check and test the safety devices for correct function. • Recommended PPE is safety shoes, safety glasses and ear protection. •... -
Page 12: Operation In Forward Direction
1.14 Operation in Forward Direction WARNING Operate the mower slowly until you become familiar with how the mower operates. Do not operate the mower faster than conditions allow. For example, hills, wet or bumpy ground, dim light or high grass are all conditions requiring slower speeds. -
Page 13: Fuel Safety
When pointing down a slope, the mower has the least weight on the drive wheels and therefore the least traction at the tires. This is the angle that the mower has the most tendency to slide. However, this is the angle that it has the least tendency to tip back. Avoid this angle, as it has the least advantage for the mower. -
Page 14: Using A Spark Arrester
1.21 Using a Spark Arrester The engine in this machine is not equipped with a spark arrester muffler. It is in violation of California Public Resources Code Section 4442 to use or operate the engine on or near any forest-covered, brush- covered, or grass covered land unless the exhaust system is equipped with a spark arrester meeting any applicable local or state laws. -
Page 15: Warning, Safety And Instructional Decals
2 Warning, Safety and Instructional Decals • Specific safety warning decals are located on the equipment near immediate areas of potential hazards. • Keep all safety signs legible. Remove all grease, dirt and debris from safety signs and instructional decals. •... -
Page 16: Specifications
3 Specifications Engine • See your engine owner’s manual • RPM: Full speed 3600 +/- 50 RPM (no load) / Idle 1550 RPM Electrical System (Electric Start) • Charging System: Internal stator coil • Battery Type: Maintenance Free • Battery Voltage: 12 Volts •... - Page 17 Fuel System • Capacity: 5.6 gal. (21.2 L) • Type of Fuel: Unleaded regular gasoline, minimum 85 octane. Do not use gasoline containing more than 10% ethanol. Do not mix oil with gasoline. • Fuel Filter: In line • Fuel shut-off: On, Off located on tank Safety Interlock System •...
-
Page 18: Machine Description & Overview
4 Machine Description & Overview The Wright Velke Hydro Pistol Grip is meant to solely cut, bag or mulch grass. The use for any other purpose is not recommended. Do not disconnect any safety switches or remove any decals. 1. Flexible Chute Deflector 2. -
Page 19: Operator's Area
4.1 Operator’s Area 1. Steering / Brake Lever 2. Neutral Latch Lock 3. OPC Paddle 4. Velke Sulky Release 5. Speed Control Knob 6. Control Linkage 7. Velke Sulky Mounting Point 4.2 Model & Serial Location 1. The plate is affixed to the right side of the engine deck in between the battery stand legs. 2. -
Page 20: Control Panel & Steering Control Levers
4.3 Control Panel & Steering Control Levers The Velke Hydro Pistol Grip speed and direction are controlled by releasing and squeezing the steering brake levers. The OPC paddles must be held down while releasing both neutral latches. Slowly release the levers to travel forward. Use the Speed Control knob to adjust max speed. -
Page 21: Safety Interlock System
4.6 Safety Interlock System The Wright Velke Hydro Pistol Grip is equipped with a safety interlock system. The PTO must be disengaged, speed adjustment lever in the “Slow” position, neutral latches in the “Locked” position and the parking brake engaged in order to start the machine. -
Page 22: Operating Instruction
5 Operating Instructions If you are not completely familiar with the Safety Instruction Manual, read it now before proceeding with the operation of the mower. REMEMBER WARNING THERE ARE CERTAIN PRECAUTIONS LISTED IN THIS MANUAL THAT YOU MUST NOW TAKE BEFORE STARTING THE MOWER 5.1 Inspect Mower Before Each Use Do not use the mower if any parts are not maintained in good operating condition. -
Page 23: How To Stop And Park The Mower
5.3 How to Stop and Park the Mower WARNING Come to a complete stop. Make sure the steering brake levers are in the neutral position with the neutral latches engaged with the levers. If the blades are on, turn them off using the switch on the instrument panel. -
Page 24: How To Perform The Neutral Adjust And Tracking Adjustments
5.7 How to Perform the Neutral and Tracking Adjustment WARNING • Find a secure location away from bystanders to perform the drive adjustments (preferably face the mower towards a wall). • Raise the drive wheels off the ground and stabilize the mower. •... -
Page 25: Service And Adjustments
Located under the dash Located Between the Hydro Pumps OPC for Paddles OPC for Brake PN 92410005, Switch, VK, NO/NC Grey Left=PN 52410006, Switch, VK, NO/NO, Blk & Gry Right=PN 92410005, Switch, VK, NO/NC Grey 6 Service and Adjustments WARNING 6.1 Tire Maintenance and Pressure Excessively worn tire tread is dangerous on all hills. -
Page 26: Replacing The Cutter Deck Belts
6.2.2 Replacing the Cutter Deck Belts • Stop the engine, remove the key and wait for all moving parts to stop. • Lower deck to the lowest setting. • Remove the deck covers. • Remove the belt by using a ½” ratchet and extension to relieve the belt tension. •... -
Page 27: Bleeding Air From The Hydaulic System
6.5 Bleeding Air from the Hydraulic System If air is entrained in the system, loss of power, excessive heat, and damage to the hydraulic pumps may occur. First, make sure the oil level in the reservoir is correct. Use fully synthetic oil: Mobil1 15W-50. Lift the mower so that the rear wheels are off the ground. -
Page 28: Cutting Blades
6.9 Cutting Blades In order to maintain the best cut, it is important that the blades are well sharpened and not damaged. Bent or cracked blades or blades with large nicks need to be replaced. Blades must be balanced after sharpening. -
Page 29: Hydraulic Motor Support Adjustment
6.11 Hydraulic Motor Support Adjustment The various holes in the mower frame and the hydraulic motor supports may be used to make a fine forward/rearward adjustment to the balance of the all Velke Mowers except the 32” (the 32” only moved up and down). -
Page 30: Fuel Evaporation System
•Temporary Height-of-Cut Adjustment: Using the caster shims (or spacers) you can adjust the blades downward temporarily .5” or 1” below the original coarse setting as described above. This assumes that the blades are level with two shims (or spacers) on the bottom and one shim on the top of the caster support arm. -
Page 31: Transporting
6.14 Transporting Use a heavy duty trailer or truck when transporting the Velke Hydro PG. Lock brake and block wheels. Securely fasten the unit to the trailer or truck with straps, chains, cable or ropes. 6.15 Loading and Unloading Use extreme caution when loading and unloading units on/off trailers or trucks. One full width ramp that extends beyond the rear tires is recommended rather than individual ramps for each side of the unit. -
Page 32: Componant Breakdown
7 Component Breakdown... -
Page 33: Electrical Schematic, Electric Start
8 Electrical Schematic (Electric Start) -
Page 34: Electrical Schematic, Recoil Start
9 Electrical Schematic (Recoil Start) -
Page 35: Maintenance Interval Chart
10 Maintenance Chart Maintenance Interval Chart MAINTENANCE ITEM Inspect for cracks in frame, cutter deck or other steel parts Inspect all belts for wear, adjustment and alignment Check all bolts and nuts for tightness (tighten as necessary) Lubricate hand control lever pivot shafts with waterproof grease Check hydraulic oil reservoir level and fill as needed - Use SYNTHETIC oil - Mobil1 15W-50 Grease caster wheel bearings... -
Page 36: Maintenance Record
Maintenance Record Unit Date Maintenance/Service Performed Shop/Technician Hours... -
Page 37: Wright Manufacturing Power Equipment Limited Warranty
WRIGHT MANUFACTURING, INC. POWER EQUIPMENT LIMITED WARRANTY THIS WARRANTY SUPERSEDES ALL PREVIOUS ON UNITS WITH A RETAIL SALES DATE ON OR AFTER 04/01/05 Wright Manufacturing, Inc. (hereinafter: WMI) warrants to the original The WMI mower, including any defective part, must be returned to an owner that the new WMI mower accompanying this document will be Authorized WMI Service Dealer within the warranty period. -
Page 38: Federal And California Emmision Control Warranty Statement
FEDERAL AND CALIFORNIA EMISSION CONTROL WARRANTY STATEMENT YOUR WARRANTY RIGHTS AND OBLIGATIONS The United States Environmental Protection Agency (EPA), California Air Resources Board (CARB) and Wright Manufacturing, Inc. (WMI) are pleased to explain the evaporative emission control system (EECS) warranty on your 2013 - 2014 commercial mower. In the United States, new equipment that use small off-road engines must be designed, built and equipped to meet the Federal’s stringent evaporative emissions standards. - Page 39 (2) Any warranted part that is scheduled only for regular inspection in the written instructions supplied is warranted for the warranty period stated above. Any such part repaired or replaced under warranty will be warranted for the remaining warranty period. (3) Any warranted part that is scheduled for replacement as required maintenance in the written instructions supplied is warranted for the period of time before the first scheduled replacement date for that part.
-
Page 40: Cut Quality And Mowing Tips
Cut Quality and Mowing Tips Problem Description Possible Cause Solution Streaking is when strips of uncut grass are left behind. Blades are not sharp Sharpen blades Blades are worn down too far Replace blades Streaking Engine RPM is too low Mow at full throttle GROUND SPEED IS TOO FAST SLOW DOWN... - Page 41 NOTES:...
- Page 42 NOTES:...
- Page 44 4600X Wedgewood Blvd Frederick, MD 21703 www.wrightmfg.com...
