  • Page 1 Manual for RockBoard® MOD 5 Cab SIM + DI Patchbay...

  • Page 2: Table Of Contents

    Handling ........................3 FCC certification ......................3 Main Features ........................ 4 Mounting ........................5 Mounting on a RockBoard® Pedalboard ................5 Detaching the MOD V2’s front plate ................6 Mounting on a non-RockBoard® pedalboard ..............7 Setup & Operation ......................8 Setup example ......................

  • Page 3: Contents

    You want to use your favorite cab? No problem, load an impulse response of its sound into the MOD 5 and you have it with you, wherever you go. The patchbay part is designed to route connections from underneath your pedalboard to its front, in order to give you a central access point to your setup and tidy up your connections.

  • Page 4: Main Features

    Main Features • IR based speaker cabinet simulations • 6 integrated IRs based on popular guitar and bass cabinets • Support of custom IRs (max. 1024 pts.) • Active DI Box • Selectable MONO/STEREO input • Selectable UN/BALANCED output • Connects to PC/MAC editor via USB •...

  • Page 5: Mounting

    For mounting your new MOD 5 onto a RockBoard® pedalboard, there are multiple options. You can either mount it in its MOD slot (available on all RockBoard® pedalboards except DUO 2.0 and 2.1) or detach the MOD’s front plate and mount it on top or underneath your pedal board.

  • Page 6: Detaching The Mod V2'S Front Plate

    Front plate, so it will fit flush onto/under the board surface. Remove the screws as indicated below to release the front plate from your MOD 5 using a PH2 Phillips head screw driver. The mounting nuts of the jack sockets do not have to be removed!

  • Page 7: Mounting On A Non-Rockboard® Pedalboard

    Mounting on a non-RockBoard® pedalboard There are multiple ways of mounting your MOD on a non-RockBoard® pedalboard. You can either mount it directly to the board surface using hook & loop tape or another reclosable fastener. Additionally RockBoard® offers the MOD Rack for mounting your MOD in various ways onto, into or underneath pedalboards of other manufacturers.

  • Page 8: Setup & Operation

    Thru-Connections The RockBoard® MOD 5 Cab SIM + DI Patchbay is designed to act as central access point to your effects setup. The A, B and C TRS sockets are wiring through connections from the front of MOD 5 to the corresponding sockets on its back.

  • Page 9: Cab Models

    For silent practicing or headphone monitoring connect your headphone to the 3.5 mm / 1/8" jack output in the front of MOD 5. Please note: the output of the Phones output will always be stereo. If inputting a mono signal, the same signal will be audible on the left and right channel. When inputting a stereo signal, tip will be left and ring will be right.

  • Page 10: Firmware Update

    Firmware Update On our website www.rockboard.net, we always provide the most recent version of the MOD5 IR Loader. The IR Loader package also includes a firmware package that makes the MOD5 compatible with the IR Loader software. The IR Loader software automatically checks for compatibility of the MOD5. If your MOD5’s Firmware is too old, you can.
