Omega National NPT8730K Quick Start Manual

Single easy access corner pantry

Easy Access

Corner Pantry

4ea.: #8 X 1" Flat Head Wood Screw

Cabinet Bottom (Not Included)

Meets BHMA Class 1 Speciﬁcations

Patents Pending

•Always read instructions completely and carefully before beginning assembly.

•Remove and check contents for concealed damage and or missing parts.

•Keep the original carton and packing material, which are required for all returns.

Step 1: Using the paper template provided align it with the face frame

of the corner cabinet and drill 2 holes 1/16" in diameter at the

marked locations. The template will set the Easy Access Cor-

ner Pantry 1/4" back from the inside of the face frame. Each

cabinet varies so check the ﬁt of the unit inside the cabinet

before drilling any holes.

Drawer

Important Notes

4ea.: 1/4-20 Flat Head

Machine Screw

Aluminum Bearing

Plastic Detent

Form OME-093, 03/2014
