Summary of Contents for adapt Xl-Base
- Page 3 XL-BASE...
- Page 4 Once you are comfortably positioned on the XL-BASE, press and hold the IN button until the XL-BASE is completely locked in place. At any time you may release the IN button and the XL-BASE will stop to allow you to reposition.
- Page 5 Press and hold the OUT button until the XL-BASE has reached the desired height for your ideal transfer. At any time you may release the OUT button and the XL-BASE will stop to allow you to reposition. Once you are ready to continue, simply press and hold the OUT button to resume you descent out of the vehicle.
- Page 7 MANUAL BACKUP SYSTEM Your new XL-BASE is equipped with a manual backup system. If you were to encounter a power failure or other functional problem, this backup system will allow your seat to be returned to the inside of your vehicle.
- Page 8 MANUAL BACKUP SYSTEM If your XL-BASE will not run and the seat is OUT of the vehicle, follow the next few steps to manually raise the seat and pivot it back in. Please note: The next few steps will require physical effort.
- Page 9 MANUAL BACKUP SYSTEM (CONTINUED) Locate the yellow drive nut on the exterior of the slide (see picture for details). Using the biggest ‘Allen’ key (yellow ‘Allen’ key), unbolt the drive nut. Once you have removed this, you will be able to push the seat base up to its pivot point. DRIVE NUT...
- Page 10 Please note: The next few steps will require physical effort. Remove the vinyl covered trim that is located on the right-hand side of the XL-BASE. Under this trim you will find two (2) ‘Allen’ keys (a red one and a yellow one).
- Page 11 MANUAL BACKUP SYSTEM (CONTINUED) *NOTE: Be careful not to disconnect or constrict the wires when manually pivoting the seat. Once the problem is resolved, do not forget to replace the ‘Allen’ keys back in place, under the vinyl covered trim. Please contact your dealer for full diagnostic and needed repairs.
-
Page 12: Year Limited Warranty
3 YEAR LIMITED WARRANTY XL-BASE Adapt Solutions # 1 Ltd. (Adapt Solutions), warrants to the original purchaser of an XL-BASE that the equipment is free from defects in material and workmanship for a period of three years from date of purchase. - Page 13 Solutions dealer or Adapt Solutions with proof of purchase indicating the date purchased. Adapt Solutions will pay for shipping back to the purchaser within the continental United States and Canada if a defect in materiel or workmanship is discovered. Return freight and repair charges will be the responsibility of the purchaser if the problem is not covered by warranty.
-
Page 14: Warranty Registration
Defective parts must be returned by an authorised dealer, who will have received a prior return authorization from Adapt Solutions #1 Ltd. All warranted parts shall be sent to Adapt Solutions #1 Ltd prepaid.
