Summary of Contents for FWE PTS-0709-135-B
- Page 1 OPERATING INSTRUCTIONS PTS BACK HEAT BOX Prisoner Tray Server with Removable Back Heat Box Module...
- Page 2 FWE PTS SERVER BACK HEAT BOX PTS-0709-135-B CONGRATULATIONS..and thank you for purchasing an FWE PTS with Removable Back Heat Box Module. Your unit has been designed and manufactured under rigid controls to assure you the most efficient service. Please take a moment to read through this booklet of important information pertaining to your cabinet.
- Page 3 FWE PTS SERVER BACK HEAT BOX Heat Box Security Lock Power Indicator Light ON / OFF Switch Handle Grip...
-
Page 4: Installation And Care
ELECTRICAL REQUIREMENTS AND GROUNDING FWE Removable Back Heat Module or models operate on 120 volt or 220-240 volt, 60 Hz, 1 ph, A.C. (unless ordered otherwise), and are equipped with a three prong grounding cord plug for your protection against possible shock hazards. - Page 5 FWE PTS SERVER BACK HEAT BOX INSTALLATION AND CARE CLEANING Keep your cabinet clean by simply wiping the interior and exterior, as needed, with a damp cloth or sponge and a mild soapy solution. NEVER USE ABRASIVES, ACIDS, OR STRONG CLEANERS. Do not flood or allow electrical parts to become wet.
- Page 6 FWE PTS SERVER BACK HEAT BOX GENERAL OPERATING INSTRUCTIONS 1) PLUG UNIT INTO OUTLET, making sure that it is a properly grounded power receptacle. Press ON-OFF rocker switch to "ON" position. Power indicator light will be on. 2) TEMPERATURE SETTING. Pre-set by factory at #7 on temperature dial.
-
Page 7: Parts List
PARTS LIST FWE PARTS DEPARTMENT: 815 459 7500 DESCRIPTION PART NUMBER MECHANICAL PARTS: Casters for PTS-0709-135-B 10'' Rigid CSTR 10 R-6 10'' Swivel CSTR 10 S-6 10'' Swivel with locking brake CSTR 10 SB-6 Locking Paddle Latch LTH PDL LK... - Page 8 FWE PTS SERVER BACK HEAT BOX WIRING DIAGRAM: 120 V 120 V 150°F PLT LT (N.O.) 500°F (N.C.) COIL T-STAT 120-250°F (N.O.) BLOWER MOTOR COOLING FAN...
- Page 9 FWE PTS SERVER BACK HEAT BOX WIRING DIAGRAM: 220 - 240 V 220 - 240 V 150°F PLT LT (N.O.) 500°F (N.C.) T-STAT 120-250°F BLOWER MOTOR COOLING FAN...
- Page 10 FWE PTS SERVER BACK HEAT BOX SERVICE RECORD Model Number ______________________ Serial Number ______________________ Date of Purchase ____________________ Notes: ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________ ___________________________________________________...
-
Page 11: Limited Warranty
FWE PTS SERVER BACK HEAT BOX LIMITED WARRANTY FWE / Food Warming Equipment Company, Inc. (Seller) warrants to the original purchaser, subject to the exceptions and conditions below, that FWE manufactured equipment shall be free from defects in material or factory workmanship, under ordinary use for the purpose for which it is designed. - Page 12 Food Warming Equipment Company, Inc. P.O. Box 1001 Crystal Lake, IL 60039-1001 Manufacturing Facilities: 7900 S. Route 31 Crystal Lake, IL 60014 FWE Parts Department: FAX: All rights reserved. 815 459 7500 815 459 7989 Subject to change without notice.
