- Page 1 SADT - 100EC Ceiling Mount Adaptor imagine the possibilities Thank you for purchasing this Samsung product. To receive more complete service, please register your product at www.samsung.com/global/register SADT-100EC_ENG.indd 1 2008-01-23 오후 4:14:36...
-
Page 2: Installation
Overview The ceiling mount adaptor (SADT-100EC) is used for the smart dome camera to be installed in a double ceiling of the concealed type. Notice • Select an installation spot which can endure more than 4 times of the product weight. - Page 3 . Install two anchor bolts (B1,B2) on the concrete ceiling. Insert the anchor bolt (B1) into the Ø219 hole. - Determine the length of the anchor bolt (B1) using the template B (accessory). - Apply a nut (N1) to the anchor bolt(B1) using template B (accessory) and determine the location.
- Page 4 4. Insert necessary wiring including the external power cable, video out cable and alarm I/O cable into the side hole of the adaptor. See the installation guide for the applicable camera, and arrange necessary cables for the installation in advance. 5.
- Page 5 BRAKET BRAKET CEILING B/D < A > < B > 6. Insert and firmly secure the anchor bolt (B1) into the two nuts (N5, N6). “B2” “B1” “N1” “N5” “N6” CEILING B/D 4_SADT-100EC SADT-100EC_ENG.indd 4 2008-01-23 오후 4:14:39...
-
Page 6: Alarm In/Out
7. Prepare the camera adapter of the CAMERA to install. Connect the power cable, video out cable and alarm I/O cable to the camera adaptor. When connect the video output cable, use the L type BNC adapter(suported). For more information, see the installation guide for the SmartDome camera. POWER CABLE VIDEO OUT BNC ADAPTOR... - Page 7 9. Use the screws on the Wiring Support Tube plate to fix it. PLATE for fixing Wiring Support Tube CEILING 0. Put up the safety wire, attached to the camera, on the safety hook. Durin g installation or detachment, to avoid safety accident and camera damage due to the fall, make sure the safety wire is secured to the hook.
- Page 8 . To avoid accidental fall and consequent physical injury or damage to the camera during installation or detachment, make sure the safety wire is secured to the hook., then insert the 3 guides of camera to the guide hole of camera adapter. After that turn the camera about 15 degrees clockwise.
- Page 9 . Insert the provided screw (M3×L6, included in camera product) into the fixing hole of the lever lock and fix it. Once you removed the camera from the camera adaptor, loosen the screw (BH M3xL6). With the lever lock turned clockwise, turn the camera counter clockwise and then pull it down.
-
Page 10: Product Specification
Product Specification Size: Ø235 X H210 Weight: 765g Operation Temperature: -10˚C ~ 50˚C Ø235 Accessories Safety wire .......... 1 Safety bracket ........1 Template A .......... 1 Template B .......... 1 MANUAL ..........1 BNC ADAPTOR-L TYPE ...... 1 SADT-100EC_9 SADT-100EC_ENG.indd 9 2008-01-23 오후... -
Page 11: Correct Disposal Of This Product
Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in the European Union and other European countries with separate collection systems) This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end of its working life.
