Summary of Contents for ITT i-ALERT 2
- Page 1 Installation, Operation, and Maintenance Manual i-ALERT®2 Equipment Health Monitor...
-
Page 3: Table Of Contents
Table of Contents Table of Contents Introduction and Safety ......................2 Introduction ..........................2 Inspect the package ........................ 2 Limited warranty ........................2 Safety ............................3 Safety terminology and symbols ..................... 3 Safety regulations for Ex-approved products in potentially explosive atmosphere ....3 Product approval standards .................... -
Page 4: Introduction And Safety
Requesting other information For instructions, situations, or events that are not considered in this manual or in the sales documents, please contact your ITT representative. Always specify the exact product type and identification code when requesting technical information or spare parts. -
Page 5: Safety
Prohibited methods include any modification to the equipment or use of parts not provided by ITT. If there is any uncertainty regarding the appropriate use of the equipment, please contact an ITT representative before proceeding. -
Page 6: Product Approval Standards
Do not charge, short circuit, crush, dissemble, heat above 100°C (212°F), incinerate or expose contents to water. Personal requirements ITT disclaims all responsibility for work done by untrained and unauthorized personnel. These are the personnel requirements for Ex-approved products in potentially explosive atmospheres: •... - Page 7 Introduction and Safety Figure 1: North America USA and Canada Europe and Worldwide certifications Standards tested to: ATEX EN 60079-0:2012 EN 60079-11:2012 EN 60079-26:2007+COR1:2011 EN 50303:2000 IECEx IEC 60079-0:2011 IEC 60079-11:2011 IEC 60079-26:2006 ATEX & IECEx Markings I M1 Ex ia I Ma II 1G Ex ia IIB T4 Ga II 1D Ex ia IIIC Da T200°C Da Ambient Temperature: -40°C to +60°C | -40°F to +140°F...
- Page 8 The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by ITT may void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 9 Introduction and Safety Industry Canada Certification ® The radio module contained in the i-ALERT 2 device is licensed to meet the regulatory requirements of Industry Canada (IC), license: IC: 216Q-PAN17. IC Notice ® The radio module within the i-ALERT 2 device complies with Canada RSS-GEN Rules. The device meets the requirements for modular transmitter approval as detailed in RSS-GEN.
- Page 10 Introduction and Safety Taiwan radio regulatory statement Figure 5: Taiwan radio regulatory statement RoHS China RoHS Table Figure 6: China RoHS table i-ALERT®2 Equipment Health Monitor Installation, Operation, and Maintenance Manual...
-
Page 11: Product Description
Product Description Product Description ® General description i-ALERT 2 Condition Monitor Description ® The i-ALERT 2 Equipment Health Monitor is a compact, battery-operated monitoring device ® that continuously measures the vibration and temperature of the pump. The i-ALERT Equipment Health Monitor uses blinking red LED and wireless notification to alert the pump operator when the pump exceeds vibration and temperature limits. -
Page 12: Installation
Installation Installation Installation ® Attach the i-ALERT 2 Equipment Health Monitor to the pump CAUTION: ® Always wear protective gloves. The equipment and the i-ALERT 2 device can be hot. Mounting options Figure 7: Mounting options Mill a Slot Drill and Tap Epoxy Screw: ¼-28 x 1.125in Screw: ¼-28 x 1.5in... - Page 13 Installation Figure 8: Location selection ® The temperature seen by the i-ALERT 2 temperature sensor maybe different from the surface ® temperature of the object it is mounted to. Mounting the i-ALERT 2 directly to the machine will give the most accurate reading. The differences are due to the temperature gradient that exists ®...
- Page 14 Installation ® Figure 9: i-ALERT 2 registration i-ALERT®2 Equipment Health Monitor Installation, Operation, and Maintenance Manual...
-
Page 15: Commissioning, Startup, Operation, And Shutdown
Commissioning, Startup, Operation, and Shutdown Commissioning, Startup, Operation, and Shutdown ® Activate the i-ALERT 2 Equipment Health Monitor ® Figure 10: i-ALERT 2 Equipment Health Monitor activation ® Steps to activate the i-ALERT 2 Equipment Health Monitor 1. Remove the sticker. ®... -
Page 16: Reset The I-Alert ® 2 Equipment Health Monitor
Commissioning, Startup, Operation, and Shutdown ® Reset the i-ALERT 2 Equipment Health Monitor ® Figure 11: i-ALERT 2 Equipment Health Monitor reset ® The LEDs correspond to an i-ALERT 2 Equipment Health monitor function. ® When using the magnet over the BlueTooth icon you can change an i-ALERT 2 Equipment Health monitor function. -
Page 17: I-Alert ® 2 Equipment Health Monitor Routine Operation
Commissioning, Startup, Operation, and Shutdown ® i-ALERT 2 Equipment Health Monitor routine operation Measurement interval The measurement interval for the condition monitor during normal and alarm operation is 5 minutes. When the monitor measures a reading beyond the specified temperature and vibration limits, the appropriate red LED flashes (after 2 consecutive readings). -
Page 18: Maintenance
Maintenance Maintenance ® Guidelines for i-ALERT 2 Equipment Health Monitor disposal Precautions WARNING: • Never heat the condition monitor to temperatures in excess of 100°C | 212°F. Heating to these temperatures could result in death or serious injury. • Never dispose of the condition monitor in a fire. This could result in death or serious injury. Guidelines This Product Contains Lithium Thionyl Chloride therefore the local Waste management companies can provide assistance in the disposal of the device that contain this type of battery. -
Page 19: Troubleshooting
Consult your ITT representative for a warranty replacement. For connection issues with smart devices, please visit www.i-ALERT.com For ITT’s privacy Policy, click here: http://itt.com/privacy/ For User SW License Agreement, click here: http://www.ittproservices.com/AppPrivacyPolicy i-ALERT®2 Equipment Health Monitor Installation, Operation, and Maintenance Manual... - Page 20 Visit our website for the latest version of this document and more information: http://www.i-alert.com Form IOM.i-ALERT2.en-US.2016-11/KPA/0920...
