This manual contains important safety instructions for the gasoline engine powered
READ SAFETY WARNINGS AND OPERATING INSTRUCTIONS CAREFULLY.
DO NOT RETURN THIS SNOW BLOWER TO THE
When you call the help-line you will need to have the following information:
Date of Purchase:
Location of Purchase:
Serial # - Snow Blower:
*Serial number is located on engine block below the starter.
Snow Blower
Owner's Manual
snow blower models: 30SB, 36SB, 45SB
SAVE THIS MANUAL.
Need Help?
Parts, Service, and Technical Assistance call:
1-800-393-0668
Monday-Friday 8:00AM-5PM EST
_______________________
_______________________
_______________________
by
STORE!
Snow blower and engine life are
extended greatly by performing
frequent lubrications, oil changes
and regular maintenance. To
protect your investment perform
routine maintenance.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Snow BEAST 30SB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DEK Snow BEAST 30SB

Summary of Contents for DEK Snow BEAST 30SB

  • Page 1 Snow Blower Owner’s Manual This manual contains important safety instructions for the gasoline engine powered snow blower models: 30SB, 36SB, 45SB READ SAFETY WARNINGS AND OPERATING INSTRUCTIONS CAREFULLY. SAVE THIS MANUAL. Need Help? Parts, Service, and Technical Assistance call: 1-800-393-0668 Monday-Friday 8:00AM-5PM EST DO NOT RETURN THIS SNOW BLOWER TO THE STORE!
  • Page 2 No part of this publication can be reproduced or distributed without prior written permission of GXi Outdoor Power, LLC Clayton, NC 27520 USA. DEK is a registered trademark of GXi Outdoor Power, LLC GXi Outdoor Power, LLC reserves the right to discontinue or change specifications or design at any time without notice and without incurring any obligation whatsoever.
  • Page 3 BEAST SERIES Check out our other great products at www.HomeDepot.com or visit our web site at www.beastpowerequipment.com Z-Beast Turf Beast 36” & 54” Walk Behind 54” & 62” Zero-Turn Finish Mower Riding Mower Snow Beast Brush Beast 36” & 45” Snow Blower 36”...

  • Page 4: Table Of Contents

    Snow BEAST 30SB, 36SB, 45SB Contents Safety Information and Warnings ............... 1 Preparation Safety Precautions ..............2 Operation Safety Precautions ..............3 Safety Decals ....................5 Product Specifications ................. 6 Control Panel and Snow Blower Components ..........7 Missing Parts Request Form ................ 8 Assembly Instructions .................

  • Page 5: Safety Information And Warnings

    Snow BEAST Safety Information and Warnings 30SB, 36SB, 45SB Safety Information Training Emission Control System Information 1. Read, understand, and follow all instructions on The U.S. and California Clean Air Acts the machine and manual(s) before attempting to EPA and California regulations require all assemble and operate.

  • Page 6: Preparation Safety Precautions

    Snow BEAST Preparation Safety Precautions 30SB, 36SB, 45SB Preparation—Safety Precautions safety signs. 1. Inspect the area where the equipment is to be 9. Be sure to inspect snow blower before each used and remove all objects such as rocks, use. mats, and wire which can be thrown by the 10.

  • Page 7: Operation Safety Precautions

    Snow BEAST Operation Safety Precautions 30SB, 36SB, 45SB 14. Keep hands and feet away from augers/ Equipment Operation—Safety Precautions impeller . This product is capable of 1. Do not operate the engine in a confined space amputating hands and feet. where dangerous carbon monoxide fumes can 15.
  • Page 8 Snow BEAST Operation Safety Precautions 30SB, 36SB, 45SB Clearing A Clogged Chute—Safety Precautions 1. SHUT THE ENGINE OFF! GASOLINE IS HIGHLY FLAMMABLE AND 2. Wait at least 10 seconds to be sure the augers EXPLOSIVE. FUEL LEAKS, A LOOSE FUEL TANK, have stopped rotating.
  • Page 9 Snow BEAST Safety Decals 30SB, 36SB, 45SB Safety Decal Identification The labels shown below are located on your snow blower to warn you of potential hazards and provide you with important safety information. If these decals become difficult to read or are missing from the snow blower, please contact GXi Parts &...

  • Page 10: Product Specifications

    Snow BEAST Product Specifications 30SB, 36SB, 45SB Models Feature 30SB 36SB 45SB Product Type Snow blower Snow blower Snow blower Clearing Path 30” 36” 45” Engine 302cc 420cc 420cc Torque 15.9 ft.lbs 20.7 ft.lbs 20.7 ft.lbs Engine Start 120V Electric Start and recoil 120V Electric Start and Recoil 120V Electric Start and Recoil Speed Control...

  • Page 11: Control Panel And Snow Blower Components

    Snow BEAST 30SB, 36SB, 45SB Control Panel and Snow Blower Components Throughout this manual, instructions are given on the operation of your SNOW BEAST snow blower. We recommend that while going through this manual, you have your snow blower available for quick and easy access in order to orient yourself with the controls, maintenance and orientation of different parts.

  • Page 12: Missing Parts Request Form

    Snow BEAST Missing Parts Request Form 30SB, 36SB, 45SB Please indicate the part that you are Name Hardware bag Other Address Date of purchase Model #: Phone Email Serial Comments: IMPORTANT: Please include your receipt. Without a receipt, your order will be delayed. You may also email us at: customerservice@gxioutdoorpower.com Fax:1-919-550-3277 If emailing, please scan in your proof of purchase.

  • Page 13: Assembly Instructions

    Snow BEAST Assembly Instructions 30SB, 36SB, 45SB Step 1: Control Panel Handles 1. Align the two holes on each side of the control panel handles over the lower handle frame. 2. Insert the bolts through the handlebar holes and frame holes.
  • Page 14 Snow BEAST 30SB, 36SB, 45SB Step 4: Chute Direction Control Cable Support 1. Attach the chute direction control cable hook to the engine cover as shown. Place the chute direction control cable into the support hook, and secure with the zip-ties provided in the hardware bag.
  • Page 15 Snow BEAST Assembly Instructions 30SB, 36SB, 45SB Step 7: Drive Control 1. Locate the thin cable on the right side (standing from the operator position) of the snow blower. 2. Attach the cable to the threaded end under the drive control handle. The cable extension may need to be attached to the bottom of the handle.
  • Page 16 Snow BEAST Assembly Instructions 30SB, 36SB, 45SB Step 9: Drift Cutters (if desired) 1. The drift cutters are attached to the main hous- ing in the stored position. 2. Remove the two bolts on each drift cutter. 3. Reattach the drift cutters in the operating posi- tion.

  • Page 17: Starting The Engine

    Snow BEAST Starting the Engine 30SB, 36SB, 45SB WARNING DANGER WARNING! The electric starter is designed to operate on 120 volt AC household current. Use only a UL-listed, 16 gauge extension cord for outdoor use that is Before attempting to use your snow blower, make sure you no longer than 50 feet (15 meters).

  • Page 18: Operating Instructions

    Snow BEAST Operating Instructions 30SB, 36SB, 45SB Engage Transmission Drive Transmission Control Your snow blower is equipped with an easily To engage the transmission drive squeeze the right lever to adjustable transmission control, which can be the hand grip. adjusted for forward and reverse speed. To disengage, let go of the right lever.
  • Page 19 Snow BEAST Operating Instructions 30SB, 36SB, 45SB Chute Direction Control Headlights To rotate the chute to the right rotate the chute con- To turn on the lights, flip the switch up. trol clockwise. To turn off the lights, flip the switch down. To rotate the chute to the left rotate the chute control counter-clockwise.
  • Page 20 Snow BEAST Operating Instructions 30SB, 36SB, 45SB Using your Snow Beast. The following tips will help ensure proper and long lasting use of your BEAST snow blower. ALWAYS wear prop- er safety equipment when operating the snow-blower, and make sure you dress appropriately for cold weath- Figure 1 Figure 1 Impeller...

  • Page 21: General Maintenance

    Snow BEAST General Maintenance 30SB, 36SB, 45SB The Importance of Maintenance CAUTION Regular maintenance is essential to ensure your snow blower continues to deliver safe and high-quality performance. CAUTION! Before making any adjustments and/or To help you properly care for your snow blower, the servicing to your SNOW BEAST, make sure the snow following pages include a recommended maintenance blower is on a level surface, with the ignition switch...

  • Page 22: Maintenance Schedule

    Snow BEAST Maintenance Schedule 30SB, 36SB, 45SB Time Interval Break-in Every 8 hrs Every 40 hrs Every 100 Every 200 (first 5 hrs) (daily) (weekly) Item Procedure (Bi-weekly) (monthly) Inspect Tension Belts (adjust if needed) Augers/Impeller Inspect Engine Air Filter Inspect Check Engine Oil...

  • Page 23: Service Adjustments

    Snow BEAST Service Adjustments 30SB, 36SB, 45SB Adjusting Augers/Impeller Cable Adjusting Drive Cable If tension seems to be too loose or too tight the If tension seems to be too loose or too tight the augers/impeller cables needs to be readjusted. drive cables needs to be readjusted.
  • Page 24 Snow BEAST Service Adjustments 30SB, 36SB, 45SB Check & Replacing the Transmission Drive Belt If belt needs to be changed or altered for any reason, the belt is located in the front of the snow blower behind the discharge chute and in front of the wheels.

  • Page 25: Adjusting Discharge Chute Deflector

    Snow BEAST Service Adjustments 30SB, 36SB, 45SB Adjusting Discharge Deflector The discharge chute is preset at the factory, but may require adjustment over time or during maintenance. For adjustments, follow the procedure below: 1. Loosen the two nuts at the chute cable mount on the discharge chute.

  • Page 26: Storage Instructions

    Snow BEAST Storage Instructions 30SB, 36SB, 45SB Short Term Storage   Let engine cool before storing and do not store Do not drain fuel indoors or near a flame. near flame, high heat, and possible ignitions from  sparks. Always park machine on level ground.

  • Page 27: Troubleshooting

    Snow BEAST Troubleshooting 30SB, 36SB, 45SB Problem Possible Causes Solution Engine will not start 1. Key in the OFF position 1. Turn key to ON position 2. Insufficient fuel in the tank 2. Add gasoline 3. Air bubble in the fuel line 3.
  • Page 28 Snow BEAST Troubleshooting 30SB, 36SB, 45SB Problem Possible Causes Solution Snow blower will not 1. Transmission cable out of 1. Readjust transmission cable move forward or reverse adjustment (too loose) or If damaged, replace and readjust. damaged. Cannot move snow 1.
  • Page 29 Snow BEAST 30SB, 36SB, 45SB Collector Housing Assembly Reference Item # GXi Part# Description B00510 Discharge Chute Assembly—Orange B00710 Discharge Chute Deflector—Orange B00910 Drift Cutters—Orange (Set of 2) B01410 Auger/Impeller Gearbox B01510 Discharge Chute Rotation Bushing with Clamps B02410 Snow Cleanout Tool with Bracket and Hardware B03711 Discharge Chute Direction Gear (Spiral Gear) with Bracket B04811...
  • Page 30 Snow BEAST 30SB, 36SB, 45SB Chassis Assembly Reference GXi Part GXi Part Item # Description Item # Description Number Number Snow blower Wheel and Tire Assembly. Includes lynch pin. Models: 30SB, 30SS, B00110 Control Handle Inter Lock Linkage. Includes rod, tab, 2 springs, and end 36SB, 36SS, 45SB, 45SS B04411 connections.

  • Page 31: Replacement Parts

    Snow BEAST Replacement Parts 30SB, 36SB, 45SB To order replacement parts, visit our web-site at www.serviceandwarrantyonline.com Or dial Toll Free 1-800-393-0668 Monday-Friday 8AM-5PM OEM Replacement Parts Engine Parts GXi Part Number Description Fuel Primer Bulb Kit: Includes primer bulb assembly, fuel line, and 2 clamps. Models: 30SB, E10211 30SS, 36SB, 36SS, 45SB, 45SS Fuel Tank with gas cap, fuel valve, fuel line, and clamps for 420cc Snow Blower Engine.
  • Page 32 Snow BEAST Replacement Parts 30SB, 36SB, 45SB Snow BEAST Additional Parts Listing GXi Part Number Description Hardware Bag and Owner's Manual - SNOW BEAST (Includes owner's manual, 3 wrenches, B00210 spark plug removal tool, 10 shear pins) Models: 30SS, 36SS, 45SS Spring Kit (Includes all drive system springs, clutch return springs, etc) Models: 30SB, 30SS, B05511 36SB, 36SS, 45SB, 45SS...

  • Page 33: Limited Warranty And Service

    Snow BEAST Limited Warranty & Service 30SB, 36SB, 45SB Length of Warranty: *(from the date of original retail purchase) Noncommercial/ Commercial Rental Products Covered by this Warranty Nonrental Engine 24 months 90 days 90 days Transmission 12 months 90 days 90 days Snow blower 12 months...
