Infrared Thermometer with Access Controller
Product image
Basic specifications:
Sensor
WTTS00
Accurate
±0.2℃
Working voltage
5V ~ 12V input
Measuring distance
5~10cm
Internal relay
Yes
Alarm
Yes(external available)
Size
130*90*53mm
Package
Neutral packaging
User manual BM-TDA
Diplay
Measuring time
Working ambient temperature:
Temp measurement range:
Wiegand input/output
Certificates
Weight
Installation
www.biomaxsecurity.com
Infrared LED
<0.5s
5℃~32℃
35℃~42.9℃
Yes
CE/FCC/ROHS
240g
Wall mounted
Advertisement
Table of Contents
Summary of Contents for BioMax BM-TDA
- Page 1 User manual BM-TDA Infrared Thermometer with Access Controller Product image Basic specifications: Sensor WTTS00 Diplay Infrared LED Accurate ±0.2℃ Measuring time <0.5s Working voltage 5V ~ 12V input Working ambient temperature: 5℃~32℃ Measuring distance 5~10cm Temp measurement range: 35℃~42.9℃ Internal relay...
- Page 2 “+/-“ to adjust value of passwords, Key “+/-“ is for Increasing and decreasing the value, key “M” is for positioning (Notes: please make sure to remember the new passwords) 6. Exit setting: Press key “M” the sixth time to exit the setting BM-TDA connection diagram www.biomaxsecurity.com...
- Page 3 Connection descriptions: Connection A (Wiegand input/output): 1. GND: GND input 2. D2 OUT：wiegand output 3. D2 IN：wiegand input 4. GND：GND input 5. DI OUT：wiegand output 6. D1 IN: wiegand input Connection B (Standalone): 1. NO IN：Relay input 2. NO OUT：Relay output 3.
- Page 4 BM-TDA Access control Sketch Map connection A (Wiegand input/output) BM-TDA Access control Sketch Map connection B (Standalone) www.biomaxsecurity.com...
