EX-A2X
I/O Expansion Module Adapter, Isolated
The EX-A2X interfaces between a variety
of I/O expansion modules and specific
Unitronics' OPLCs.
A single adapter can be connected to up
to 8 expansion modules.
The EX-A2X may either be snap-mounted
on a DIN rail, or screw-mounted onto a
mounting plate.
Component Identification
1 Status indicators
2 COM port, EX-A2X to OPLC
3 Power supply connection points
4 EX-A2X to expansion module
connection port
Before using this product, it is the responsibility of the user to read and understand this document and
any accompanying documentation.
All examples and diagrams shown herein are intended to aid understanding, and do not guarantee
operation. Unitronics accepts no responsibility for actual use of this product based on these examples.
Please dispose of this product in accordance with local and national standards and regulations.
Only qualified service personnel should open this device or carry out repairs.

User safety and equipment protection guidelines

This document is intended to aid trained and competent personnel in the installation of this equipment as
defined by the European directives for machinery, low voltage, and EMC. Only a technician or engineer trained
in the local and national electrical standards should perform tasks associated with the device's electrical wiring.
Symbols are used to highlight
information relating to the user's
personal safety and equipment
protection throughout this document.
When these symbols appear, the
associated information must be read
carefully and understood fully.
Failure to comply with appropriate safety guidelines can result in severe personal injury or
property damage. Always exercise proper caution when working with electrical equipment.
Unitronics
Symbol Meaning
Danger
Warning
Caution Caution
Description
The identified danger causes physical
and property damage.
The identified danger can cause
physical and property damage.
Use caution.
