Samsung YP-N30 Quick Manual

Quick-N30 2/14/04 1:29 PM
YP-N30 Quick Guide

Location of Controls

Neck strap Hook
Earphone Jack
Microphone
Display
Voice Recording Button

Playing Music

When you press the button, the yepp logo appears and a music/voice file is played.
Stopping Music
When you press the button while playing, the music stops. If no buttons are pressed
within 5 seconds (changes depending on settings), the yepp automatically powers off.
1
Page 2
Play/Stop/Pause/Forward/Backward
Button
Volume
Hold Switch
USB Cable Connection Port
MENU/Loop Repeating Button
Connecting the USB cable
Before connecting yepp to PC, make sure to install USB driver.
1
Plug one end of the USB cable into the USB port
on the PC.
2
Insert the battery into the yepp and turn on the
power.
3
Slide down the bottom cover of the player.
Plug the other end of the USB cable
into the USB port on the right side at the bottom.
If you disconnect the USB cable from your PC while
implementing a command or initializing during USB driver
installation, your PC may not function correctly.
4
USB driver is installed with a message saying that
it is searching for a new device. You may not see
the display screen during installation. Go to the
device manager to check that installation has
been successfully completed.
5
When USB driver is installed, "SAMSUNG YP-
N30" will appear in [System Properties]
[Device Manager]
2
