Page 1: Table Of Contents
Welcome Product introduction Features Contact us Legal statements IPS Group Confidential and Proprietary Trademarks FCC statements FCC Interference Statement (Part 15.105 (b)) FCC Part 15 Clause 15.21 [ Do not Modify warning]: FCC Part 15.19(a) [interference compliance statement], unless the following statement is already provided on the device label: 11... - Page 2 Paid Fault Cards only Coins only Out of order Prepay No payment accepted SSPM Diagnostics Mode Diagnostics modes levels Level 1 Level 2 Level 3 Sub-menus Faults Coin Test Card Test Comms Test Fault Logging Meter Swap Voltages...
- Page 3 Understanding M5™ Battery Voltages Process flow References and Specifications M5™ Features, Functions, and Parts M5™ parts with NFC M5™ functions M5™ circuit boards and internal electronics M5™ top covers Model 795 Model 132 / Model 147 Access Cards Meter Diagnostics card...
- Page 4 SSPM Card Slot SSPM Coin Slot SSPM Diagnostics Button SSPM Display SSPM Keypad Primary functions Secondary functions Tertiary functions SSPM LEDs No Parking / After Hours Idle / Expired Paid Out of Order SSPM Payment Method Decal SSPM Solar Panel SSPM Validator SSPM Error and Fault Codes Error messages...
- Page 5 Turning the SSPM Off SSPM Coin Operation SSPM Card Operation How To's How To Clear an SSPM Coin Jam How To Replace an SSPM Coin Slot How To Clear an SSPM Card Jam How To Check the M5™ Battery Voltage Checking battery voltages...
- Page 6 How To Charge the M5™ Main Battery How To Replace an SSMP Backup Battery How To Force an SSPM to Update Glossary Index IPS Group, Inc. M5™ - User Guide 100-014 M5™ 132 M5™ 147 M5™ 795...
-
Page 7: Welcome
Product introduction The IPS Group, Inc. SSPM is a revolutionary product designed to enhance a city’s current single space parking system by providing addi- tional payment options (such as credit card), access to real-time data (via web-based management system), without disruption of current parking meter operations. -
Page 8: Contact Us
This makes their implementation and use, both intuitive and hassle-free. Contact us IPS welcomes customer feedback as part of the evolution of this product, so if you have any questions or concerns, please contact IPS Group, Inc. at: (858) 404-0607 support@ipsgroupinc.com... -
Page 9: Trademarks
IPS, IPS GROUP, IPS Group, Inc., and other IPS-owned marks are trademarks and / or registered trademarks of IPS Group, Incorporated in the United States, and may be registered in other countries. IPS reserves all rights to the IPS copyright materials contained herein. -
Page 10: Fcc Interference Statement (Part 15.105 (B))
FCC Interference Statement (Part 15.105 (b)) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment gen- erates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. - Page 11 Changes or modifications not expressly approved by IPS Group, Inc. could void the user’s authority to operate the equipment. If this equip- ment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna.
-
Page 12: General Information And Concepts
General Information and Concepts The chapters listed below provide high-level and general information for the IPS Group, Inc SSPM. SSPM Operating States SSPM Diagnostics Mode Understanding M5™ Battery Voltages SSPM Operating States This concept topic discusses the five IPS Group, Inc. SSPM operating states. - Page 13 1. Insertion of credit card payment method. 2. Pressing the keypad buttons. When environments have minimal ambient light (evening hours, indoors, garages, shaded areas, etc.), if the meter is "woken up", the back- light illuminates to help the motorist view the LCD. The SSPM indicates an expired state (payment is required) by flashing red LEDs.
-
Page 14: Paid
Paid A paid SSPM LCD alternates between the present parking rate and time limit information (default screen), and the remaining time (in the HH:MM format) and the expiration time. (Optionally the SSPM can be configured through the DMS to display negative time duration (or "grace" time) once the meter expires.) -
Page 15: Fault
Fault An SSPM can experience three types of fault operational states. 1. Cards Only 2. Coins Only 3. Out of Order The LCD alternates between the present parking rate and time limit information (default screen), and the type of fault, accordingly. Cards only If the SSPM detects a coin jam, it experiences a "Cards Only"... -
Page 16: Coins Only
Coins only If the SSPM detects a card jam, it experiences a "Coin Only" fault. While in this state the SSPM only accepts coin payments, and does NOT accept card payments. The following shows the alternating LCD messages. -
Page 17: Out Of Order
Out of order If the SSPM detects a coin jam and a card jam (i.e. both payment options are unavailable), it experiences an "Out of Order" fault. While in this state the SSPM does NOT accept coin or card payments. The following shows the alternating LCD messages. -
Page 18: Prepay
Prepay A SSPM can be configured (through the DMS) to accept payment before the start of an enforcement period, by creating a "prepay" period. A prepay periods occur within a "free parking" period, and ends when the "pay period" begins (i.e. when enforcement starts). When an SSPM receives currency while in a prepay period, the LCD shows the amount of time purchased in addition to the amount of free parking time remaining (i.e., until the pay period / enforcement starts). -
Page 19: Sspm Diagnostics Mode
SSPM Diagnostics Mode This concept topic discusses the IPS Group, Inc. SSPM Diagnostics mode. The SSPM’s Diagnostic mode is used to determine meter issues and prevent potential problems. Diagnostics modes levels The SSPM offers three levels of Diagnostics mode. Level 1 contains the least amount of sub-menus; while Level 3 offers the highest amount of sub-menus. - Page 20 Level 2 Level 2 Diagnostics mode is signified by a blank hash mark in the upper-right hand corner of the Diagnostics mode main screen. (See the red circle in the following figure.) To enter Diagnostics mode (level 2) on the SSPM, quickly insert and remove a Diagnostics card from the EMV card reader, and press √...
-
Page 21: Level 3
Level 3 Level 3 Diagnostics mode is signified by two blank hash marks in the upper-right hand corner of the Diagnostics mode main screen. (See the two red circles in the following figure.) To enter Diagnostics mode (level 3) on the SSPM, quickly insert and remove a Diagnostics card from the EMV card reader, and press √... -
Page 22: Sub-Menus
Faults The Faults sub-menu shows any errors reported by the meter. When a fault / error occurs, the SSPM reports it to the IPS maintenance staff (through the DMS), as an email or SMS. The report conveys the type of fault, the time it occurred, and the location of the individual SSPM. -
Page 23: Coin Test
Card Test The Card Test sub-menu allows IPS maintenance staff to verify the card reader is operating properly. During a card test, quickly insert and remove a valid credit card. The LCD shows the card type, card number, and expiration date. If this information is not displayed, the card... -
Page 24: Comms Test
Comms Test The Comms Test sub-menu allows IPS maintenance staff to test the SSPM's ability to communicate, by forcing it to “call-in” to the DMS. This test verifies that the SSPM can successfully communicate with the DMS, and updates the internal clock and available firmware / con- figurations. -
Page 25: Fault Logging
Fault Logging The Fault Logging sub-menu allows IPS maintenance staff to research all faults that are logged on a meter. Scroll through the log to view each fault, and clear them each log event This log is transmitted wirelessly to the DMS, eliminating the need for pole-site fault log collection. -
Page 26: Meter Swap
Meter Swap The Meter Swap sub-menu must be used when removing a SSPM mechanism from a pole site, and replacing it with a different mech- anism. After the new mechanism is installed, enter Diagnostics mode and scroll to Meter Swap. Press √ OK to Continue, then press — Time (less time) to confirm. -
Page 27: Voltages
Voltages The Voltages sub-menu shows the real-time power in milli-volts (mV) provided by the meter's solar panel, "Main" (rechargeable) battery , and "Backup" (non-rechargeable) battery, simultaneously. The Main battery (a lithium polymer or cylindrical lithium-ion), is permanently mounted directly on the SSPM Main PCBA. The Backup bat- tery (a lithium-thionyl chloride (Li-SOCI2)), is a temporary battery housed and connected at the left side of the SSPM. - Page 28 OFF. If an SSPM must be "bagged" (out-of-service) for ≥ 48 hours, IPS recommends pla- cing it into Sleep mode. If an SSPM must be bagged or stored for 1 month, IPS recommends turning the meter OFF (by disconnecting the jumper (JMP0002) at JMP6 header), and / or the Back-up battery.
- Page 29 This information is intended for internal use by IPS personnel, or a customer’s authorized field technicians. The M5™ SSPM uses two different batteries: Rechargeable Main Battery Non-rechargeable Backup Battery (Large external battery) Process flow The following figure summarizes the process flow.
- Page 31 Related Topics Click here to view the task topic How To Check the M5™ Battery Voltage. Click here to view the task topic How To Charge the M5™ Main Battery.
