CARLO GAVAZZI DuplineSafe GS 7380 0080 Quick Manual

DuplineSafe
Configuration and Test Unit
Type GS 7380 0080
Product Description
Configuration and Test Unit
for DuplineSafe. Configures
DuplineSafe Safety Relay
Output module type number
GS38300143230
DuplineSafe Safety Input
module type number
GS75102101. Monitors the
Type Selection
Supply
Internal battery
Product Specifications
Display
Type
Height of dots
Keyboard
No. of keys
Channel keys
Command keys
Cable 1
GS73800080 connector
Adapt 7380
Programmer cable
Cable 2
GS73800080 connector
Safety module connector
Test cable
Specifications are subject to change without notice (06.02.2008)
Dupline ® is a registered trademark. A product of the CARLO GAVAZZI Group
DuplineSafe bus in Test Unit
mode.
Highly recommended for
and
DuplineSafe system start-
up, troubleshooting
maintenance.
Ordering no.
GS 7380 0080
2 x 16 characters
LCD
5 mm
Tactile keys
12
1-8
« ← » « → » (scroll up/down)
« NO », « YES », « READ/ON »
GS73800080 to Adapt 7380
or safety module
1 6/6 modular plug
1 6/6 modular plug
GAP-CAB
GS73800080 to Safety
module
1 6/6 modular plug
GRIP
GTU8-GRIB-CAB
• Portable Configuration and Test Unit
• Configures the DuplineSafe Relay Output module
GS38300143230
• Configures the DuplineSafe Input module GS75102101
• Monitoring of DuplineSafe Input module status
• LCD-display
• 12-key tactile keyboard
• Supplied by standard 9V battery
• ADAPT 7380 included
Ordering Key
®
Type: Dupline
Type no.
and
Supply Specifications
Power supply
Type
Battery Life Time (Sleep)
General Specifications
Environment
Degree of protection
Pollution degree
Operating temperature
Storage temperature
Humidity (non-condensing)
Mechanical resistance
Shock
Vibration
Dimensions (l x w x d)
Material
Weight
Du line
Fieldbus
Installationbus
GS 7380 0080
9V battery (not included)
6LR61
Typ. 2 years
IP 40
3 (IEC 60664)
0° to +50°C (+32° to +122°F)
-20° to +60°C (-4° to +140°F)
20 to 80%
15 G (11 ms)
2 G (6 to 55 Hz)
145 x 90 x 28 mm
ABS, grey
250 g excluding battery
®
