Summary of Contents for C.A.T. JL7 Black Path Edition

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Unpacking Your Amplifier Turning on the Amplifier OptiBias™ Replacing your Power Tubes New Power Tubes NOS Driver Tubes Mechanical Grounding Tube Dampers Power Conditioners Special Power Cords Break In Warm up Use of Output Taps Choice of Output Tap Tube Layout How To Replace the Lamp in the Power Switch Packing up Your Amplifier...

  • Page 3: Unpacking Your Amplifier

    Congratulations on your purchase of the Convergent Audio JL7 A mplifier. Your decision is an indication that you are a dedicated Audiophile, seeking the state of the art in music reproduction. UNPACKING YOUR AMPLIFIER Open the box from the top. Remove the top piece of foam. You will now see a cardboard “cradle”.

  • Page 4: New Power Tubes

    NEW POWER TUBES circuit works best with tubes in the big middle section of the “bell shaped OptiBias™ curve” and so this is what we provide with your amps. This is also what we will provide for you when the time finally comes to replace them. Therefore, we recommend that new power tube sets only be bought from CAT.

  • Page 5: Power Conditioners

    POWER CONDITIONERS CAT amplifiers have built in isolation transformers which already provide tremendous power conditioning. Use of any additional external devices will restrict current delivery and degrade dynamics and bass response. SPECIAL POWER CORDS Your amplifier is provided with a decent standard power cord. Feel free to experiment, but beware of cords which sound significantly “different”.

  • Page 7: How To Replace The Lamp In The Power Switch

    HOW TO REPLACE THE LIGHT BULB IN YOUR POWER AMPLIFIER: Unplug your amp first! You must remove the red push button from the power switch. Grip the red button with your fingers on the top and bottom of the side which is out the most. Gently pull it out. It pops out easily.

  • Page 8: Packing Up Your Amplifier

    How To Repackage the CAT JL7 Power Amplifier: 1. Put the box on the ground. 2. Put the large piece of foam inside the bottom. 3. Put the amplifier in the cardboard cradle. Make sure the protective foam sheet is still in place, particularly in the front where it protects the shiny front plate.

  • Page 9: Warranty Registration

    WARRANTY: Your JL7 amplifier is warranted for six months from date of purchase. The warranty will be extended to three years with the return of the completed warranty registration form within 30 days of purchase. Be sure to include a copy of the sales receipt to validate your registration. Tubes carry a ninety day warranty.
