Yardline SANTA CLARA Assembly Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

16950
STOP!
STOP!
Call Us First!
DO NOT RETURN TO STORE.
For immediate help with assembly or product information
call our toll free number:
1-800-844-9273
or email:
customerservice@yardline.net
Our staff is ready to provide assistance
April through October M-F 8:00 AM to 4:30 PM EST
Saturday 8:30 AM to 4:30 PM EST
November through March M - F 8:00 AM to 5:00 PM EST

Advertisement

Table of Contents
loading

Summary of Contents for Yardline SANTA CLARA

  • Page 1 For immediate help with assembly or product information call our toll free number: 1-800-844-9273 or email: customerservice@yardline.net Our staff is ready to provide assistance April through October M-F 8:00 AM to 4:30 PM EST Saturday 8:30 AM to 4:30 PM EST...
  • Page 2 (This page intentionally left blank.)
  • Page 3 16950 05/15/2019 ASSEMBLY MANUAL SANTA CLARA 12' x 7'-6" (365,8 x 228,6 cm) ACTUAL FLOOR SIZE IS 144" x 90" (365,8 x 228,6 cm) KEEP THIS MANUAL FOR FUTURE REFERENCE IM P O RTANT ! READ INSTRUCTIONS THOROUGHLY PRIOR TO BEGINNING ASSEMBLY. BEFORE YOU BEGIN • BUILDING RESTRICTIONS AND APPROVALS...
  • Page 4 TOOLS Required Optional Phillips Tool Belt/ Utility Knife Screwdriver Nail Pouch Shingle Blades Drill / Driver Tin Snips 1/4" Drill Bit (for drip edge) Caulk Gun 3/8" Drill Bit 1/2" Drill Bit Pliers #2 Philips Drive Bit Paint Tools Hammer Chalk Line Level Safety Glasses...
  • Page 5 ADDITIONAL MATERIALS FOUNDATION OR FLOOR MATERIALS • This shed kit includes a complete wood floor system. • This shed kit does not include ANY leveling materials. • See the FLOOR LEVELING section on page 8 for recommended methods and suggested materials to properly level your floor, as this will vary depending on your specific site. REINFORCED WOOD FLOOR FRAME (OPTIONAL) IMPORTANT! The included floor has been designed for general use. Depending on your specific use you may want to construct a heavy duty floor frame by adding additional floor joists (shown below).
  • Page 6 PARTS IDENTIFICATION AND SIZES Part identification WOOD SIZE CONVERSION CHART letters are stamped on some parts. Treated lumber is stamped: Nominal Board Size Actual Size 2 x 4 ....1-1/2" x 3-1/2" (3,8 x 8,9 cm) 1 x 4 ....3/4" x 3-1/2" (1,9 x 8,9 cm) 2 x 3 ....1-1/2"...
  • Page 7 PARTS LIST continued... 19/32" x 3-1/2" x 59-1/4" (1,5 x 8,8 x 150,4 cm) 19/32" x 3-1/2" x 60-1/2" (1,5 x 8,8 x 153,7 cm) 19/32" x 3-1/2" x 61-1/16" (1,5 x 8,8 x 155,1 cm) 19/32" x 3-1/2" x 61-1/16" (1,5 x 8,8 x 155,1 cm) 19/32 x 2-1/2 x 67-3/4"...
  • Page 8 WALL PANEL & DOORS PARTS LIST 3/8" x 10-7/16" x 48" (1 x 26,5 x 121,9 cm) 3/8" x 5-1/2" x 48" 3/8" x 48 x 76" 3/8" x 48" x 84" 3/8" x 48" x 84" (1 x 14 x 121,9 cm) (1 x 113,3 x 193 cm) (1 x 122 x 213,4 cm) (1 x 122 x 213,4 cm)
  • Page 9 HARDWARE / WINDOWS / Misc. H 2.5 Tie Plate 1/2" (1,2 cm) 8 x 16" Window (20,3 x 35,6 cm) DOOR HARDWARE #12 2" (5,1 cm) 2" (5,1 cm) 1-1/2" (3,8 cm) Spring Door Bolt Stop 1-1/4" (3,2 cm) #8 3/4" (1,9 cm) 1"...
  • Page 10 FLOOR LEVELING OPTIONS There are multiple ways to level your floor frame. Our recommended leveling method is shown below. Leveling materials are not included in this kit. PREFERRED METHOD - 4x4 TREATED RUNNERS • 3" Screws angled into 4x4. • (2) at each point frame •...
  • Page 11 CONCRETE FOUNDATION Your kit contains all materials to construct a wooden floor. If you choose to install your kit on a concrete slab refer to the diagram below. Treated Sill Plate Caulk between sill plate and concrete. 3-1/2" (8,9 cm) 4" (10,2 cm) Building Size Actual Size 12'x 7'-6" (365,8 x 228,6 cm)
  • Page 12 FLOOR FRAME PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 87" (5,1 x 10,2 x 221 cm) Look for TREATED 2 x 4 x 96" (5,1 x 10,2 x 243,8 cm) Stamp 2 x 4 x 48" (5,1 x 10,2 x 121,9 cm) BEGIN Orient parts as shown on fl at surface.
  • Page 13 LEVEL AND SQUARE FLOOR FRAME Before attaching fl oor decking, it is important to level and square the fl oor frame. A level and square fl oor frame is required to correctly construct your shed. BEGIN See page 8 for the preferred fl oor leveling method. Use level and check the frame is level before applying fl oor panels.
  • Page 14 FLOOR PANELS PARTS REQUIRED: 2" (5,1 cm) 5/8" x 48" x 96" (1,6 x 121,9 x 243,8 cm) BEGIN Attach the 5/8" x 48" x 96" panel with the rough side up (painted-grid lines side) with the 48" edge and corner fl ush to the fl oor frame (Fig A). Secure panel with two 2" nails in the corners.
  • Page 15 FLOOR PANELS PARTS REQUIRED: x123 2" (5,1 cm) 5/8" x 42" x 96" 5/8" x 48" x 90" (1,6 x 106,7 x 243,8 cm) (1,6 x 60,6 x 122 cm) Continue installing panels using 2" nails 6" apart on edges, and 12" apart inside panels. Flush 6"...
  • Page 16 IMPORTANT! Check the floor frame is level after installing floor panels. Re-level if needed. • The floor should be used as a stable work surface for wall construction. • Organize your assembly procedure during the build process HINT: to avoid over-handling of the walls. Back Wall Front Wall...
  • Page 17 BACK WALL FRAME PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 48" (5,1 x 10,2 x 121,9 cm) 2 x 4 x 68" (5,1 x 10,2 x 172,7 cm) 2 x 4 x 96" (5,1 x 10,2 x 243,8 cm) BEGIN Orient parts on edge on floor.
  • Page 18 BACK WALL PANELS PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE 48" x 76" BLOCK (121,9 x 193 cm) • Ensure top of panel is overhanging the top of frame by 4". Place 48" x 76" panel onto wall frame with primed side up as shown. Use the gauge block to mark the 3/4" measurement on the wall stud. Secure panel using 2"...
  • Page 19 BACK WALL PANELS PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE BLOCK 48" x 76" (121,9 x 193 cm) Place center and end 48" x 76" panels For squareness maintain 3/4" on frame as shown (Fig. A, Fig. B). measurement along panel edges. Flush Nail using 2" nails 6" apart on edges 4"...
  • Page 20 FRONT WALL - DOOR HEADER PARTS REQUIRED: 3" (7,6 cm) 7/16" x 3-1/4" x 68-3/4" (1,1 x 8,3 x 174,6 cm) 2 x 4 x 69" (5,1 x 10,2 x 175,3 cm) BEGIN Build header assembly as shown using 3" nails. Flush Flush 3-1/4" x 68-3/4"...
  • Page 21 FRONT WALL FRAME PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 39" (5,1 x 10,2 x 99,1 cm) 2 x 4 x 70-1/2" (5,1 x 10,2 x 179,1 cm) 2 x 4 x 12-1/8" (5,1 x 10,2 x 30,8 cm) 2 x 4 x 72"...
  • Page 22 FRONT WALL FRAME PARTS REQUIRED: Pre-Assembled Door Header 3" (7,6 cm) 4" x 69" (358,1 cm) 2 x 4 x 69" (5,1 x 10,2 x 175,3 cm) Install door header using 3" nails at locations shown. Orient parts PJ on edge as shown. Secure using (2) 3"...
  • Page 23 FRONT WALL PANELS PARTS REQUIRED: 2" (5,1 cm) 3/8" x 48" x 96" (1 x 121,9 x 243,8 cm) Handle panels with care to avoid breakage. BEGIN Install first 48" x 96" panel 5-7/8" above top plate. Secure panel using 2" nails 6" apart along edges and 12" apart on inside of panels. There will be a 5-7/8”...
  • Page 24 FRONT WALL PANELS PARTS REQUIRED: 2" (5,1 cm) 3/8" x 1-1/2" x 9" (0,9 x 3,8 x 22,9 cm) 3/8" x 5-1/2" x 48" 3/8" x 10-7/16" x 48" (1 x 14 x 121,9 cm) (1 x 26,5 x 121,9 cm) Install panels in the following order: 1. 10-7/16" x 48"...
  • Page 25 FRONT WALL PANELS PARTS REQUIRED: 3" (7,6 cm) 2" (5,1 cm) Temporary Brace 2 x 3 x 72" (5,1 x 7,6 x 182,8 cm) 3/8" x 48" x 96" (1 x 121,9 x 243,8 cm) Install 2nd 48" x 96" panel fl ush to frame as shown and 5-7/8" from the top. Secure panel using 2"...
  • Page 26 BACK WALL INSTALLATION PARTS REQUIRED: 3" (7,6 cm) TEMPORARY 2 x 3 x 59-1/4" (5,1 x 7,6 x 150,5 cm) 3" (7,6 cm) 2" (5,1 cm) BEGIN Center back wall assembly on the 144" fl oor dimension. Note: The 4" wall overhang is installed to the top. 4"...
  • Page 27 FRONT WALL INSTALLATION PARTS REQUIRED 3" (7,6 cm) TEMPORARY 2 x 4 x 78-1/16" (5,1 x 10,2 x 198,3 cm) 3" (7,6 cm) 2" (5,1 cm) BEGIN Center front wall assembly on the 144" front fl oor dimension. Use (2) OFB as temporary braces. Level wall and secure OFB using 3"...
  • Page 28 DOUBLER INSTALLATION PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 48" (5,1 x 10,2 x 122 cm) 2 x 4 x 96" (5,1 x 10,2 x 243,8 cm) BEGIN Center doublers SP and TP on back wall top plate. Secure using 3"...
  • Page 29 OUTER RAFTER INSTALLATION PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 92-3/16" (5,1 x 10,2 x 234,2 cm) 2" (5,1 cm) BEGIN Install rafters on front and back wall doublers. Ensure rafters are fl ush to end of top plates (Fig. B, Fig. D). Secure rafters as shown in all Figures.
  • Page 30 OUTER RAFTER INSTALLATION PARTS REQUIRED: H 2.5 Tie Plate 1-1/2" (3,8 cm) Attach tie plates using 1-1/2" nails as shown. 1-1/2" (3,8 cm) Nails FINISH Your outer rafters are now installed.
  • Page 31 RAFTERS PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 92-3/16" (5,1 x 10,2 x 234,2 cm) 2" (5,1 cm) BEGIN Measure and mark location of each rafter. Note the door location. Center rafters on marks. Secure rafters using 2" screws installed centered into outer rafter ends (Fig. A). Continue securing rafters using 3"...
  • Page 32 RAFTERS PARTS REQUIRED: H 2.5 Tie Plate 1-1/2" (3,8 cm) Attach (9) tie plates using 1-1/2" nails as shown (Fig. A). Fig. A 1-1/2" (3,8 cm) Nails FINISH Your rafters are now installed.
  • Page 33 SIDE WALL PANELS PARTS REQUIRED: 3" (7,6 cm) TEMPORARY SUPPORT 1-1/4 x 2-1/2 x 69" (3,2 x 6,3 x 175,3 cm) 2" (5,1 cm) 1-1/2" (3,8 cm) 3/8" x 42" x 96" 3/8" x 42" x 96" 3/8" x 48" x 84" 3/8"...
  • Page 34 SIDE WALL PANELS PARTS REQUIRED: 1-1/2" (3,8 cm) 2" (5,1 cm) Place 48" x 84" panel onto side wall flush with bottom of installed 42" x 96" panel. Secure panel using (1) 2" nail in bottom corner (Fig. C). Ensure the measurement between the panel edges are the same along the corner (Fig. F).
  • Page 35 SIDE WALL STUDS PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 78-1/16" (5,1 x 10,2 x 198,3 cm) 2 x 4 x 82-1/2" (5,1 x 10,2 x 209,6 cm) 2 x 4 x 86-15/16" (5,1 x 10,2 x 220,8 cm) BEGIN Install NES centered at seam of side wall panels (Fig A).
  • Page 36 SIDE WALL PANELS PARTS REQUIRED: 1-1/2" (3,8 cm) (Left / Green) (Right / Red) 3/8" x 2-11/16" x 12-1/4" (1,5 x 6,8 x 31,1 cm) 3/8" x 2-11/16" x 12-1/4" (1,5 x 6,8 x 31,1 cm) BEGIN Install 2-11/16" x 12-1/4" triangular fi ller panel using (2) 1-1/2" nails. Flush fi ller panel to installed panels (Red for right side) as shown.
  • Page 37 ROOF PANELS PARTS REQUIRED: 2" (5,1 cm) 7/16 x 10-11/16 x 28" (1,1 x 27,1 x 71,1 cm) 7/16 x 10-11/16 x 96" 3/4" GAUGE (1,1 x 27,1 x 243,8 cm) 7/16 x 10-11/16 x 31-7/8" BLOCK (1,1 x 27,1 x 81 cm) Roof panels may cause serious injury until securely fastened.
  • Page 38 ROOF PANELS PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE 7/16" x 48 x 96" BLOCK (1,1 x 121,9 x 243,8 cm) Square the roof by attaching one 48" x 96" panel at this time. Use the panel's long edge as a lever to bring your roof into square. Place the 48"...
  • Page 39 ROOF PANELS PARTS REQUIRED: 2" (5,1 cm) 3/4" GAUGE 7/16" x 48" x 96" BLOCK 7/16" x 11-7/8" x 96" (1,1 x 121,9 x 243,8 cm) (1,1 x 30,2 x 243,8 cm) Install 2nd 48"x 96" panel flush to installed panels. Maintain 3/4"...
  • Page 40 ROOF PANELS PARTS REQUIRED: x160 2" (5,1 cm) Complete the securing of all upper roof panels using 2" nails 6" along edge and 12" inside panel. 6" (15,2 cm) FINISH Your roof panels are now installed.
  • Page 41 RAFTER EXTENSIONS PARTS REQUIRED: 2" (5,1 cm) 2 x 3 x 10-7/16" (5,1 x 7,6 x 26,5 cm) BEGIN Line up each rafter extension QVA 90 degrees square with rafters as shown. Attach rafter extensions using 2" screws through roof panels (Fig. A). Use (4) screws at roof panel seams.
  • Page 42 SIDE RAKE FRAMING PARTS REQUIRED: 2" (5,1 cm) 1 x 3 x 31-15/16" (2,5 x 7,6 x 81,1 cm) 1 x 3 x 72" (2,5 x 7,6 x 182,8 cm) BEGIN Align THB edge fl ush with rafter extension (Fig A). Attach using (3) 2" nails (Fig B). Attach HJ fl ush with THB using (5) 2"...
  • Page 43 SIDE SOFFIT PARTS REQUIRED: 2" (5,1 cm) 3/8" x 5-1/4" x 94-7/16" (1 x 13,3 x 242,5 cm) BEGIN Attach 94-7/16" soffi t primed side down fl ush to front wall panel (Fig. A). Secure to side rake frame THB using (7) 2" fi nish nails (Fig. A, B). Fig.
  • Page 44 FRONT SOFFIT PARTS REQUIRED: 2" (5,1 cm) 3/8" x 10-3/8" x 75-5/8" (1 x 26,3 x 191,2 cm) 3/8" x 10-3/8" x 79-5/8" (1 x 26,3 x 202,2 cm) BEGIN Install 75-5/8" and 79-5/8" soffi t panel primed side out under rafter extensions and fl ush to side wall soffi t (Fig. A).
  • Page 45 FRONT FASCIA TRIM PARTS REQUIRED: 2" (5,1 cm) 19/32" x 3-1/2" x 60-1/2" (1,5 x 8,8 x 153,7 cm) BEGIN Measure 1/4" past left roof panel and line up WAB primed side out and flush up under roof panels (Fig. A). Right side of WAB is approximately 3/4" from center of rafter extension. Secure WAB using 2"...
  • Page 46 FRONT FASCIA TRIM PARTS REQUIRED: 2" (5,1 cm) 19/32" x 3-1/2" x 96" (1,5 x 8,8 x 243,8 cm) Position ZX primed side out, fl ush with WAB and fl ush up under roof panels. Secure ZX using 2" fi nish nails into rafter extensions (Fig. B). 2"...
  • Page 47 SIDE FASCIA TRIM ASSEMBLY PARTS REQUIRED: 2" (5,1 cm) 2 x 3 x 31-15/16" (5,1 x 7,6 x 81,1 cm) 19/32" x 3-1/2" x 61-1/16" (1,5 x 8,9 x 155,1 cm) 19/32" x 3-1/2" x 45" (1,5 x 8,9 x 114,3 cm) 19/32"...
  • Page 48 SIDE FASCIA TRIM PARTS REQUIRED: 2" (5,1 cm) 2" (5,1 cm) LEFT FASCIA ASSEMBLY BEGIN Place left side fascia assembly between roof sheathing and side soffit (Fig. A, Fig. B). Secure fascia assembly under roof panels flush with front fascia board using (6) 2" screws through roof sheathing (Fig. A).
  • Page 49 SIDE FASCIA TRIM PARTS REQUIRED: 2" (5,1 cm) RIGHT FASCIA ASSEMBLY Nail up through side soffi t into fascia assembly using (7) 2" fi nish nails (Fig. C). Nail front fascia to side fascia using (2) 2" fi nished nails (Fig. D). 2"...
  • Page 50 REAR FASCIA TRIM PARTS REQUIRED: 3" (7,6 cm) 2 x 3 x 59-1/4" (5,1 x 7,6 x 150,5 cm) 2" (5,1 cm) 2 x 3 x 96" (5,1 x 7,6 x 243,8 cm) BEGIN Install PT and GKA using 2" wood screws through roof sheathing (Fig. A). 2"...
  • Page 51 REAR FASCIA TRIM PARTS REQUIRED: 2" (5,1 cm) 19/32" x 3-1/2" x 59-1/4" (1,5 x 8,8 x 150,5 cm) 19/32" x 3-1/2" x 96" (1,5 x 8,8 x 243,8 cm) Nail HBA and ZX to PT and GKA using 2" fi nish nails (Fig. C). Ensure trim is primed side out.
  • Page 52 BACK CORNER TRIM PARTS REQUIRED: 2" (5,1 cm) 3/8" x 2" x 73-5/16" (0,9 x 5,1 x 186,2 cm) ¸ BEGIN Place 73-5/16" back corner trim fl ush to bottom of back soffi t board (Fig. A) and fl ush with side panel (Fig. B). Secure trim using (14) 2"...
  • Page 53 SIDE CORNER TRIM PARTS REQUIRED: 2" (5,1 cm) 3/8" x 2" x 73-7/16" (0,9 x 5,1 x 186,5 cm) 3/8" x 2" x 73-7/16" (0,9 x 5,1 x 186,5 cm) 3/8" x 2" x 93-1/8" (0,9 x 5,1 x 236,5 cm) 3/8"...
  • Page 54 FRONT TRIM PARTS REQUIRED: 2" (5,1 cm) 19/32" x 2-1/2" x 72-3/4" (1,5 x 6,3 x 184,8 cm) 19/32" x 2-1/2" x 90-5/8" (1,5 x 6,3 x 230,2 cm) ¸ BEGIN Install (2) ZD trim pieces centered and fl ush up to soffi t. Secure trim using (14) 2"...
  • Page 55 FRONT WINDOWS PARTS REQUIRED: 3/4" (1,9 cm) ¸ BEGIN Apply high quality exterior-grade caulk behind frame near edge before installing to seal window. You must caulk around windows to validate warranty. Position window in center of opening and level. Secure using (4) screws on sides of each window. (4) 3/4" (1,9 cm) Screws per window...
  • Page 56 FRONT WINDOW TRIM PARTS REQUIRED: 2" (5,1 cm) 19/32" x 2-1/2" x 9" (1,5 x 6,4 x 22,9 cm) 19/32" x 5-1/2" x 70-1/4" (1,5 x 14 x 178,4 cm) Install (2) CMB centered on front wall panels. Flush bottom of CMB flush to bottom of panel across door opening. Secure using (18) 2"...
  • Page 57 FRONT WINDOW TRIM PARTS REQUIRED: 3/4" (1,9 cm) 19/32" x 2-1/2" x 58-3/4" (1,5 x 6,3 x 149,2 cm) Install (2) TTB on window trim, centered as shown. Secure using (6) 2" fi nish nails. 2" (5,1 cm) Finish Nails Nail into FRAMING Flush CENTER...
  • Page 58 DOOR TRIM &THRESHOLD PARTS REQUIRED: 2" (5,1 cm) 64" Metal Threshold 19/32 x 2-1/2 x 67-3/4" (1,5 x 6,3 x 172,1 cm) 3/4" (1,9 cm) x11 Bagged separately / special coating ¸ BEGIN Install TJB flush to lower window trim and flush to front panels. Secure trim using 2"...
  • Page 59 DOOR TRACK PARTS REQUIRED: 1/8" BIT 5/16" x 2" (3 mm) (8m x 5,1 cm) ¸ BEGIN Install right door track first. Place right track brackets flush along top of lower window trim and flush to right corner trim. Mark bracket-hole locations on window trim. Pre-drill holes using a 1/8" drill bit. Secure track using (4) 2"...
  • Page 60 DOOR REINFORCEMENT PARTS REQUIRED: 3/4" (1,9 cm) ¸ BEGIN Reinforce doors by back-screwing through inside of door panel into trim. Use (20) 3/4" screws in each door, according to pattern shown. Space screws evenly.
  • Page 61 DOOR HARDWARE PARTS REQUIRED: Metal Rain Channel 3/4" (1,9 cm) 1" x 1" x 36" (2,5 x 2,5 x 91,4 cm) Orient doors with these grooves facing outward. ¸ BEGIN Install 36" rain channel flush to end centered across upper corner of door. Secure using 3/4"...
  • Page 62 DOOR HARDWARE PARTS REQUIRED: #8 X 3/4" (1,9 cm) Self-Piercing 36" (91,4 cm) Door Brush Channel 36" (91,4 cm) Door Brush Round Head Screws ¸ BEGIN Assemble (2) 36" door brushes as shown: Slide door brush into channel (Fig. A). Crimp each end of channel (Fig. B). Fig.
  • Page 63 DOOR TROLLEYS PARTS REQUIRED: 1" (2,5 cm) Orient doors with these grooves facing outward. ¸ BEGIN Install (2) rolling door trolleys to inside top of each door using screws supplied in rolling door hardware bag. Position as shown. INSIDE OF DOOR 4-1/4"...
  • Page 64 DOOR INSTALLATION PARTS REQUIRED: BEGIN Slide right and left door into track as shown (Fig. A). Fig. A NOTE: Install doors into track slowly to prevent damage to rain channel.
  • Page 65 WEATHERSTRIP PARTS REQUIRED: Weatherstrip Roll BEGIN Peel adhesive backing from weatherstrip and install to inside of left door. Weatherstrip should be flush to bottom of over door trim and overhanging 1/2" past edge of door (Fig. A, Fig. B). Flush 1/2" (13 mm) Fig.
  • Page 66 DOOR STIFFENERS PARTS REQUIRED: 2" (5,1 cm) 1-1/4" x 2-1/2" x 69" (3,2 x 6,3 x 175,3 cm) Center each OO vertically on the inside of door between the fl oor and door header (Fig. C) and fl ush to edge of door (Fig. D). From outside, secure OO using (7) 2"...
  • Page 67 DOOR TRIM PARTS REQUIRED: 3/4" (1,9 cm) 19/32" x 2-1/2" x 70-1/8" (1,5 x 6,3 x 178,1 cm) 19/32" x 2-1/2" x 70-1/8" (1,5 x 6,3 x 178,1 cm) BEGIN Install trim TKL and TKR flush into door trim corners, as shown (Fig. A). Secure trim to door from inside using 3/4"...
  • Page 68 DOOR HARDWARE PARTS REQUIRED: 1-1/2" (3,8 cm) 1/8" BIT 2" (5,1 cm) (3,0 mm) ¸ BEGIN Install door handles centered on trim and to measurement shown. Secure handles to door using (4) 2" pan head screws (Fig. A). Pre-drill using a 1/8" drill bit. Refer to latch hardware packaging instructions for installation.
  • Page 69 DOOR HARDWARE PARTS REQUIRED: #12 2" (5,1 cm) ¸ BEGIN Flush the stay roller bracket up underneath the vertical door trim and flush against wall panel (fig. A). Roll the door all the way over the bracket. If the door does not hit the bracket, install bracket using 2"...
  • Page 70 DOOR HARDWARE PARTS REQUIRED: #8 3/4" (1,9 cm) Door Stop ¸ BEGIN Install door stop centered on over door trim seam and flush to bottom of trim as shown. Secure using (4) 3/4" screws. TRIM OVER DOOR SAFETY: Flush Door Stop 3/4" (1,95 cm) must not protrude Screws in doorway...
  • Page 71 DOOR HARDWARE PARTS REQUIRED: #8 X 3/4" (1,9 cm) Self-Piercing Round Head Screws 69-3/4" (177,2 cm) Door Brush Channel 69-3/4" (177,2 cm) Door Brush ¸ BEGIN Assemble (2) 69-3/4" door brushes as shown in STEP - 1, PAGE 59, Fig. A and Fig. B. Install (2) 69-3/4"...
  • Page 72 DOOR HARDWARE PARTS REQUIRED: 1-1/4 (3,2 cm) Spring 3/8" BIT Bolt (2,5 cm) ¸ BEGIN Center spring bolt to inside left door vertical stiffener OO. Flush bottom of spring bolt to bottom of OO (Fig. A). Secure using (4) 1-1/4" screws (Fig. B). Fig.
  • Page 73 VENTS PARTS REQUIRED: 1/2" (1,3 cm) 8 x 16" (20,3 x 35,6 cm) ¸ BEGIN Locate and mark for two vents in both side walls as shown. (1) at top and (1) at bottom Cut out marked openings. Caulk behind vent fl anges. Secure using 1/2"...
  • Page 74 PAINT & CAULK - NOT INCLUDED - • Use acrylic latex caulk that is paintable. Caulk at all horizontal and vertical seams, between the trim and walls, and all around the door trim. • Use a high quality exterior acrylic latex paint. When painting your building, there are a few key areas that can be easily overlooked that must be painted: •...
  • Page 75 DRIP EDGE PARTS REQUIRED: 1" (2,5 cm) Install side drip edge fl ush along roof panels. Flush ends to trim (Fig. A). Secure using 1" roofi ng nails 6" apart. Only nail top of drip edge. Roof Felt Drip Edge Drip Edge OVERLAP Fig.
  • Page 76 SHINGLES - NOT INCLUDED - • Follow directions provided by manufacturer and these instructions. Familiarize yourself with a 3-Tab Shingle. Notch Notch SHINGLE NAIL PATTERN 1/2" 1" Sealing Strip 1" (1,3 cm) (2,5 cm) (2,5 cm) Half A Rain Slot Full Rain Slot NAILS NEVER DRIVE FASTENERS INTO OR ABOVE SEALING STRIPS. ¸ BEGIN Install first starter row upside down, color up and flush to drip edge at bottom of roof panel. Use (4) nails per shingle. Starter row must be straight and level all the way across with lower edge of roof deck.
  • Page 77 SHINGLES continued... Install second row of shingles flush at top of first row's rain slots. Ensure flush to drip edge at front side, stagger each row. DOOR Notch BACK OF SHED Flush with rain slots. Flush with rain slots. 1" (2,5 cm) Continue installing rows of shingles by staggering at front.
  • Page 78 SHINGLES - DRIP EDGE Install drip edge over top shingle row with 1" overhang over roof edge. 1" (2,5 cm) Using your shingle hooked blade carefully cut shingles on a fl at surface along the rain slots, using a chalk line for reference. Align remaining shingles with edge of the front drip edge.
  • Page 79 LIMITED CONDITIONAL WARRANTY* Backyard Storage Solutions, LLC warrants the following: Every product is warranted from defects in workmanship and manufacturing for 1 year. All accessories, hardware and metal components are warranted for 2 years. All Oriented Strand Board (OSB) is warranted for 2 years Siding and Trim is warranted for 15 years.
