DATREND Systems vPad-Mini Operating Manual

Safety analyzer
Hide thumbs

Advertisement

Quick Links

vPad -Mini
™
vPad Safety Analyzer
Operating Manual
MN-125b

Advertisement

loading

Related Manuals for DATREND Systems vPad-Mini

Summary of Contents for DATREND Systems vPad-Mini

  • Page 1 vPad -Mini ™ vPad Safety Analyzer Operating Manual MN-125b...
  • Page 3 ™ vPad -Mini vPad Safety Analyzer Operating Manual © 2019 - 2020 Datrend Systems Inc. Unit 130 - 4020 Viking Way Richmond, BC • CANADA • V6V 2L4 Tel: 800.667.6557 (North America Only) or 604.291.7747 • Fax 604.294.2355 e-mail: customerservice@datrend.com...
  • Page 5 Automation Copyright Datrend Systems Inc. (“DSI”) agrees to a limited copyright release that allows you to reproduce manuals and other printed materials for use in service training programs and other technical publications. If you would like other reproductions or distributions, submit a written request to Datrend Systems Inc.
  • Page 6 Activation is required, the Terms and Conditions published on the Datrend Systems Inc. (DSI) website shall prevail. By using the App, you agree to these terms and Conditions. IN NO EVENT SHALL DATREND SYSTEMS INC. BE LIABLE FOR CONSEQUENTIAL DAMAGES.

  • Page 7: Table Of Contents

    OPERATORS MANUAL Table of Contents ..........
  • Page 8 OPERATORS MANUAL Table of Contents # Page iv...

  • Page 9: Overview

    OPERATORS MANUAL 1 Overview vPad-Mini™ is an electrical safety analyzer designed for manual safety testing in an environment with limited need for Applied Parts testing. Options are available to: a) record measurements, create test records and use Bluetooth communications to print or transfer the records; or. b) automate the safety test according to the following standards: IEC62353, IEC61010, AU/NZ 3551 or NFPA99.
  • Page 10 OPERATORS MANUAL Overview/Chapter 1 # Page 2...

  • Page 11: Manual Testing

    2 Manual Testing 2.1 General The vPad-Mini app, in its most basic mode, is a manual electrical safety tester. Test results are only saved if you manually record the measurement value. There is no evaluation of passing or failing against any limit values you wish to impose.
  • Page 12 OPERATORS MANUAL If there is a problem during initialization of the hardware, an Alert Dialog is shown (Figure 2). Figure 2 Fault messages which may be shown by the dialog are: Error Message Shown if... Analyzer electronics off-line ! Attempt to connect with Check AC supply input.
  • Page 13 Figure 4 Standards supported by vPad-Mini are AAMI-ES1, NFPA 99, IEC 60601, IEC 62353, IEC 61010, VDE751 and AU/NZ 3551. On first run of the app, the default standard will be AAMI-ES1. The selected standard appears on most menus of the app, including the main menu where it is shown above the button.
  • Page 14 However, access to the Apps submenu of the Android Settings will be necessary if the vPad-Mini app needs to be updated in the field with a new version, or you wish to use QuickSupport (from Teamviewer) for remote support.
  • Page 15 OPERATORS MANUAL The phone's BACK button is used to exit the Android Settings menu. button of Figure 3 saves changes, if any, to the safety standard, polarity delay and/or receptacle status on returning to the Main Menu, and closes the Settings Menu.
  • Page 16 OPERATORS MANUAL The large central button selects the type of measurement to be performed. 2.3.1 The button displays a schematic image which represents the measurement being displayed on the upper half of the screen. 2.3.2 Initially the button image is set to L1-L2 voltage.
  • Page 17 OPERATORS MANUAL 2.4 Load Current Activity button on the main menu measures and displays load current. This measurement is somewhat simpler than others on the app since it provides only one type of measurement. Figure 9 A numeric readout occupies the entire upper half of the screen. The measurement value is updated approximately once per second.
  • Page 18 OPERATORS MANUAL 2.5 Resistance button on the main menu starts a resistance measurement (Figure 10). The UI of this activity is similar in design to the UI for the voltage measurement (see Section 3). Figure 10 A numeric readout occupies the entire upper half of the screen. The measurement value is updated approximately once per second.
  • Page 19 OPERATORS MANUAL 2.5.3 When the central button is pressed a pop-up pick list is then shown which allows the user to change the type of measurement. Figure 11 As shown in Figure 11, this activity provides two measurements: power cord or PE resistance and point-to-point resistance.
  • Page 20 OPERATORS MANUAL 2.6 Leakage Currents button on the main menu initiates leakage current measurements (Figure 12). The UI of this activity is highly dependant on the setting of the standard, and in this way the leakage measurements differs somewhat from other parameters.
  • Page 21 OPERATORS MANUAL The "ground button" may be disabled or hidden depending on the selected leakage test. For AAMI and IEC60601 earth leakage, the button is disabled, its image is set to the open-circuit icon, and the ground at the test receptacle is maintained in the open state. For IEC62353 equipment leakage, and for AAMI isolation or IEC MAP tests, the "ground button"...
  • Page 22 OPERATORS MANUAL The "polarity button" is enabled for all leakage tests unless the standard is set to NFPA, in which case the button is disabled and all measurements are performed with receptacle polarity set to normal. When the selected leakage test is the AAMI (lead) isolation test, the IEC60601 MAP test, or the IEC62353 applied part leakage test, the ground and neutral buttons on the UI are hidden and a button which controls the MAP test voltage is then shown (see Figure 14).
  • Page 23 OPERATORS MANUAL An image button located at the top left corner of the UI enables the user to select the leakage test type. Figure 16 The content of the pick list depends on the standard which has been selected via the Settings Menu of Section 2.2, as follows:...
  • Page 24 OPERATORS MANUAL 2.7 Help Activity Test-related menus of the app provide a button which displays reference information and instructions which pertain to the menu in use. The help information is contained in HTML files and related figures which are included in the app. A help system based on HTML enables the help to include hyperlink references (Figure 17), photographs (Figure 18) and reference tables (Figure 19).

  • Page 25: Recording Results

    The recording option is integral to the vPad-Mini firmware and is activated by an activation file installed on the phone. The activation file is provided through the Datrend dealer on purchase of the option, and is tabletID (phone) specific.
  • Page 26 OPERATORS MANUAL Figure 21 This screen will display a listing of the test records currently in memory, provide some options on the way in which the list will be ordered (by name, by date, ascending or descending), provide the ability to search for a particular record, and select multiple records to send or print.
  • Page 27 OPERATORS MANUAL If there are measurements, the screen will show the measurement and the above button will change to . Touching this button will delete the measurement at the bottom of the list. Figure 23 Note that when there are measurements on the screen, the file save button icon will be enabled.
  • Page 28 OPERATORS MANUAL Figure 25 Once a measurement is stored to the clipboard, return to the Main screen to select another parameter, or to finalize the saving of the complete record. Going back to the Recording screen (Figure 21), note the listing of the test records currently in memory.
  • Page 29 OPERATORS MANUAL Figure 29 Figure 27 Figure 28 The lists will be separated as best as possible by the Mini, based on the type of communication protocol identified by Android. It is possible to process multiple files at once using the ‘multiple files’ button, , on the Recording screen, Figure 21.
  • Page 30 OPERATORS MANUAL In addition, it is possible to search for a particular record by entering a keyword or several characters, and searching based on ‘starts with’ or ‘contains’. Press the magnifying glass icon button to begin the search. Figure 32 Enter 2 or more characters of a filename that begins with the characters and press ‘Starts with’...

  • Page 31: Automated Testing

    Recording option. The automation option is integral to the vPad-Mini firmware and is activated by an activation file installed on the phone. The activation file is provided through the Datrend dealer on purchase of the option, and is tabletID (phone) specific.
  • Page 32 OPERATORS MANUAL Figure 33 Pressing the button will provide a dialog box, Figure 34, to allow entry of an identification code for AUTO the device. This code can be alpha, numeric or alphanumeric, but must uniquely identify the device as it will be used in the test record filename.
  • Page 33 The selection of a Standard will identify what particular tests are to be performed to meet the requirements of the electrical safety standard, as identified in the Default<std> file resident on the vPad-Mini. On initial delivery, this file will define a test protocol which meets the basics of an accepted Standard, subject to any limitations imposed by vPad-Mini.
  • Page 34 OPERATORS MANUAL The Serial number is (should be) unique to the device and must be entered by the keyboard. Touch in the Serial Number input text box to activate the keyboard. Enter the serial number and press when done.
  • Page 35 Figure 39 The list of facilities, for instance, is a text file resident on the vPad-Mini. The file can be created on a PC and transferred to the Mini tablet, or it can be created as new devices are tested. In the above screen, the Search has been entered with a blank initial value, as indicated by the blank text input box, in the lower left corner.
  • Page 36 OPERATORS MANUAL To add an entry to the list, type in the new value to the text input box of Figure 39 and touch the icon, . The value added will now appear in the list. Touch the new entry to select it and return to the Equipment Information screen.
  • Page 37 OPERATORS MANUAL Figure 42 Note that the search is case insensitive. Touch on the desired value in the List to accept it as the input and return to the Equipment Information screen. When all of the parameters deemed necessary have been entered, touch the...
  • Page 38 OPERATORS MANUAL Figure 43 Figure 44 If the Edit Info box is checked, these screens will be skipped over, but the answers will be assumed to , and the info from the files will be used. Note that the name of the ‘last test performed on this equipment’ will be a ‘seq’ type filename if the protocol was based on a ‘named’...
  • Page 39 OPERATORS MANUAL 4.1 Test Protocols When a test is started for the first time on a device, it may be necessary to select the desired standard from the drop-down list. On this first-time test, the protocol will start as the default protocol defined for the particular standard.
  • Page 40 OPERATORS MANUAL If you wish to change the test protocol for this device, touch the Next Page icon, . The test protocol is defined over a total of 4 pages. The only change available on page 1 is selection of the Class of the device.
  • Page 41 If Semi-Auto(mated) mode is enabled, the vPad-Mini will stop and wait for instructions at any point where changing the Mains test condition is about to happen, or where user input is required.
  • Page 42 OPERATORS MANUAL Figure 48 Once a protocol has been setup, it can be saved to a ‘named’ sequence by touching the Save icon When the Save icon is touched, a dialog will be presented as shown in Figure 49, below.
  • Page 43 OPERATORS MANUAL 4.2 Test Protocols Based on a Sequence On the ‘Sequence’ screen a ‘named’ sequence can be selected from the dropdown list shown in Figure 50 and Figure 51. When naming sequences, it is recommended that one of the following ‘keys’ be included in the name, depending on the Standard used: 62353, 61010, or NFPA.
  • Page 44 OPERATORS MANUAL Figure 52 Note that the Save As input box is already filled in with the name of the sequence you started with, but the dropdown list and the keyboard input are still available if a different filename is desired.
  • Page 45 OPERATORS MANUAL Figure 54 An advisory to turn the EUT ON and wait till it reaches operational condition before continuing. Figure 55 An advisory to turn the EUT OFF in an orderly manner prior to removing power from the receptacle. This could happen in preparation for reversing the polarity on the receptacle, or at the end of a test prior to saving results.
  • Page 46 OPERATORS MANUAL An advisory to turn the EUT ON and wait until it reaches operational mode. This would typically be seen after applying Reverse Polarity. Figure 57 During testing, test measurements are taken and compared to limits set out in the protocol. A typical Leakage Current test is shown below.
  • Page 47 OPERATORS MANUAL 4.4 Testing Applied Parts Many medical devices have applied parts consisting of one or more leads used to connect to the patient and acquire a signal for a given parameter or function such as ECG. Applied parts are designated as: a) Type B if they are applied to an external body part (does not break the skin or enter the body cavity) and include a ground/protective earth connection to make the measurement;...
  • Page 48 Applied Part. The functions will be presented in a list, filtered by AP Type. The functions list is located in the /Datrend/vPad-Mini/Lists/ folder in the Functions_list file. The list contains a B, BF or CF prefix to allow the functions to be filtered. If a function can be more than one Applied Part Type, an entry must exist for each Type.
  • Page 49 4.5 Saving Results As measurements are made, the test and the results are stored to a file on the vPad-Mini. The test report is a text file which is stored in the Datrend/vPad-Mini/Records folder. The user can optionally assign some descriptive information to the test report, including Technician and actual Labor Time.
  • Page 50 OPERATORS MANUAL Figure 64 On this Save Test Record screen, the user is provided the opportunity (again) to save this test protocol as a named Test Sequence. The difference here is that this is the sequence that will be recorded in the device test data and will be recalled in later tests, rather than just as a protocol based on the device ID.
  • Page 51 OPERATORS MANUAL Figure 66 If you select the first option, you will go to the Standards screen, where you will be able to define and Run a protocol based on a standard, or alternately go from the Standards screen to the Sequence screen and select a ‘named’...
  • Page 52 OPERATORS MANUAL Operation/Chapter 4 # Page 44...

  • Page 53: Upgrades And Maintenance

    OPERATORS MANUAL 5 Upgrades and Maintenance Software Applications (Apps) may be upgraded from time-to-time to provide enhanced features or improvements. Contact Datrend or your local dealer for information on these upgrades. In some cases, the changes made to an App may be to correct operational issues that have come to the attention of DSI.
