AIR NEEDLE SCALER
This product contains or, when used, produces a chemical
known to the State of California to cause cancer and birth
defects or other reproductive harm.
(California Health & Safety Code § 25249.5, et seq.)
Please carefully read and save these instructions before attempting to assemble, maintain, install, or operate this product.
Observe all safety information to protect yourself and others. Failure to observe the instructions may result in property
damage and/or personal injury. Please keep instructions for future reference.
For warranty purchases, please keep your dated proof of purchase. File or attach to the manual for safe keeping.
For Customer Service, Call 1-800-348-5004
or e-mail customerservice@focus-ontools.com
WARNING
*Actual product may vary slightly
40806
05/2017
Advertisement
Table of Contents
Summary of Contents for Steel Core 40806
- Page 1 Observe all safety information to protect yourself and others. Failure to observe the instructions may result in property damage and/or personal injury. Please keep instructions for future reference. For warranty purchases, please keep your dated proof of purchase. File or attach to the manual for safe keeping. For Customer Service, Call 1-800-348-5004 40806 05/2017 or e-mail customerservice@focus-ontools.com...
-
Page 2: Instructions Pertaining To A Risk Of Fire, Electric Shock, Or Injury To Persons
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS WARNING: When using tools, basic precautions should always be followed, including the following: GENERAL To reduce the risks of electric shock, fire, and injury to persons, read all the instructions before using the tool. WORK AREA 1. -
Page 3: Specifications
SPECIFICATIONS Stroke 1/2″ Blows per minute 4000 Overall Length 18″ Average Air Consumption 10 CFM @ 90 PSI Air Inlet 1/4″ -18 NPT Throttle Driver Retainer Air Inlet Housing Needle Tube Needle Holder Needles ASSEMBLY 1. During shipment, some Needles may fall out of the Needle Holder. If so, remove the Needle Holder (26), Needles (25), and Spring (27) from the Needle Tube (28). -
Page 4: Tool Setup
TOOL SETUP TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION: Turn off the tool, detach the air supply, safely discharge any residual air pressure in the tool, and release the Throttle before performing any inspection, maintenance, or cleaning procedures. TO PREVENT SERIOUS INJURY: Do not adjust or tamper with any control or component in a way not specifically explained within this manual. - Page 5 GENERAL OPERATING INSTRUCTIONS 1. If an automatic oiler is not used, add a few drops of Pneumatic Tool Oil to the airline connection before use. Add a few drops more after each hour of continual use. 2. Grip the Air Needle Scaler with both hands. Place one hand on the Needle Tube and the other hand on the Barrel for best control.
-
Page 6: Parts List
PARTS LIST Part Description Part Description Air Inlet Piston O-Ring Cylinder O-Ring Clamping Chuck Valve Stem Flat Key 3X12 Spring Housing O-Ring Cushion Pad Lock Screw Position Block Trigger Banding Ring Rear Housing Hammer Clamp Nut Needle Washer Needle Holder Rear End Plate Spring Idler Pin... - Page 7 Limited Manufacturer Warranty FOT makes every effort to ensure that this product meets high quality and durability standards. FOT warrants to the original retail consumer a 1-year limited warranty from the date the product was purchased at retail and each product is free from defects in materials.
