Summary of Contents for LI-COR 7900-300
Page 1
Heavy Duty Adjustable Tripod Instruction Manual...
Page 3
Regional Offices LI-COR Biosciences GmbH Siemensstraße 25A 61352 Bad Homburg Germany Phone: +49 (0) 6172 17 17 771 envsales-gmbh@licor.com LI-COR Biosciences UK Ltd. St. John’s Innovation Centre Cowley Road Cambridge CB4 0WS United Kingdom Phone: +44 (0) 1223 422102 envsales-UK@licor.com LI-COR Distributor Network: www.licor.com/env/distributors...
Page 4
Notes on Safety This LI-COR product has been designed to be safe when operated in the manner described in this manual. The safety of this product cannot be guaranteed if the product is used in any other way than is specified in this manual. The product is intended to be used by qualified personnel.
Contents Section 1. General Information Safety Information Precautions Site Selection Soil Conditions Loading the Tripod Components Tripod Guy Wire Kit 1-10 Grounding Kit 1-11 Component List 1-12 Tools 1-13 Section 2. Assembling the Tripod Legs and Base Mast and Guy Wires Anchor the Tripod Section 3.
Safety Information The 7900-300 Heavy Duty Adjustable Tripod has been designed to be safe when operated in the manner described in this manual. The safety of this product cannot be guaranteed if the product is used in any other way than described in this manual.
Doing so could lead one to fail to observe the safety warnings and sustain per- sonal injury or damage to equipment through the use of the tripod. Warning: Assembly of the 7900-300 Adjustable Heavy Duty Tripod should be car- ried out with a minimum of two people. Attempts to assemble the tripod with an insufficient number of people could lead to personal injury.
Page 9
Section 1. General Information Warning: The tripod is not suitable for installation on solid rock, soils that are composed of a rocky substrate, or other hard surfaces that will not allow install- ation of any of the following: earth anchors, foot stakes, or grounding rod. In these conditions the tripod may not meet the specifications described in the instructions and additional measures may be required to stabilize the tripod.
Section 1. General Information Warning: Never weld the tripod or attach a bracket that serves to sup- port a climbing apparatus. Doing so will compromise the strength of the tripod and may result in injury, death, and/or damage to equip- ment.
Section 1. General Information Soil Conditions The Heavy Duty Adjustable Tripod can be adequately supported in “average” soil. “Average” soils are defined as stiff silts and clays containing up to 50% sand and gravel and having blow counts (N) of 8 to 16 per ASTM D 1586 and unconfined compressive strengths of 1500 to 3000 pounds per square foot.
Section 1. General Information Loading the Tripod Load the tripod according to the maximum weights and frontal areas given below. Warning: The guy kit, earth anchors, and foot stakes must be installed to meet the tripod specifications. If these components are not installed, the tripod may fall or fail, resulting in injury, death, and/or damage to equipment.
Page 13
Section 1. General Information Tripod Component Maximum Load Maximum Frontal Area Cross Arm Left 12.25 kg (27 lbs) 0.19 m (2.05 ft Right 12.25 kg (27 lbs) 0.19 m (2.05 ft Masts Upper 12.25 kg (27 lbs) 0.18 m (1.94 ft Lower 24.5 kg (54 lbs) 0.37 m...
Section 1. General Information Components The tripod includes the following components. If you have just taken delivery of your shipment, check to be sure it includes everything that you ordered. Tripod Lower Mast (1): 1.95 m (6'5") long; 6 cm (2.375") Outside Diameter (OD) Sched- Lower Mast part num- ber : 9879-014 ule 40 Aluminum Pipe 6061-T6.
Page 15
Section 1. General Information Leg Braces part num- Leg Braces (3): 0.82 m (2'9") long; 6 cm (2.375") OD Schedule 40 Aluminum ber: 9879-015 Pipe 6061-T6. Cross Arm (1): 1.5 m (59") long, 3.3 cm (1.3") OD Schedule 80 Aluminum Pipe Cross Arm part num- 6061-T6.
Section 1. General Information Guy Wire Kit Guy Wire Fitting and Hardware (1): Aluminum 6061-T6. Guy Wire Kit part number: 9979-003 Guy Wires (3): 7.62 m (25') Zinc-aluminum Coated Steel. Gripple® Cable Clasps (11): Gripple Plus Medium. Duckbill® Anchors (4): Model 68 Duckbill® Earth Anchors w/ 168 cm (66 in) Cable.
Section 1. General Information Grounding Kit Lightning Rod/Ground Wire Clamps (3): To secure the lightning rod and ground Grounding Kit part number 9979-004 wire to the mast. Ground Rod Clasp (1): To secure the ground wire to the ground rod. Ground Wire (1): 1.22 m (4'), 8 AWG Copper Wire. Ground Rod (1): 1.83 m (6') long;...
Section 1. General Information Tools We recommend the following tools for assembly. Tools are not provided with the tripod but can be purchased from a hardware or department store. Gloves Safety Glasses 19 mm Wrench (13 mm Optional) Torque Wrench and Sockets (19 mm and 13 mm) Hex Key (8 mm) Standard (Slotted Tip) Screwdriver Torpedo Level...
Page 20
Section 1. General Information 1-14 Heavy Duty Adjustable Tripod...
Section 2. Assembling the Tripod Legs and Base Attach One Leg to the Mast Gather the following components for one leg: lower mast, leg, leg extension, leg brace, foot, 90 mm bolts, lock washers, flat washers, and nuts. Attach the leg to the mast as shown below. Tighten the nut(s) to finger-tight for now.
Page 22
Section 2. Assembling the Tripod Attach the Leg Brace to the Mast and Leg Attach the leg brace between the leg and mast as shown below. Be sure the warn- ing label is near the mast. Warning: Pinch point. Use caution during assembly. Tighten the nut(s) to finger-tight for now.
Page 23
Section 2. Assembling the Tripod Attach the Leg Extension and Foot Attach the leg extension and foot to the leg, as shown below. Warning: Pinch point. Use caution during assembly. Tighten the nut(s) to finger-tight for now. When the tripod mast and legs are com- pletely assembled, tighten it to 23 N•m (204 lb•in;...
Section 2. Assembling the Tripod Mast and Guy Wires Install the Upper Mast The upper mast extends the reach of the tripod up to 4 meters (13.12 feet). Slide the upper mast over the lower mast. Secure it with a 90 mm bolt, nut, and two washers.
Page 25
Section 2. Assembling the Tripod Position the guy wire fitting on the mast so that is as close as possible to the anticipated cross arm location. It must still be under the cross arm. Secure it with a 100 mm bolt, nut, two flat washers, and a lock washer. Tighten the nut 23 N•m (204 lbs•in;...
Page 26
Section 2. Assembling the Tripod Install the Cross Arm The cross arm mounts to the mast with the cross arm bracket. Attach the bracket to the mast with U-bolts, flat washers (24 mm M8), lock washers (M8) and nuts (13 mm M8) from the cross-arm bracket hardware bag.
Page 27
Section 2. Assembling the Tripod Install the Guy Wires on the Mast Insert a cable thimble into each of the cable holes in the guy wire fitting. Warning: The earth anchor cables are stiff, corrosion res- istant wire rope. Wear gloves and safety goggles when hand- ling them.
Page 28
Section 2. Assembling the Tripod Install the Lightning Rod Install two lightning rod clamps as shown below. Attach the lightning rod to the mast with the two clamps. Use an 8 mm hex key to tighten the lightning rod. Raise the Tripod Prior to raising the tripod, consider access to the site, the position of the cross-arm with respect to expected orientation of sensors, and wind direction.
Section 2. Assembling the Tripod Anchor the Tripod Drive the Mast Anchor into the Ground The earth anchor is to secure the mast to the ground. Think ahead about the pos- ition of the tripod—or even set the tripod in position, then identify the point on the ground where the anchor should be driven.
Page 30
Section 2. Assembling the Tripod When setting the earth anchor, the cable will give several centimeters (~1 inch) when the anchor rotates underground. Caution: When installed in suitable soil (see Soil Conditions on page 1-5), the tri- pod can withstand a 161 kph (100 mph) wind while supporting a load. If soil conditions deviate from those described here, take measures to ensure that the mast anchor can withstand 392 kg (864 lbs) of upward force in order to ensure that the tripod will meet the wind and load specifications.
Page 31
Section 2. Assembling the Tripod Plumb the Mast Move the tripod into the desired position and use a torpedo level to check the ver- tical orientation of the mast on adjacent sides. Adjust one or more legs until the level indicates that the mast is plumb. Each leg can be extended or retracted in 5.1 cm (2 in) increments.
Page 32
Section 2. Assembling the Tripod Torque the Nuts and Bolts Tighten the nuts and bolts on the legs, leg extensions, leg braces and feet to 23 N•m (204 lb•in; 17 lb•ft). If not adequately tightened in the previous steps, tighten the cross arm nuts to 9.6 N•m (85 lb•in;...
Page 33
Section 2. Assembling the Tripod Connect the Mast Anchor Insert a thimble into the anchor point on the mast. Warning: The earth anchor cables are stiff, corrosion res- istant wire rope. Wear gloves and safety goggles when hand- ling them. Insert 22.86 cm (9 in) of earth anchor cable into a Gripple®...
Page 34
Section 2. Assembling the Tripod Install the Foot Stakes Foot stakes serve to secure the feet and prevent them from moving on the ground. Using a hammer, drive two stakes into oppos- ite corners of each foot. It is normal for the top of each stake to deform when it is driven.
Page 35
Section 2. Assembling the Tripod Install the Guy Anchors and Wires The three remaining earth anchors are to secure the guy wires. Prepare each anchor by inserting the cable into a Gripple® connector according to the arrows printed on the connector. Make a loop around a thimble and insert the other end of the cable into the Gripple.
Page 36
Section 2. Assembling the Tripod 3.9 m (12 ft 10 in) 3.7 m (12 ft 2 in) 3.4 m (11 ft 2 in) 3.1 m (10 ft 2 in) 2.8 m (9 ft 2 in) 2.5 m (8 ft 2 in) 2.3 m (7 ft 7 in) 45°...
Page 37
Section 2. Assembling the Tripod Tighten the Guy Cables Finish installing each guy wire by routing the guy cable through one side of a Gripple® according to the arrows on the device, through the loop at the end of the guy anchor, and back through the Gripple, pulling at least 7.6 cm (3 in) through the Gripple.
Page 38
Section 2. Assembling the Tripod Note: To release the Gripple, locate the Gripple release key in the Guy Wire Kit. Identify the hole in the Gripple, which can be found near either one of the cable insertion points. Insert the Gripple release key into this hole and press firmly. If there is tension on the cable it may be helpful to relieve the tension.
Page 39
Section 2. Assembling the Tripod Verify the Stability of the Tripod As a final step, verify the stability of the tripod to ensure it is assembled properly. Double check the vertical orientation of the tripod using a level (see Plumb the Mast on page 2-11).
Page 40
Section 2. Assembling the Tripod 2-20 Heavy Duty Adjustable Tripod...
Section 3. Maintenance Several routine maintenance procedures will ensure that the tripod is stable over time. Monthly Perform a visual inspection for damage or wear. Check the orientation of the tripod to ensure that it has not slipped out of plumb and that the mast is level (see Plumb the Mast on page 2-11).
Page 42
Section 3. Maintenance Heavy Duty Adjustable Tripod...
Section 4. Tripod Accessories The accessories are to secure sensors to the tripod or other instrument platform. Gas Analyzer and Sonic Anemometer Mounting Hardware Gas Analyzer Mount Kit: Includes crossover fitting, swivel mount, and riser bar, Gas Analyze Mount- which are listed separately below. ing Kit part number 7900-340 Crossover Fitting: Offset Cross, ¾"...
Section 4. Tripod Accessories Cross Arm Kit Cross Arm and Mounting Kit: Includes a 1.5 m (59") cross arm and mounting Cross Arm and hardware, listed separately below. Mounting Kit part number 7900-330 Mounting Hardware: Two 3.3 cm M8 U-bolts; two 6 cm M8 U-bolts; eight 13 mm Cross Arm Mounting M8 nuts;...
Appendix A. Specifications Tripod Load Capacity: 135 kg (297 lbs) Maximum Load Area: 2.19 m (23.58 ft Base Diameter: 2.54 m (8 ft 4 in) Mast Outer Diameter: 6.03 cm (2.375 in) Weight: 50 kg (110 lbs) Maximum Slope: 13.0° Maximum Wind Gust (3 seconds) : 161 kph (100 mph) Upper Mast...
Page 46
Appendix A. Specifications Heavy Duty Adjustable Tripod...
Inc.'s examination discloses to have been defective in material or workmanship without charge and only under the following conditions, which are: The defects are called to the attention of LI-COR, Inc. in Lincoln, Nebraska, in writing within one year after the shipping date of the instrument.
Page 48
The foregoing constitutes LI-COR, Inc.'s sole obligation and liability with respect to damages resulting from the use or performance of the instrument and in no event shall LI-COR, Inc. or its representatives be liable for damages beyond the price paid for the instrument, or for direct, incidental or con- sequential damages.
Page 50
Regional Offices LI-COR Biosciences GmbH Siemensstraße 25A 61352 Bad Homburg Germany Phone: +49 (0) 6172 17 17 771 envsales-gmbh@licor.com LI-COR Biosciences UK Ltd. St. John’s Innovation Centre Cowley Road Cambridge CB4 0WS United Kingdom Phone: +44 (0) 1223 422102 envsales-UK@licor.com LI-COR Distributor Network: www.licor.com/env/distributors...
