Cocoon HE180457 Quick Start Manual

Using the ultimate
smartphone lens kit
1
Using the smartphone lens with selfie light
and clip
1. Inserting your desired lens with the
selfie light
Make sure the light is facing you and push
the lens with thread side first through the
hole in the middle of the light. You should
hear a click when it is in. Make sure that the
end of the lens with the thread is the same
side as the back of the light
2. Connecting your lens and light with
the clip
Put the clip at the back of the light. Position
so that the thread of the lens is in line
with the thread in hole of the clip and wind
together
3. Position the clip over your camera
lens
Align the clip over your camera lens. This
might have to be adjusted to made sure that
the clip isn't covering any of the camera lens
4. Turn on the selfie light
Press the button on the side of the light to
turn it on
5. Start taking photos
Aim the mobile and take the photo or video as normal
Light specification
Input rating: 5V
Battery capacity: 60mAh
2
3
5
500mA
4
7
6
HE180457
PLU: 700257
12/19
1. Telescope
Lens Clip
2. Telescope
Lens
8
3. Universal Lens
Clip
4. Selfie Light
5. Eyecup
6. Fisheye Lens
7. Wide Angle
Lens
8. Macro Lens
1.
2.
3.
