Luvata Heatcraft Series Installation, Operation And Maintenance

Condenser coil

Condenser Coil Installation,

Operation and Maintenance

Installation, Operation and Maintenance Guide

Guidelines for the installation, operation and maintenance of

the Heatcraft brand of refrigerant condenser coils manufactured

by Luvata in Grenada, MS have been provided to help insure

proper performance of the coils and their longevity. These are

general guidelines that may have to be tailored to meet the spe-

ciﬁ c requirements of any one job. As always, a qualiﬁ ed party

or technician should perform the installation and maintenance

of any coil. Protective equipment such as safety glasses, steel

toe boots and gloves are recommended during the installation

and routine maintenance of the coil.

Receiving Instructions

All Heatcraft coils are factory tested, inspected and carefully

packaged.

Damage to the coils can occur after they have left the factory.

Therefore, the coils should be inspected for shipping damage upon

receipt. The freight bill should also be checked against items

received for complete delivery. Damaged and/or missing items

should be noted on the carrier's freight bill and signed by the driver.

For additional assistance, contact your local Luvata coil repre-

sentative.
