DTC PRORXD Series User Manual

Broadcast receiver
Hide thumbs
Table of Contents

Advertisement

Quick Links

Resource Identifier 100167
Revision 12.1
PRORXD Broadcast Receiver User Guide
Commercial in Confidence
DTC - Solent
Fusion 2
1100 Parkway
Solent Business Park
Whiteley
Hampshire
PO15 7AB
United Kingdom
+44 (0)1489 566 750

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRORXD Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DTC PRORXD Series

Summary of Contents for DTC PRORXD Series

  • Page 1 Resource Identifier 100167 Revision 12.1 PRORXD Broadcast Receiver User Guide Commercial in Confidence DTC - Solent Fusion 2 1100 Parkway Solent Business Park Whiteley Hampshire PO15 7AB United Kingdom +44 (0)1489 566 750...

  • Page 2: Intended Audience

     Notice about this Publication While DTC makes every attempt to maintain the accuracy of the information contained in its product manuals, the information is subject to change without notice. Performance specifications included in this manual are for guidance. All particulars are given by DTC in good faith, actual performance may vary.

  • Page 3: Symbols

    The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 0-2 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.

  • Page 4: Document History

    PRORXD Broadcast Receiver User Guide Commercial in Confidence Revision 12.1 Document History This is a controlled document, written and produced by the DTC Technical Publications team. Changes are recorded in the table below. Revision Date Author Summary of Changes 27/06/2014 Initial release.

  • Page 5: Table Of Contents

    The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 0-4 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
  • Page 6 The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 0-5 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.

  • Page 7: Product Overview

    SD composite video monitoring output is also offered. The unit can also be used as an IP decoder. When paired with a DTC Broadcast IP Encoder, the unit can send an IFB signal to the remote location via the reverse leg of the IP link. An optional adaptive bit-rate The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd.

  • Page 8: Prorxd-2Ru

    DTC Narrowband, enabling broadcast quality (4.8Mbps) signals to be transmitted in only 2.5MHz bandwidth is available as an option. Designed to work with external DTC down- converters, the receiver can be located up to 100m from the antennas using standard 75Ω co-axial cables.

  • Page 9: Approval Notices

    SD composite video monitoring output is also offered. The unit can also be used as an IP decoder. When paired with a DTC IP Encoder, the unit can send an IFB signal to the remote location via the reverse leg of the IP link. An optional adaptive bit-rate encoding/decoding mode is also available, allowing fully automated operation on variable capacity or contended networks such as VSAT or BGAN terminals.

  • Page 10: Product Package

    The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 2-4 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.

  • Page 11: Accessory Options

    The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 2-5 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.

  • Page 12: Labelling

    The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 2-6 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.

  • Page 13: Connections, Controls And Indicators

    The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 3-7 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
  • Page 14 The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 3-8 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.

  • Page 15: Prorxd-2Ru

    The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 3-9 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
  • Page 16 The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 3-10 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.

  • Page 17: Getting Started

    The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 4-11 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.

  • Page 18: Node Finder

    The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 4-12 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
  • Page 19 The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 4-13 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
  • Page 20 The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 4-14 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.

  • Page 21: Web Browser Control

    Our PRORXD units are shipped to you with a fixed IP address (192.168.0.1). If it is necessary to change the IP address, this can be done via the front panel display or using DTC’s Node Finder application. 4.3.2 Open Web Browser Open a web browser on your PC and enter the PRORXD IP address in the address bar.

  • Page 22: Web Browser Operation

    The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 5-16 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.

  • Page 23: Status>Input Tab

    The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 5-17 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.

  • Page 24: Status>Service Tab

    The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 5-18 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.

  • Page 25: Global Settings Tab

    The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 5-19 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
  • Page 26 If you selected Manual from the Preset setting, you will need to enter an LO frequency in MHz. If it is a DTC downconverter which is not included in the preset list, you may find this detail in Section 6.3.
  • Page 27 The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 5-21 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
  • Page 28 The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 5-22 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
  • Page 29 The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 5-23 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
  • Page 30 The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 5-24 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.

  • Page 31: Configuration Tab

    The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 5-25 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
  • Page 32 The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 5-26 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
  • Page 33 The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 5-27 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
  • Page 34 The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 5-28 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
  • Page 35 The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 5-29 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
  • Page 36 The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 5-30 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
  • Page 37 The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 5-31 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
  • Page 38 The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 5-32 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.

  • Page 39: Log Tab

    PRORXD to let you operate it. DTC will make a new license file which we will send to you, save this file to a convenient location on your PC. Check that the middle part of the license file matches the serial number displayed in the Information tab.

  • Page 40: Frequency Tab

    5.9.2 Upgrade your PRORXD When a new software release is available for the PRORXD, DTC will make it available on our WatchDox facility. See Section 8.1. The upgrade is provided as a single file or two files which need to be uploaded in sequence. The single file can be used for upgrades of software v2.2.0 onwards, but if the software is v2.1.1 or earlier use the two...

  • Page 41: Information Tab

    The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 5-35 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.

  • Page 42: Snmp Tab

    Commercial in Confidence Revision 12.1 5.12 SNMP Tab You can upload SNMP MIBs data from this tab. If this is a requirement, please contact DTC Technical Support. The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd.

  • Page 43: Appendix A - Reference Material

    The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 6-37 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.

  • Page 44: Pinouts - Prorxd-2Ru

    The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 6-38 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
  • Page 45 The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 6-39 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.

  • Page 46: Downconverter Data

    The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 6-40 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.

  • Page 47: Single Channel Sensitivity

    The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 6-41 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.

  • Page 48: Appendix B - Remote Control Guide

    The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 7-42 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.

  • Page 49: About The Programming Model

    The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 7-43 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
  • Page 50 The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 7-44 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.

  • Page 51: Appendix C - Getting Technical Support

    We undertake to get a first response to you in less than one working day and a progress update at least every two weeks. Using the DTC RMA Service If there is a problem and all troubleshooting steps have been unsuccessful, you may need to contact DTC for Return Material Authorisation (RMA) service. 8.1.1 Step 1: Email DTC To return something to Solent please Email solent.customerhub@domotactical.com.
  • Page 52 The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 8-46 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.

  • Page 53: Appendix D - Safety And Maintenance

    The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 9-47 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.

  • Page 54: Repairs And Alterations

    The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 9-48 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.

  • Page 55: Cleaning

    The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 9-49 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.

  • Page 56: Appendix E - Glossary

    The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 10-50 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
  • Page 57 The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 10-51 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
  • Page 58 The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 10-52 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
  • Page 59 The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 10-53 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.
  • Page 60 The information contained in this document is the property of Domo Tactical Communications (DTC) Ltd. Page 10-54 Any copying or reproduction in any form whatsoever is prohibited without the written permission of DTC. © 2014-2019 Copyright Domo Tactical Communications (DTC) Limited. All rights reserved.

This manual is also suitable for:

Prorxd-1ruProrxd-2ruPr0rxd-2-1ruPr0rxd-4-1ruProrxd-2-2ruPr0rxd-4-2ru ... Show all
