TPAD10M RFID Pad Reader
◆
Before you use this product, please carefully read this manual, and properly keep
it for future reference.
◆
As our products continue improving, they may be changed without advanced
notice.
◆
The contents of this manual have been carefully checked. For any printing error or
misunderstanding content, please contact us as soon as possible.
User Manual
Version: V1.00
Advertisement
Table of Contents
Summary of Contents for Andea Electronics TPAD10M
- Page 1 TPAD10M RFID Pad Reader User Manual ◆ Before you use this product, please carefully read this manual, and properly keep it for future reference. ◆ As our products continue improving, they may be changed without advanced notice. ◆ The contents of this manual have been carefully checked. For any printing error or misunderstanding content, please contact us as soon as possible.
-
Page 2: Table Of Contents
User Manual Contents Product Overview ................1 1.1. Product Introduction ..............1 1.2. Product Features ................1 1.3. Pictures ..................1 1.4. Main Parameter ................2 Product Structure ................. 3 2.1. Product Appearance ..............3 2.2. Product Dimensions ..............4 2.3. -
Page 3: Product Overview
1. Product Overview 1.1. Product Introduction TPAD10M is a RFID reader-writer machine that is specially designed for self-checkout and check-in, book sorter and production lines. It has the super anti-interference ability of reading and writing. The product uses a metal shielding design, so they can be installed in metal environment and not affected by the metal at the bottom and around. -
Page 4: Main Parameter
379.5*290*20.7mm Maximum Operating 50℃ Temperature ① Dimensions are approximate. For specific dimension, please refer to the real object; ② As our products continue improving, technical parameters may be changed without advanced notice. Guangzhou Andea Electronics Technology Co., Ltd. 2/16 http://www.gzandea.com... -
Page 5: Product Structure
User manual 2. Product Structure 2.1. Product Appearance Figure 1 Product appearance description Table 2 Product appearance description Description ① Power switch ② USB interface ③ LED indicator ④ Sensing area Guangzhou Andea Electronics Technology Co., Ltd. 3/16 http://www.gzandea.com... -
Page 6: Product Dimensions
Communication interface of the device adopts USB interface, and it can connect directly through the computer USB interface. as shown below: Figure 3 USB communication interface 2.5. Power Switch This device is equipped with a power switch button , as shown below: Guangzhou Andea Electronics Technology Co., Ltd. 4/16 http://www.gzandea.com... -
Page 7: Device Connection
The device is connected to the PC via a USB communication interface, and power is supplied via USB without additional power supply: Figure 5 Connect via the device's own USB cable 4. Description Of Indicator Light Figure 6 Indicator light Guangzhou Andea Electronics Technology Co., Ltd. 5/16 http://www.gzandea.com... -
Page 8: Instructions Of Configuration Tools
Double-click the file to open the test tool, as shown below: Figure 7 R-Tool connection interface Select the corresponding communication method according to the actual interface type used by the device. Guangzhou Andea Electronics Technology Co., Ltd. 6/16 http://www.gzandea.com... -
Page 9: Configuration Description Of Parameters
RF parameters, inventory parameters, working mode and other parameters of the device: Note: All changed configuration parameters must be saved by clicking [Write] button and then clicking [Save] button. Otherwise, the setting is invalid. Guangzhou Andea Electronics Technology Co., Ltd. 7/16 http://www.gzandea.com... -
Page 10: Communication Interface
Figure 9 Parameter configuration interface 5.1.1. Communication Interface Figure 10 Configuration interface for communication interface ⚫ Bus address: between 1-255 ⚫ Baud Rate: 9600, 19200, 38400, 57600, 115200, 230400 ⚫ Parity check type: None, Odd, Even Guangzhou Andea Electronics Technology Co., Ltd. 8/16 http://www.gzandea.com... -
Page 11: Buzzer Default Parameters
1)Auto close RF when RF is free for specified time：In the host control mode, the device will automatically close the RF if it does not receive a command of card reading or opening the RF. Guangzhou Andea Electronics Technology Co., Ltd. 9/16 http://www.gzandea.com... -
Page 12: Inventory Parameters
Otherwise, it is ASK 100%. 4) ASK modulation depth: 0.5% -60% ⚫ ISO18000p3m3 1)M: Manchester 2,Manchester 4 2) DR:FC/16847khz, FC/32424khz 3) Modulation depth:0.5%-29% 5.1.4. Inventory Parameters Figure 13 Configuration interface for inventory parameters Guangzhou Andea Electronics Technology Co., Ltd. 10/16 http://www.gzandea.com... - Page 13 4) Min dynamic Q: set the minimum dynamic Q value. 5) Max dynamic Q: set the maximum dynamic Q value. ⚫ ISO14443B 1) AFI: 00-FF.Note: 00 means not to enable. 2) Slot Number: 1,2,4,8,16. Guangzhou Andea Electronics Technology Co., Ltd. 11/16 http://www.gzandea.com...
-
Page 14: System Work Mode
② Output block’s data: output the content of the data block (not including the security status byte). ③ Output format of block’s data: A. Format as hex string. B. Format as ASCII. Guangzhou Andea Electronics Technology Co., Ltd. 12/16 http://www.gzandea.com... -
Page 15: Testing
After entering the main interface of R-Tool test software, select "ISO Multi-Tag Test" ,carry out the procedure as shown in the following figure ①, ② and ③ for tags inventory test: Figure 15 Multi-Tag inventory test steps Guangzhou Andea Electronics Technology Co., Ltd. 13/16 http://www.gzandea.com... -
Page 16: Single Tag Operation Testing
Step 5: 1) For a single tag: click the "Connect" button; 2) For multiple tags: in UID drop-down box, select the tags required to be operated, and then click the "Connect" button; Guangzhou Andea Electronics Technology Co., Ltd. 14/16 http://www.gzandea.com... -
Page 17: Technical Support
4) After the operation is completed, click the [Disconnect] button to disconnect the tag connection. 6. Technical Support ➢ Download link for development data and testing https://www.gzandea.com/download.php ➢ Call for equipment debugging and technical support Mobile phone: 138 0251 4535 Fixed telephone: 0086-20-32039552 Guangzhou Andea Electronics Technology Co., Ltd. 15/16 http://www.gzandea.com... - Page 18 -- Increase the separation between the equipment and receiver. -- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -- Consult the dealer or an experienced radio/TV technician for help. Guangzhou Andea Electronics Technology Co., Ltd. 16/16 http://www.gzandea.com...
- Page 19 Guangzhou Andea Electronics Technology Co., Ltd. Address: Room 401, Building H, Jingye San Street, Yushu Industrial Park, Economic And Technological Development Zone, Guangzhou. Zip code: 510663 Phone: 0086-20-32039550, 32039551, 32039552 Fax: 0086-20-32039553 Website: http://www.gzandea.com...
