- Page 1 ® ® < > < > GPS MOBILE LOCATOR USER’S MANUAL...
-
Page 2: Table Of Contents
Contents Introduction........................3 Applications ........................3 Package Contents ......................4 Pin Assignment ......................4 Getting Started ......................5 Operating Procedure ....................6 Specifications ........................7 Limited Warranty ......................9... -
Page 3: Introduction
Personal Computer and map software to display your real time location on the monitor. The GM-33-232 is an all-weather rugged design product for all applications. Before you get started with your GM-33-232 ®, make sure to read the PC hardware requirements to run the Mapping software. Applications... -
Page 4: Package Contents
After opening your package, make sure that the following items are not missing or damaged. GM-33-232 ® Mobile Locator User’s Manual and Driver’s CD If above items are missing or damaged, contact ETEK Navigation immediately at Tel: 886-2-26860199 Fax: 886-2-26866159 Pin Assignment... -
Page 5: Getting Started
The magnetic part should face downward and attach on either the metallic or non–metallic surface. It is the best if the GM-33-232 unit is placed in an open space and allows it to see the clear sky at least for the first fix. -
Page 6: Operating Procedure
Operating Procedure Caution DO NOT TRY TO DO STEPS, WHILE VEHICLE IS IN MOTION. AND KEEP YOUR EYES ON THE ROAD Step 1: Please wait till the Operation System to finish loading and then plug in the GM-33 GPS Locator. Step 2: The Operation System will identify the device automatically. -
Page 7: Specifications
Specifications PHYSICAL Dimension 53mm( L) × 44mm (W) × 16mm( H) Weight 214 gram (With Cable) High impact, corrosion-proof Enclosure PC (polycarbonate) resin Construction Ultrasonic welded, fully waterproof Mounting Magnetic mount ENVIRONMENTAL Operating: 0 ~ +70 degree C Temperature Storage: -20 ~ +85 degree C Humidity 95% non-condensing COMMUNICATION... - Page 8 Check Installation & If the DB-9 connecter connects to PC 4. If your PC recognizes GM-33-232 as a mouse Please remove the GM-33-232 from the COM Port of your PC or device and plug it back. If it still happens, please restart your PC.
-
Page 9: Limited Warranty
Limited Warranty ® ® ’ ’...
