Mounting the UCLEAR Pulse Pro
Dual MEMS microphones in Full
Face, Modular, and ¾ Helmets:
Remove the helmet headliner from
the front/brim.
Using the included small hook &
loop mic mounting rounds, or tape,
mount the Pro-Microphones under
the liner in the brim of the helmet.
Typically, this brim material is
perforated and unpadded. Avoid
placing the microphones inside air
vent channels.
Tuck excess wire under the
headliner and refit your headliner
over the microphones. When
headliner and padding is replaced,
none of the microphones or wires
should be visible.
UCLEAR Pro Microphones Placement
Microphone Mounts
UCLEAR Pulse
Pro Dual
MEMS
Microphones
and Speakers
Place wide, near outside edges
of eyebrows near temple.
Tuck excess wire under liner.
Advertisement
Summary of Contents for Uclear Pulse Pro Dual MEMS
- Page 1 Mounting the UCLEAR Pulse Pro Dual MEMS microphones in Full Face, Modular, and ¾ Helmets: Remove the helmet headliner from the front/brim. Place wide, near outside edges Using the included small hook & of eyebrows near temple. loop mic mounting rounds, or tape, Tuck excess wire under liner.
- Page 2 UCLEAR Pulse Pro Dual MEMS Pro Microphones in Schuberth C3 Pro or Touratech Aventuro Helmets: Another good example for the perfect UCLEAR Pulse Pro microphone location in a Schuberth modular (flip front) helmet (similar helmet: Touratech Aventuro) After removing the mesh layer of the inner liner, both microphones can be mounted invisible below the mesh and won’t disturb while putting the helmet on/off or...
- Page 3 Tuck wires behind cheek pads. Avoid placing the microphones directly over or behind any air vents. Microphone Mounts UCLEAR Pulse Pro Dual MEMS Microphones / Speaker Set...
