- Page 2 Complete IDE Series: IDE100...
- Page 3 Before You Begin your Installation The product you have purchased is designed to be easily installed into most IBM PC or compatible systems. Many products have large, easy-to-read legends to allow for the easy configuring of the product. This installation manual contains detailed instructions.
- Page 4 If for some reason you are unable to return the product directly to its place of purchase, refer to the “Servicing Your Product” and “Warranty” sections in this manual for instructions. Complete IDE Series: IDE100...
- Page 5 Contents Section One: Introduction ........6 Section Two: Drive Addresses ....... 7 Section Three: Installation ........9 Appendix A: Servicing Your Boca Product ..11...
- Page 6 Before going any further, please examine the IDE100 for any visible damage which may have occurred during shipment. If damage exists or if any items appear to be missing, please contact the retailer from whom the IDE100 was purchased. Complete IDE Series: IDE100...
- Page 7 Section Two: Primary/Secondary Drive Addresses The primary and secondary addressing jumper block is labelled J4 and is used for both the hard drive interface (HDC) and floppy drive controller (FDC). Primary addresses are set as shown below. J4 would be configured as shown below if the IDE100 were the first or only hard and floppy drive controller in the system.
- Page 8 Secondary hard HDD/IRQ15 HDD-SEC drive with floppy HDD/IRQ14 HDD-PRI controller FDD/DIS HDD-DIS enabled. FDD/ENA HDD-ENA Secondary hard drive, but HDD/IRQ15 HDD-SEC HDD-PRI HDD/IRQ14 NO additional floppy support FDD/DIS HDD-DIS HDD-ENA FDD/ENA is needed. FDC is disabled Complete IDE Series: IDE100...
- Page 9 Section Three: Installation Follow the directions below to physically install the IDE100 in your system. 1. Power down the computer and remove the cover from the system. 2. Select an empty expansion slot and remove the retaining screw and dust cover. Firmly insert the IDE100 card, securing it with the retaining screw.
- Page 10 FDISK and FORMAT to prepare your hard disk drive for use. If you connected the IDE100 to an EXISTING hard drive, simply power up the system and the controller will automatically recognize the drive. Complete IDE Series: IDE100...
- Page 11 Appendix A: Servicing Your Boca Product If your IDE100 requires service, first contact the authorized IDE100 dealer from whom you purchased the board. If the dealer is unable to assist you, contact Boca Research, Inc. directly, and then please follow the instructions below.
- Page 12 Boca Research, Inc. RMA Department — RMA #___________ 1601 Clint Moore Road Boca Raton, FL 33487 6. If the repairs done on your board were covered by the warranty, Boca Research will return it prepaid via UPS ground. Complete IDE Series: IDE100...
- Page 13 Limited Warranty Boca Research, Inc. (BRI) warrants to the original buyer of this BRI product that the hardware is free of defects in materials and workmanship for a period of five (5) years from the date of purchase from BRI or an authorized dealer (“the Warranty Period”).
- Page 14 Trademarks All Boca Research products are trademarks of Boca Research, Inc. All other references to computer systems, software, and peripherals use trademarks owned by their respective manufacturers. Publication Date: August, 1995 Printed in the U.S.A. IDE100.PM5 Complete IDE Series: IDE100...
- Page 16 Manual Part # 9453 Rev. 2.0 Complete IDE Series: IDE100...
