PNUT REMOTE CONTROL SYSTEM
The PNUT remote control system contains the
following items:
H212 handheld
C220 controller
Antenna
Charging cradle
Wiring harness
POWERING ON THE HANDHELD
The H212 requires a special sequence to turn on.
This sequence is used to verify that all the buttons are
working correctly prior to start up. It also minimizes
any accidental powering up of the handheld.
To power up the H212:
1. Press and hold the
red
button.
2. Press and hold the
green
button.
3. Release the
red
button.
green
4. Release the
button.
2
4
1
3
Regular flashing
green
LED: System turned on but
no link.
Solid, or short flashes of
green
LED: System turned
on and linked.
MATCHING
First Method
1. Turn off the H212.
2. Apply power to the C220.
3. Momentarily ("blip") the power off to the C220
six to seven times (i.e. power off for 1/2 second,
power on for one second; six times). Leave the
power on after the sixth blip.
Model: C220
STATUS
4. The LED on the C220 will light up
5. Continue with steps five to eight below in second
method.
Second Method
1. Turn off the H212.
2. Apply power to the C220.
3. Using a smooth motion, wave the H212 back
and forth over the top left corner of the C220 so
that the two magnets under the
button pass over the surface of the Aarcomm
logo.
Or
Model: C220
STATUS
4. If the C220 successfully detects the magnets on
the H212, the C220 LED will light up
5. Press and hold the three round buttons on the
bottom left side of the H212.
6. Press and release the
7. The C220 LED will turn white and a message
will appear on the H212 indicating a successful
match. If not, make sure the H212 and the C220
have compatible part numbers.
8. Power on the H212 normally to verify that the
system is matched.
1 second
On
POWERING OFF THE HANDHELD
1/2 second
Pressing the
H212 handheld. The LCDs on the H212 will be put
into in sleep mode and will not draw any power from
the battery.
dark blue.
CHARGING THE BATTERY
The H212 is waterproof and completely sealed
to IP67 rating. For improved reliability, it does not
have a removable battery and is charged using the
wireless charging cradle. The magnets on the back
of the H212 are only used for alignment and not for
electrical contact.
red
green
and
red
The
LED will begin to flash when the H212 should
be charged. Place the H212 on the charging cradle to
begin charging. The LCD screen will show the charge
status; please allow a minute or two for the charge
level to be calculated accurately.
Model: C220
A battery that is completely discharged will take
approximately three hours to charge. The battery can
STATUS
be charged at anytime even if it is not depleted. A quick
30 minute charge will allow the handheld to operate
for eight hours. A full battery will last approximately 50
to 120 hours, depending on the performance setting.
dark blue.
red
button on the H212
red
E-stop button will shut down the
