Installation Guide
This procedure is designed as an installation aid. Skilled trades people that are familiar
with general construction and electrical installation techniques should perform the
installation. Licensed electricians should provide electrical installation connections.
Installations and connections should be done in accordance with all national and local
codes and permits. In no way is this document intended to construe warranty or fitness
of use of the products described, nor is it intended to provide safety instruction for those
installing the product.
WARNING
Before proceeding with installation or service maintenance of this product:
• Disconnect power to reduce electrical shock risk.
• Review the entire Installation Guide.
• Inspect this properly packaged product for any damage that may have occurred during transit.
• Verify product application complies with manufacturer design recommendations.
• Verify the availability of necessary tools and incidental material.
• Verify applicable code requirements. Field assembly and installation are subject to acceptance by
local inspection authority.
• Appropriate safety equipment to be determined by end user, per applicable safety standards and
precautions.
LED Street Lighting
120-277 & 347-480Vac
EC Series

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LEOTEK EC Series and is the answer not in the manual?

Questions and answers

Summary of Contents for LiteOn LEOTEK EC Series

  • Page 1 LED Street Lighting 120-277 & 347-480Vac EC Series Installation Guide This procedure is designed as an installation aid. Skilled trades people that are familiar with general construction and electrical installation techniques should perform the installation. Licensed electricians should provide electrical installation connections. Installations and connections should be done in accordance with all national and local codes and permits.
  • Page 2 Step 1 - Unfasten the stainless steel latches Fig. 1 Step 2 - Open the power door . Power door will securely hang (Fig. 2-a) or is easily removed (Fig. 2-b). Fig. 2-a Fig. 2-b Step 3 - Loosen the two slip-fitter bracket bolts and insert the mounting arm.
  • Page 3 Step 4 - Adjust Drive Current Drive current should be set to comport with designed illumination levels and circuit loading. Consult with design engineer before changing. Unless ordered otherwise, the default factory setting is 700mA (blue wire). To change the setting to 530mA (yellow wire), open the fast connector shown in Fig 4-b, and change the connection accordingly.
