Safety Information
WARNING:Do not allow children to play with or arund the log rack.
Pre-Assembly
HARDWRE INCLUDED
AA
BB
EE
FF
PART LIST
Part
Description
AA
M8 x L65 mm bolt
BB
M8 x L35 mm bolt
CC
M8 x L45 mm bolt
DD
EE
FF
Assembly
1 ASSEMBLING THE MIDDLE LEG WITH HOLE
Attached Middle leg(KK) to middle leg with hole(LL) by inserting two M8xL65mm(AA) and M8 Nut(DD)
through the corresponding holes of the legs.Repeat this step for the other side of middle leg(KK),and then repeat
this step for another side of legs assembling.Attached connector(HH) to middle leg with hole(LL) by inserting two
M8xL45bolt(CC) and M8 nut(DD).Tighten securely with allen wrench(GG) and Wrench(FF).
USE AND CARE GUIDE
8FT. LOG RACK
PACKAGE CONTENTS
CC
DD
GG
HH
Quantity
M8 Nut
M8 Nut
Wrench
II
JJ
Part
16
GG
8
HH
2
II
18
JJ
8
KK
1
LL
Item#1000011856
Model#H177B-L
Service:1-877-527-0313
KK
Description
Allen Wrench
Connector
Upper Side Frame
Bottom Side Frame
Middle Leg
Middle Leg With Hole
LL
Quantity
1
1
2
2
4
2
