JASON Hydrotherapy HSC650 Owner's Manual

" T O B e r e M O V e D F O r u s e B Y T H e O C C u P a n T "
Jason International, Inc.
8328 MacArthur Drive
North Little Rock, AR 72118
www.jasoninternational.com
InsTallaTIOn, OPeraTIOn, anD MaInTenanCe
If the carton shows sign of damage, inspect
the product before accepting and describe the
problem on the Bill of lading.
InsPeCTIOn
Inspect the unit prior to installation. In the event of a
problem, DO NOT install the unit.
All components are factory assembled to the bath and the
unit is water tested and inspected prior to leaving Jason
International, Inc.
If the carton shows sign of damage, inspect the product
before accepting and describe the problem on the Bill of
Lading.
NOTe: Transportation and insurance from Jason's
factory are the buyer's responsibility.
Damage sustained in transit is the responsibility of the
carrier. If damage is discovered,
The carrier must be immediately notified in writing with a
request for a representative to inspect the unit. Failure of
the carrier to respond should be reported to the seller and
carrier. Always file a freight claim promptly.
The installer is responsible for insuring that the unit is
free from defects or shipping damage. In the event of a
problem, DO NOT install the unit.
Jason International is not responsible for damage that
might have been avoided by inspection or testing prior to
installation.
Owner's reCOrD
Dealer:
Date Purchased:
Date Installed:
Installer:
Jason International, Inc. • 501.771.4477
Owner's Manual
Home spa
Damage to the unit during installation will not be covered
by warranty and is the responsibility of the installer. ALL
WARRANTY CLAIMS ON ACRYLIC SURFACE DAMAGE
MUST BE MADE PRIOR TO INSTALLATION. Inspect
plumbing and bath surface for missing or damaged
components. Alert your dealer of any discrepancies.
To protect the unit from damage keep the bath in the
carton until ready for installation.
eQuIPMenT aCCess
In accordance with Building Codes, service access to all
therapy bath equipment, controls, and electrical connections
must be provided during installation (See Table 1 -
Specifications for minimum access size). Access must be
provided for both the pump/control and the blower/control.
Insufficient access will hinder repair and maintenance.
Warranty service will not cover cost of providing equipment
access.
Model
HSC650 (Round)
HSR6555
Page 1 of 16
Table 1 - Specifications
HomeSpa COLLECTION (Air Whirpool Bath)
Operating
Overall Dimensions Blower Pump
Capacity
L x W x H (in.) Gallons
HP
L x W x H (cm) Liters
78 x 78 x 28 90/170
1
198 x 198 x 71 341/643
78 x 66 x 28 80/160
1
198 x 168 x 71 303/606
PlaCe serIal nuMBer CarD wITH
PrODuCT COnFIguraTIOn In THIs BOx
Customer Service : 800.255.5766
Copyright © 2014 Jason International.
49-1014-301
Date 05/2014
Min. Size Floor
Access Loading
W x H (in.) lbs/ft2
HP
W x H (cm) kg/M2
36 x 17 in 70.9
1.5
91 x 43 cm 346
36 x 17 in 64.6
1.5
91 x 43 cm 315
