Summary of Contents for Gotrax Nova Pro
- Page 1 Nova Pro S M A R T E R H O V E R B O A R D USER MANUAL...
-
Page 2: Congratulations On Your Purchase
Congratulations on your purchase! This user manual will help you operate your new Hoverboard. Be sure to read ALL OF THE INFORMATION in this manual before riding. NOTE TO ALL RIDERS UNDER 18 YEARS OF AGE: important that you get parental permission before riding your Hoverboard. - Page 3 Don’t ride until you read this ALWAYS wear a helmet when riding your hoverboard. Make sure your hoverboard has a before taking it out full battery to ride. Always be aware of local road laws, and follow them. WARNING To reduce the risk of injury, adult supervision is required, never use in roadways, near cars, on or near steep inclines or steps, swimming pools or other bodies of water;...
-
Page 4: Warning Message
2. Abuse - We do not cover physical damage due to negligent care and extreme riding. 3. Whenever you ride the GOTRAX Hoverboard , you risk severe injury or even death from loss of control, collisions, and falls. Use caution and ride at your own risk. - Page 5 1. SRX PRO Hoverboard 2. SRX PRO Approved Power Adapter / Charging Unit Unpack 1. Hoverboard 2. Approved Power Adapter / Charging Unit Remove all packaging material, then inspect each item for any accidental damage that may have occurred during shipping. Remove all packing material, then inspect each item for accidental damage that may have occurred during shipp...
- Page 6 Get to know your hoverboard Blue LED Blue LED Footpad Footpad Power Button Charger Port Blue LED Blue LED The hoverboard comes fully assembled. 6.2mph Charger model: FY0424200850 5 Miles Manufacturer: SHENZHEN FUYUANDIAN 176 lbs POWER CO LTD 36V 2.6AH Input: 100-240Vac, 50/60Hz, 1.5Adc max DC 42V 0.85A Output: 42Vdc, 0.85 Adc...
- Page 7 1. Insert the charging plug into the port. Charge your hoverboard 2. The charger box will have a green light when fully charged and a red light when charging. Before using the hoverboard, you must fully charge the battery. 1. Insert the charging plug into the port. 2.
- Page 8 Hoverboard Functions press and hold the silver button on the back of your hoverboard To power the hoverboard on, for 1 second. press the silver button on the back of your hoverboard twice in a row. Mode Switch 1. Double-click the switch button within 1.5 seconds in the shutdown state to switch between self- balancing and non-self balancing modes.
-
Page 9: Riding Tips
Riding Tips 1. You will want to start riding your hoverboard by mounting the board button and the charging port. 2. Place your hoverboard on the ground directly in front of your feet. Step with one foot onto the platform, and then quickly step up onto the hoverboard with your second foot. -
Page 10: Maintenance And Repair
Maintenance & Repair If you regularly clean and maintain your electric hoverboard, it will extend its life. If the hoverboard is dirty, wipe it clean with a Cleaning and storage: soft damp cloth. DO NOT use alcohol, gasoline, kerosene, or other corrosive chemical solvents to clean the hoverboard. - Page 11 Troubleshooting: issues is calibrating your board. Here are the steps involved in 1. Start with the hoverboard powered off. 2. Adjust the foot pedals until they are level with each other and the ground. 3. Press and hold the power button for 10 seconds. The LED lights will 4.
-
Page 12: Bluetooth Setup
Bluetooth Setup The hoverboard features a Bluetooth speaker that can be paired with any mobile device to play audio. The Bluetooth speaker is automatically enabled when the hoverboard is turned on and will remain enabled and discoverable as long as the hoverboard is powered on. Read the instructions below to learn how to operate the hoverboard Bluetooth speaker. -
Page 13: Battery Information
Battery Information Improper disposal of used batteries may seriously pollute the environment. Please comply with local disposal regulations. Make sure to store your hoverboard and power adapter in conditions that do not exceed 104 degrees Fahrenheit or below 32 degrees Fahrenheit. Warning - Risk of Fire - No User Serviceable Parts, The prolonged exposure to UV Rays, Rain and the Elements may damage the enclosed materials, store indoors when not in use. -
Page 14: Troubleshooting
GOTRAX .com , and reserve the rights to update and change manuals online. Please contact our customer service team if you are experiencing problems or need more detailed information. They can be reached at GOTRAX .com Warranty For warranty information, please visit GOTRAX .com... - Page 15 W W W . G O T R A X . C O M #RideGOTRAX...
- Page 16 GOLABS, INC .com 2201 Luna Rd.
