- Page 1 ® DA-300 IO Tester Operations Manual THIS MANUAL CONTAINS TECHNICAL INFORMATION FOR ® THE DA-300 IO Tester REVISION: June 19, 2017 Version 1.0 888-0300-002...
- Page 2 EBERLE DESIGN INC., PHOENIX, ARIZONA EDI IS CERTIFIED TO ISO 9001:2008 QUALITY SYSTEMS STANDARDS. DA-300 IS A REGISTERED TRADEMARK OF EBERLE DESIGN INC. INFORMATION CONTAINED HEREIN IS PROPRIETARY TECHNICAL INFORMATION OF EBERLE DESIGN INC. PUBLICATION, REPRODUCTION OR USE IN WHOLE OR PART IS NOT PERMITTED EXCEPT UNDER TERMS AGREED UPON IN WRITING.
- Page 3 Table of Contents Section 1 GENERAL ......................1 Section 2 SPECIFICATIONS ..................... 2 Section 3 PROCEDURES ....................3...
- Page 4 ® The Data Aggregator DA-300 provides the ability to monitor several DC and AC analog ® signals as well as detector outputs from a traffic cabinet. The DA-300 also generates relay ® outputs. Production testing and demonstration of a DA-300...
- Page 5 DA-300 IO TESTER Operations Manual Section 2 SPECIFICATIONS ® (Note: An output channel of a tester is an input to the DA-300 Input Voltage: 80 to 145 VAC Output Power DC Voltage: 24VDC @ 1.25 A Output Adjustable DC Voltage:...
- Page 6 DC voltage by rotating it clockwise. ® Freely adjust the DC or AC voltages as required by the test for this DA-300 input channel. When the test for this channel is complete, flip the toggle switch of step 1 back down.
- Page 7 ® DA-300 IO TESTER Operations Manual Simulating a Detector Input There are 16 detector toggle switches labeled DET1 through DET16. When a detector toggle switch on the IO Tester is pushed up, the IO Tester simulates that particular channel as a turned-on detector output or “call” to the connected DA unit.
