Heavy Duty
Vehicle Stands
Operating Instructions & Parts Manual
Model Number
HW93524
HW93526
!
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
Read this manual and follow all the Safety Rules and Operating Instructions before using this product.
HW93524-M0 rev 08172010
Capacity per pair
7 Ton
25 Ton
HW93524
HW93526
10939 N. Pomona Ave. Kansas City, MO 64153
customerservices@heinwerner-automotive.com
Made in the
U.S.A.
SFA Companies
Advertisement
Table of Contents
Summary of Contents for HEIN-WERNER AUTOMOTIVE HW93524
- Page 1 Obey all safety messages that follow this symbol to avoid possible injury or death. SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153 customerservices@heinwerner-automotive.com Read this manual and follow all the Safety Rules and Operating Instructions before using this product. HW93524-M0 rev 08172010...
- Page 2 Rated capacity is per pair! SPECIFICATIONS Model Capacity per Pair Base Size Min. Height Max. Height Height Intervals HW93524 7 Ton 9-1/4" x 9-1/4" 9-1/2" 15-3/4" 1" HW93526 25 Ton 10"...
- Page 3 BEFORE USE WARNING (refer to Figure 1 for location of components) 1. Verify that the product and the application are • Study, understand, and follow all instructions compatible. If in doubt, contact Hein-Werner customer provided with and on this device before use. Service.
- Page 4 REPLACEMENT PARTS PART NO. DESCRIPTION 928062 7 Ton Pin & Chain Assy 928065 25 Ton Pin & Chain Assy TWO YEARS LIMITED WARRANTY For a period of two (2) years from date of purchase, SFA Companies will repair or replace, at its option, without charge, any of its products which fails due to a defect in material or workmanship under normal usage.
